直接路由+目标网段——路由信息。协议字段：表示当前路由的生产方式，direct——直接。优先级：路由默认优先级，direct-0，越小越优先。1. 需求如下：需要配置两台PCPC1=19”。

直连路由

目标网段 —— 路由信息。

协议字段：代表当前路由的生产方式，direct——直连。

优先级：路由默认优先级，direct-0，越小越优先。

1.需求

如下拓扑图两台路由两台PC PC1 = 192.47.10.1/24 PC2 = 192.47.20.2/24 AR1 --- G0/0/0 = 12.47.1.1/24 G0/0/1 = 192.47.10.254/24 AR2 --- G0/0/0 = 12.47.1.2/24 G0/0/1 = 192.47.20.254 通过静态路由使得PC1与PC2能够进行通信

拓扑图

AR1配置：

[Huawei]sysname AR1 [AR1]interface GigabitEthernet 0/0/0 [AR1-GigabitEthernet0/0/0]ip address 12.47.1.1 24 [AR1-GigabitEthernet0/0/0]q [AR1] [AR1]interface GigabitEthernet 0/0/1 [AR1-GigabitEthernet0/0/1]ip address 192.47.10.254 24 [AR1-GigabitEthernet0/0/1]q [AR1] //添加静态路由 [AR1]ip route-static 192.47.20.0 24 12.47.1.2 [AR1]display ip routing-table

AR2配置：

[Huawei]sysname AR2 [AR2]interface GigabitEthernet 0/0/0 [AR2-GigabitEthernet0/0/0]ip address 12.47.1.2 24 [AR2-GigabitEthernet0/0/0]q [AR2] [AR2]interface GigabitEthernet 0/0/1 [AR2-GigabitEthernet0/0/1]ip address 192.47.20.254 24 [AR2-GigabitEthernet0/0/1]q //添加静态路由 [AR2]ip route-static 192.47.10.0 24 12.47.1.1 //查看路由表 [AR2]display ip routing-table

PC1对PC2进行通信测试：

2.需求

添加一台AR3使用S口与AR1和AR2相连接 PC1 = 192.47.10.1/24 PC2 = 192.47.20.2/24 AR1 --- G0/0/0 = 12.47.1.1/24 G0/0/1 = 192.47.10.254/24 S1/0/0 = 13.47.1.1/24 AR2 --- G0/0/0 = 12.47.1.2/24 G0/0/1 = 192.47.20.254/24 S1/0/0 = 23.47.1.2/24 AR3 --- S1/0/0 = 13.47.1.3/24 S1/0/1 = 23.47.1.3/24 通过静态路由使得全部通信 1.断开AR1与AR2 测试是否通过AR3进行通信。 2.修改优先级主从G口，S口作为备选。

拓扑图

AR3

//one---------- [Huawei]sysname AR3 [AR3] [AR3]interface Serial 1/0/0 [AR3-Serial1/0/0]ip address 13.47.1.3 24 [AR3-Serial1/0/0]q [AR3] [AR3]interface Serial 1/0/1 [AR3-Serial1/0/1]ip address 23.47.1.3 24 [AR3-Serial1/0/1]q [AR3] //two---------- //添加静态路由 [AR3]ip route-static 192.47.10.0 255.255.255.0 13.47.1.1 [AR3]ip route-static 192.47.20.0 255.255.255.0 23.47.1.2

AR1根据上面实验来做配置S1/0/0

//one---------- [AR1]interface Serial 1/0/0 [AR1-Serial1/0/0]ip ad [AR1-Serial1/0/0]ip address 13.47.1.1 [AR1-Serial1/0/0]q [AR1] //two---------- //添加静态路由 [AR1]ip route-static 23.47.1.0 24 13.47.1.3 [AR1]ip route-static 192.47.20.0 24 13.47.1.3

AR2根据上面实验来做配置S1/0/0

//one---------- [AR2]interface Serial 1/0/0 [AR2-Serial1/0/0]ip ad [AR2-Serial1/0/0]ip address 23.47.1.2 24 //two---------- //添加静态路由 [AR2]ip route-static 13.47.1.0 24 23.47.1.3 [AR2]ip route-static 192.47.10.0 24 23.47.1.3

断开AR1与AR2之间的线路：

[AR1]interface GigabitEthernet 0/0/0 [AR1-GigabitEthernet0/0/0]shutdown [AR2]interface GigabitEthernet 0/0/0 [AR2-GigabitEthernet0/0/0]shutdown

PC1对PC2进行通信测试：

打开AR1与AR2之间的线路测试：

[AR1]interface GigabitEthernet 0/0/0 [AR1-GigabitEthernet0/0/0]undo shutdown [AR2]interface GigabitEthernet 0/0/0 [AR2-GigabitEthernet0/0/0]undo shutdown

查看AR1的路由表：

根据上图可以得出结论： 去往192.47.20.0/24网段有两条路可以选择[12.47.1.2]和[13.47.1.3] 他们的优先级都是60所以在PC1与PC2通信时会分流进行各占百分之50的资源 因为S口是只有几m的传输速度比较缓慢所以咱们只能把他作为备用线路来使用 而G口是千兆口正常传输都是使用G口来传输比较快速高效当G口出现问题才会自动选取S口来进行流量放行 而选取主要的端口作为传输要道需要修改他们的优先级 优先级越小则就从那一条路由进行放行 下面我将使用G口作为主要路由通信，而S口作为备用通道，只需修改优先级即可 [AR1]ip route-static 192.47.20.0 24 13.47.1.3 preference 61 [AR2]ip route-static 192.47.10.0 24 23.47.1.3 preference 61 我把S口的路由线路修改大一级则就先选取优先级较小 当然我也可以把G口修改为59其结果也是一样

查看路由表发现只显示G口没有显示S口：

咱们把G口断开然后再次进行查看路由表：

[AR1]interface GigabitEthernet 0/0/0 [AR1-GigabitEthernet0/0/0]shutdown

根据上图路由表可以看出只要咱们配置好两条路由，就算主线路出现问题也是可以正常通信的，如上直接选取了优先级为61的13.47.1.3路由进行与其他设备通信。由此可得通过写多条路由可以进行备份，来防止线路出现损坏而不能正常接收流量等问题。

[AR1]ip route-static 192.47.20.0 24 13.47.1.3 [AR2]ip route-static 192.47.10.0 24 23.47.1.3 [AR3]ip route-static 192.47.10.0 24 13.47.1.1 [AR3]ip route-static 192.47.20.0 24 23.47.1.2 ip route 。。。。。 pre 61 [AR1]ip route-static 192.47.20.0 255.255.255.0 13.47.1.3 preference 61 Info: Succeeded in modifying route. [AR2]ip route-static 192.47.10.0 255.255.255.0 23.47.1.3 preference 61 Info: Succeeded in modifying route.

1.拓扑图

PC2

PC4

任务1_配置SW2和SW3使得PC1与PC4通信

SW2配置：

[Huawei]sysname SW2 [SW2] [SW2]vlan 10 [SW2-vlan10]q [SW2]interface e0/0/2 [SW2-Ethernet0/0/2]port link-type access [SW2-Ethernet0/0/2]port default vlan 10 [SW2-Ethernet0/0/2]q [SW2] [SW2]interface e0/0/3 [SW2-Ethernet0/0/3]port link-type access [SW2-Ethernet0/0/3]port default vlan 10 [SW2-Ethernet0/0/3]q [SW2] [SW2]interface e0/0/1 [SW2-GigabitEthernet0/0/1]port link-type trunk [SW2-GigabitEthernet0/0/1]port trunk allow-pass vlan all [SW2-GigabitEthernet0/0/1]q # 查看分配vlan [SW2]display port vlan Port Link Type PVID Trunk VLAN List ------------------------------------------------------------------------------- Ethernet0/0/1 hybrid 1 - Ethernet0/0/2 access 10 - Ethernet0/0/3 access 10 -

SW3配置：

[Huawei]sysname SW3 [SW3] [SW3]vlan 20 [SW3-vlan20]q [SW3]interface e0/0/2 [SW3-Ethernet0/0/2]port link-type access [SW3-Ethernet0/0/2]port default vlan 20 [SW3-Ethernet0/0/2]q [SW3] [SW3]interface e0/0/3 [SW3-Ethernet0/0/3]port link-type access [SW3-Ethernet0/0/3]port default vlan 20 [SW3-Ethernet0/0/3]q [SW3] [SW3]interface e0/0/1 [SW3-GigabitEthernet0/0/1]port link-type trunk [SW3-GigabitEthernet0/0/1]port trunk allow-pass vlan all [SW3-GigabitEthernet0/0/1]q # 查看分配vlan [SW3]display port vlan Port Link Type PVID Trunk VLAN List ------------------------------------------------------------------------------- Ethernet0/0/1 hybrid 1 - Ethernet0/0/2 access 20 - Ethernet0/0/3 access 20 -

SW1配置：

[Huawei]sysname SW1 [SW1]vlan batch 10 20 [SW1]interface Vlanif 10 [SW1-Vlanif10]ip address 172.47.1.254 24 [SW1-Vlanif10]q [SW1] [SW1]interface Vlanif 20 [SW1-Vlanif20]ip address 172.47.2.254 24 [SW1-Vlanif20]q [SW1] [SW1]interface GigabitEthernet 0/0/2 [SW1-GigabitEthernet0/0/2]port link-type trunk [SW1-GigabitEthernet0/0/2]port trunk allow-pass vlan all [SW1-GigabitEthernet0/0/2]q [SW1]interface GigabitEthernet 0/0/3 [SW1-GigabitEthernet0/0/3]port link-type trunk [SW1-GigabitEthernet0/0/3]port trunk allow-pass vlan all [SW1-Vlanif20]q [SW1]

PC4对PC2进行通信测试：

任务2_配置DHCP_server使得PC1与PC3获取地址使得通信：

SW1配置：

[SW1]vlan 100 [SW1-vlan100]q [SW1] [SW1]interface Vlanif 100 [SW1-Vlanif100]ip address 11.47.1.2 24 [SW1-Vlanif100]q [SW1] [SW1]interface GigabitEthernet 0/0/1 [SW1-GigabitEthernet0/0/1]port link-type access [SW1-GigabitEthernet0/0/1]port default vlan 100 [SW1-GigabitEthernet0/0/1]q [SW1]

AR1配置：

[Huawei]sysname AR1 [AR1]interface GigabitEthernet 0/0/0 [AR1-GigabitEthernet0/0/0]ip address 11.47.1.1 24 [AR1-GigabitEthernet0/0/0]q [AR1] [AR1]ip route-static 172.47.1.0 24 11.47.1.2 [AR1]ip route-static 172.47.2.0 24 11.47.1.2 # 开启dhcp [AR1]dhcp enable # 设置一个名为v10的地址池来分配地址给vlan10 [AR1]ip pool v10 [AR1-ip-pool-v10]gateway-list 172.47.1.254 [AR1-ip-pool-v10]network 172.47.1.0 mask 255.255.255.0 [AR1-ip-pool-v10]dns-list 8.8.8.8 [AR1-ip-pool-v10]q # 设置一个名为v20的地址池来分配地址给vlan20 [AR1]ip pool v20 [AR1-ip-pool-v20]gateway-list 172.47.2.254 [AR1-ip-pool-v20]network 172.47.2.0 mask 255.255.255.0 [AR1-ip-pool-v20]dns-list 8.8.8.8 [AR1-ip-pool-v20]q [AR1] # 放行地址 [AR1]interface GigabitEthernet 0/0/0 [AR1-GigabitEthernet0/0/0]dhcp select global [AR1-GigabitEthernet0/0/0]q [AR1]

SW1继续配置DHCP中继：

[SW1]dhcp enable [SW1]interface Vlanif 10 [SW1-Vlanif10]dhcp select relay [SW1-Vlanif10]dhcp relay server-ip 11.47.1.1 [SW1-Vlanif10]q [SW1]interface Vlanif 20 [SW1-Vlanif20]dhcp select relay [SW1-Vlanif20]dhcp relay server-ip 11.47.1.1 [SW1-Vlanif20]q [SW1]

PC1通过DHCP获取地址：

PC3通过DHCP获取地址：

测试AR1与PC2和PC4的通信：

任务3_配置AR2使得全部通信：

SW1配置：

[SW1]vlan 200 [SW1-vlan200]q [SW1] [SW1]interface Vlanif 200 [SW1-Vlanif200]ip address 12.47.1.2 24 [SW1-Vlanif200]q [SW1] [SW1]interface GigabitEthernet 0/0/4 [SW1-GigabitEthernet0/0/4]port link-type access [SW1-GigabitEthernet0/0/4]port default vlan 200 [SW1-GigabitEthernet0/0/4]q

AR2配置：

[Huawei]interface GigabitEthernet 0/0/0 [Huawei-GigabitEthernet0/0/0]ip address 12.47.1.1 24 [Huawei-GigabitEthernet0/0/0]q [Huawei] [Huawei]ip route-static 172.47.1.0 24 12.47.1.2 [Huawei]ip route-static 172.47.2.0 24 12.47.1.2 [Huawei]

AR2与PC2和PC3进行通信测试：

2.拓扑图

ISP

[AR3]interface GigabitEthernet 0/0/0 [AR3-GigabitEthernet0/0/0]ip address 100.47.1.254 24 [AR3-GigabitEthernet0/0/0]q [AR3] [AR3]interface GigabitEthernet 0/0/1 [AR3-GigabitEthernet0/0/1]ip address 200.47.1.254 24 [AR3-GigabitEthernet0/0/1]q [AR3] [AR3]sysname ISP [ISP] # 认证授权和收费三a认证 [ISP]aaa # 设置用户为WDJ-47 密码为huawei@123 [ISP-aaa]local-user WDJ-47 password cipher huawei@123 Info: Add a new user. [ISP-aaa] # 设置pppoe拨号 [ISP-aaa]local-user wdj-47 service-type ppp [ISP-aaa]q [ISP] # 配置虚拟模板 [ISP]interface Virtual-Template 0 [ISP-Virtual-Template0] # 设置认证模式 [ISP-Virtual-Template0]ppp authentication-mode ? chap Enable CHAP authentication # 推荐使用chap因为在发送过程中会加密 pap Enable PAP authentication [ISP-Virtual-Template0]ppp authentication-mode chap # 下发一个公网地址进行能够上网 [ISP-Virtual-Template0]remote address 202.47.1.2 # 设置虚拟地址 [ISP-Virtual-Template0]ip address 202.47.1.1 24 [ISP-Virtual-Template0]q [ISP] # 设置接口绑定（服务器端） [ISP] [ISP]interface GigabitEthernet 0/0/2 [ISP-GigabitEthernet0/0/2]pppoe-server bind virtual-template 0 [ISP-GigabitEthernet0/0/2]q [ISP]

AR2

# 配置客户端 # 创建拨号上网接口并且设置账户密码 [AR2]interface Dialer 0 [AR2-Dialer0] [AR2-Dialer0]ppp chap user WDJ-47 [AR2-Dialer0]ppp chap password cipher huawei@123 [AR2-Dialer0]ip address ppp-negotiate [AR2-Dialer0]dialer user 1 # 创建绑定编号 [AR2-Dialer0]dialer bundle 100 [AR2-Dialer0]q [AR2] # 拨号接口与物理接口进行绑定 [AR2]interface GigabitEthernet 0/0/1 [AR2-GigabitEthernet0/0/1]pppoe-client dial-bundle-number 100 [AR2-GigabitEthernet0/0/1]q [AR2] # 查看下发地址 检查AR2的Dialer0是否有地址 [AR2]display ip interface brief *down: administratively down ^down: standby (l): loopback (s): spoofing The number of interface that is UP in Physical is 4 The number of interface that is DOWN in Physical is 1 The number of interface that is UP in Protocol is 3 The number of interface that is DOWN in Protocol is 2 Interface IP Address/Mask Physical Protocol #Dialer0 202.47.1.2/32 up up(s) GigabitEthernet0/0/0 12.47.1.1/24 up up GigabitEthernet0/0/1 unassigned up down GigabitEthernet0/0/2 unassigned down down NULL0 unassigned up up(s) [AR2]

3.拓扑图

SW2配置：

[SW2]interface e0/0/4 [SW2-Ethernet0/0/4]port link-type access [SW2-Ethernet0/0/4]port default vlan 10 [SW2-Ethernet0/0/4]q [SW2]

AR1配置：

[AR1]interface GigabitEthernet 0/0/1 [AR1-GigabitEthernet0/0/1]ip address 10.47.1.254 24

SW1配置：

[SW1]ip route-static 10.47.1.0 24 11.47.1.1

任务需求：

需求：ACL访问控制列表 1.服务器2无法访问AR2 2.客户端2可以ping通服务器2，但是无法访问

解释ACL

标准ACL:2000-2999可以帮助匹配数据的源IP地址 高级ACL：3000-3999可以帮助匹配数据的五元组（源目IP，源目端口号，协议号） 二层ACL：4000-4999 可以帮助匹配MAC地址

sw1配置

[SW1]acl number 2000 # 过滤源地址 [SW1-acl-basic-2000]rule 5 deny source 172.47.1.1 0 [SW1-acl-basic-2000]q [SW1] # 调用acl [SW1]interface GigabitEthernet 0/0/2 [SW1-GigabitEthernet0/0/2]traffic-filter inbound acl 2000

验证server2无法访问AR2

[SW1]interface GigabitEthernet 0/0/2 [SW1-GigabitEthernet0/0/2]undo traffic-filter inbound acl 2000 [SW1-GigabitEthernet0/0/2]q [SW1]

[AR2]acl number 2000 [AR2-acl-basic-2000]rule 5 deny source 172.47.1.1 0 [AR2-acl-basic-2000]q [AR2]interface GigabitEthernet 0/0/0 [AR2-GigabitEthernet0/0/0]traffic-filter inbound acl 2000 [AR2-GigabitEthernet0/0/0]q [AR2]

测试通信：

测试通信：

[AR1]acl number 3000 [AR1-acl-adv-3000]rule deny tcp source 10.47.1.3 0 destination 172.47.1.1 0 destination-port eq www [AR1-acl-adv-3000]rule deny tcp source 10.47.1.3 0 destination 172.47.1.1 0 destination-port eq ftp [AR1-acl-adv-3000]q [AR1]interface GigabitEthernet 0/0/0 [AR1-GigabitEthernet0/0/0]traffic-filter outbound acl 3000 [AR1-GigabitEthernet0/0/0]q [AR1]

测试：

[AR2]ip route-static 0.0.0.0 0 202.47.1.1 [SW1]ip route-static 0.0.0.0 0 12.47.1.1

[AR2]acl 2001 [AR2-acl-basic-2001]rule permit source 172.47.1.0 0.0.0.255 [AR2-acl-basic-2001]rule permit source 172.47.2.0 0.0.0.255 [AR2-acl-basic-2001]q [AR2] [AR2]interface Dialer 0 [AR2-Dialer0]nat outbound 2001 [AR2-Dialer0]nat server protocol tcp global current-interface 5000 inside 172.47 .1.1 www [AR2]interface GigabitEthernet 0/0/0 [AR2-GigabitEthernet0/0/0]undo traffic-filter inbound
