Vue ArcGISJavaScriptAPI如何实现地图交互与数据可视化功能？

本文共计850个文字，预计阅读时间需要4分钟。

目录 + 版本 + 环境搭建 + 新建Vue + 添加ArcGIS JavaScript + 包引入 + 复制资源信息 + 页面测试 + 版本 + Vue + ArcGIS JavaScript 4.22 + 注意 + ArcGIS JavaScript 3.x 与 ArcGIS JavaScript 4.x 差异 + 环境搭建 + 新建Vue + 可使用

目录

• 版本
• 环境搭建
• 新建vue
• 增加ArcGIS JavaScript 包引用
• 拷贝资源信息
• 页面测试

版本

Vue 2

ArcGIS JavaScript 4.22

注意 ArcGIS JavaScript3.x 和ArcGIS JavaScript 4.x框架差异较大

环境搭建

新建vue

可以使用vue ui创建项目

增加ArcGIS JavaScript 包引用

package.json

"dependencies": { "core-js": "^3.8.3", "vue": "^2.6.14", "@arcgis/core":"4.22.2", "ncp":"^2.0.0" }, "devDependencies": { "@babel/core": "^7.12.16", "@babel/eslint-parser": "^7.12.16", "@vue/cli-plugin-babel": "~5.0.0", "@vue/cli-plugin-eslint": "~5.0.0", "@vue/cli-service": "~5.0.0", "eslint": "^6.8.0", "eslint-plugin-vue": "^5.2.3", "vue-template-compiler": "^2.6.14" },

ncp: 主要用于拷贝资源信息

@arcgis/core 是arcgis_js仓库

拷贝资源信息

package.json中配置copy命令

"scripts": { "serve": "vue-cli-service serve", "build": "vue-cli-service build", "lint": "vue-cli-service lint", "copy": "ncp ./node_modules/@arcgis/core/assets ./public/assets" },

安装完依赖后运行 copy命令

yarn yarn copy yarn serve ------------------- npm i npm run copy npm run serve

运行完copy命令后,会将arcgis相关资源拷贝到public/assets目录下

全局引入

main.js

import '@arcgis/core/assets/esri/themes/light/main.css' import esriConfig from '@arcgis/core/config.js' esriConfig.assetsPath = './assets'

页面测试

helloworld.vue

<template> <div class="hello"> <div id="map" class="map" v-show="flag == 'map'"> </div> <div id="earth" class="map" v-show="flag == 'earth'"></div> </div> </template> <script> import Map from '@arcgis/core/Map' import MapView from '@arcgis/core/views/MapView' import MapImageLayer from '@arcgis/core/layers/MapImageLayer' import ElevationLayer from '@arcgis/core/layers/ElevationLayer' import BaseElevationLayer from '@arcgis/core/layers/BaseElevationLayer' import SpatialReference from '@arcgis/core/geometry/SpatialReference' import SceneView from '@arcgis/core/views/SceneView' import Basemap from '@arcgis/core/Basemap' import TileLayer from '@arcgis/core/layers/TileLayer' export default { name: 'HelloWorld', data() { return { mapView: null, map: null, map3d: null, flag: 'earth' } }, mounted() { this.initBasemap() }, methods: { initBasemap() { const self = this //二维 const mapImageLayer = new MapImageLayer({ url: "192.168.3.156:6080/arcgis/rest/services/xiangyang/jichang/MapServer" }) this.map = new Map({ // basemap: basemap, layers: [mapImageLayer] }) this.mapView = new MapView({ container: 'map', map: self.map, spatialReference: new SpatialReference({ wkid: 3857 }), rotation: 41.2, zoom: 3 }) // 三维地形 const ExaggeratedElevationLayer = BaseElevationLayer.createSubclass({ properties: { exaggeration: 10 }, load: function () { // TopoBathy3D contains elevation values for both land and ocean ground this._elevation = new ElevationLayer({ url: "elevation3d.arcgis.com/arcgis/rest/services/WorldElevation3D/TopoBathy3D/ImageServer" }); this.addResolvingPromise( this._elevation.load().then(() => { this.tileInfo = this._elevation.tileInfo; this.spatialReference = this._elevation.spatialReference; this.fullExtent = this._elevation.fullExtent; }) ); return this; }, // Fetches the tile(s) visible in the view fetchTile: function (level, row, col, options) { // calls fetchTile() on the elevationlayer for the tiles // visible in the view return this._elevation.fetchTile(level, row, col, options).then( function (data) { const exaggeration = this.exaggeration; for (let i = 0; i < data.values.length; i++) { // Multiply the given pixel value // by the exaggeration value data.values[i] = data.values[i] * exaggeration; } return data; }.bind(this) ); } }); const basemap = new Basemap({ baseLayers: [ new TileLayer({ url: "services.arcgisonline.com/ArcGIS/rest/services/World_Imagery/MapServer" }), new TileLayer({ url: "tiles.arcgis.com/tiles/nGt4QxSblgDfeJn9/arcgis/rest/services/terrain_with_heavy_bathymetry/MapServer" }), ] }); const elevationLayer = new ExaggeratedElevationLayer(); this.map3d = new Map({ basemap: basemap, ground: { layers: [elevationLayer] } }); const view = new SceneView({ container: "earth", map: this.map3d, alphaCompositingEnabled: true, qualityProfile: "high", camera: { position: [-55.039, 14.948, 19921223.3], heading: 2.03, tilt: 0.13 }, environment: { background: { type: "color", color: [255, 252, 244, 0] }, starsEnabled: true, atmosphereEnabled: true, lighting: { type: "virtual" } }, }); this.map3d.ground = { layers: [elevationLayer] }; } } } </script> <!-- Add "scoped" attribute to limit CSS to this component only --> <style scoped> .hello { width: 100%; height: 100%; } .map { width: 100%; height: 100%; } </style>

demo地址

gitee.com/wolf_pro/vue_arcgis4.22.git
