Vue组织架构树图组件vue-org-tree

说明

最近需要作出一个组织架构图来可视化展示一下，最后找到vue-org-tree这个组件，觉得效果还不错~，可选节点颜色、横向/纵向展开、打开/收起，在这记录一下使用方法，效果图如下：

快速开始

安装

npm install --save-dev less less-loader npm install --save-dev vue2-org-tree

（可能还需要安装其他组件，报错的话根据提示再install就行）

然后在main.js引入

import Vue2OrgTree from 'vue2-org-tree'; Vue.use(Vue2OrgTree)

使用

<template> <div> <div class="container"> <div class="col-md-10 col-md-offset-1"> <div class="page-header"> <h3>基于Vue的组织架构树组件</h3> </div> <div class="row"> <div class="col-md-8 col-md-offset-2"> <form class="form-horizontal row"> <div class="col-md-4"> <div class="checkbox"> <label> <input type="checkbox" v-model="horizontal" > Horizontal </label> </div> </div> <div class="col-md-4"> <div class="checkbox"> <label> <input type="checkbox" v-model="collapsable" > Collapsable </label> </div> </div> <div class="col-md-4"> <div class="checkbox"> <label> <input type="checkbox" v-model="expandAll" @change="expandChange" > Expand All </label> </div> </div> <p><br></p> <p><br></p> <div class="col-md-6"> <div class="form-group"> <label class="control-label col-md-5">labelClassName:</label> <div class="col-md-7"> <select class="form-control" v-model="labelClassName" > <option value="bg-white">bg-white</option> <option value="bg-orange">bg-orange</option> <option value="bg-gold">bg-gold</option> <option value="bg-gray">bg-gray</option> <option value="bg-lightpink">bg-lightpink</option> <option value="bg-chocolate">bg-chocolate</option> <option value="bg-tomato">bg-tomato</option> </select> </div> </div> </div> </form> </div> </div> <p><br></p> <div class="text-center"> <vue2-org-tree name="test" :data="data" :horizontal="horizontal" :collapsable="collapsable" :label-class-name="labelClassName" :render-content="renderContent" @on-expand="onExpand" @on-node-click="onNodeClick" /> </div> </div> </div> </div> </template>

<script> export default { data() { return { data: { id: 0, label: "XXX科技有限公司", children: [ { id: 2, label: "产品研发部", children: [ { id: 5, label: "研发-前端" }, { id: 6, label: "研发-后端" }, { id: 9, label: "UI设计" }, { id: 10, label: "产品经理" } ] }, { id: 3, label: "销售部", children: [ { id: 7, label: "销售一部" }, { id: 8, label: "销售二部" } ] }, { id: 4, label: "财务部" }, { id: 9, label: "HR人事" } ] }, horizontal: false, collapsable: true, expandAll: false, labelClassName: "bg-white" }; }, methods: { renderContent(h, data) { return data.label; }, onExpand(data) { if ("expand" in data) { data.expand = !data.expand; if (!data.expand && data.children) { this.collapse(data.children); } } else { this.$set(data, "expand", true); } }, onNodeClick(e, data) { alert(data.label); }, collapse(list) { var _this = this; list.forEach(function(child) { if (child.expand) { child.expand = false; } child.children && _this.collapse(child.children); }); }, expandChange() { this.toggleExpand(this.data, this.expandAll); }, toggleExpand(data, val) { var _this = this; if (Array.isArray(data)) { data.forEach(function(item) { _this.$set(item, "expand", val); if (item.children) { _this.toggleExpand(item.children, val); } }); } else { this.$set(data, "expand", val); if (data.children) { _this.toggleExpand(data.children, val); } } } } }; </script>

<style type="text/css"> .org-tree-node-label { white-space: nowrap; } .bg-white { background-color: white; } .bg-orange { background-color: orange; } .bg-gold { background-color: gold; } .bg-gray { background-color: gray; } .bg-lightpink { background-color: lightpink; } .bg-chocolate { background-color: chocolate; } .bg-tomato { background-color: tomato; } </style>

API

• props

propdescriptontypedefaultdataObjectpropsconfigure propsObject{label: 'label', children: 'children', expand: 'expand'}labelWidthnode label widthString | Number.autocollapsablechildren node is collapsableBooleantruerenderContenthow to render node labelFunction-labelClassNamenode label classFunction | String-

events

• on-expand
• well be called when the collapse-btn clicked
• on-node-click
• well be called when the node-label clicked

参考html例子：github.com/hukaibaihu/vue-org-tree/blob/gh-pages/index.html

组件github：github.com/hukaibaihu/vue-org-tree

Vue组织架构图组件

vue-tree-chart

:deciduous_tree: Vue2树形图组件

安装：

npm i vue-tree-chart --save

使用：

• in template:

<TreeChart :json="treeData" />

• in script:

import TreeChart from "vue-tree-chart"; export default { components: { TreeChart }, data() { return { treeData: { ... } } } ...

属性：

• json

组件数据，支持字段：

• - name[String] 节点名称
• - image_url[String] 节点图片
• - children[Array] 节点后代
• - mate[Object] 节点配偶

示例：

{ name: 'root', image_url: "static.refined-x.com/avat.jpg", children: [ { name: 'children1', image_url: "static.refined-x.com/avat1.jpg" }, { name: 'children2', image_url: "static.refined-x.com/avat2.jpg", mate: { name: 'mate', image_url: "static.refined-x.com/avat3.jpg" }, children: [ { name: 'grandchild', image_url: "static.refined-x.com/avat.jpg" }, { name: 'grandchild2', image_url: "static.refined-x.com/avat1.jpg" }, { name: 'grandchild3', image_url: "static.refined-x.com/avat2.jpg" } ] }, { name: 'children3', image_url: "static.refined-x.com/avat.jpg" } ] }

事件：

• click-node

点击节点触发，接收当前节点数据为参数

演示：

npm run serve

构建：

npm run build-bundle

以上为个人经验，希望能给大家一个参考，也希望大家多多支持易盾网络。
