如何详细安装Ubuntu16.04上Opencv 3.2.0及3.0.0-alpha版本的源码？

本文共计822个文字，预计阅读时间需要4分钟。

教程1：Opencv3.0.0-alpha在Ubuntu16.04的安装

1. 更新系统包列表： bash sudo apt-get update

2. 安装依赖项： bash sudo apt-get install build-essential cmake git libopencv-dev

3. 克隆Opencv源代码： bash git clone https://github.com/opencv/opencv.git cd opencv git checkout 3.0.0-alpha

4. 创建构建目录： bash mkdir build cd build

5. 配置并编译Opencv： bash cmake .. make -j4 # 使用4个线程编译

6. 安装Opencv： bash sudo make install

7. 检查安装： bash opencv-version

教程1： Opencv3.0.0-alpha在ubuntu16.04的安装

# step 1
# 安装依赖 （太多了，自己相应替换）
sudo apt-get -y install libopencv-dev build-essential cmake git libgtk2.0-dev pkg-config python-dev python-numpy libdc1394-22 libdc1394-22-dev libjpeg-dev libpng12-dev libjasper-dev libavcodec-dev libavformat-dev libswscale-dev libgstreamer0.10-dev libgstreamer-plugins-base0.10-dev libv4l-dev libtbb-dev libqt4-dev libfaac-dev libmp3lame-dev libopencore-amrnb-dev libopencore-amrwb-dev libtheora-dev libvorbis-dev libxvidcore-dev x264 v4l-utils unzip

sudo apt-get -y install libopencv-dev build-essential cmake git libgtk2.0-dev pkg-config python-dev python-numpy libdc1394-22 libdc1394-22-dev libjpeg-dev libpng12-dev libjasper-dev libavcodec-dev libavformat-dev libswscale-dev libgstreamer0.10-dev libgstreamer-plugins-base0.10-dev libv4l-dev libtbb-dev libqt4-dev libfaac-dev libmp3lame-dev libopencore-amrnb-dev libopencore-amrwb-dev libtheora-dev libvorbis-dev libxvidcore-dev x264 v4l-utils unzip --fix-missing


# step 2
# 下载解包
wget github.com/Itseez/opencv/archive/3.0.0-alpha.zip
unzip opencv-3.0.0-alpha.zip
# step 3
# 编译
cd opencv-3.0.0-alpha
mkdir build
cd build
cmake -D CMAKE_BUILD_TYPE=RELEASE -D CMAKE_INSTALL_PREFIX=/usr/local -D WITH_TBB=ON -D BUILD_NEW_PYTHON_SUPPORT=ON -D WITH_V4L=ON -D WITH_QT=ON -D WITH_OPENGL=ON ..
# step 4
#安装
make
sudo make install

# step 5
# 安装完成，进行整理
sudo /bin/bash -c 'echo "/usr/local/lib" > /etc/ld.so.conf.d/opencv.conf'
sudo ldconfig
sudo apt-get update

教程2：

今天重装了Opencv3.20 和Opencv3.2.0conbtrib，将安装日志记录如下：

1. 查询自己的Opencv版本 ​​pkg-config --modversion opencv​​

2. 下载​​Opencv3.2.0 和Opencv contrib3.2.0​​ 对于opencv3.2.0 ​​​pan.baidu.com/s/1bp03gab​​​ 对于Opencv3.2.0 contrib

3. 卸载当前的Opencv ,进入安装的build目录,执行 ​​sudo make uninstall​​ ，然后​​cd ..​​ 执行​​rm -rf build​​

4. 清理/usr中所有的opencv相关选项 ​​rm -r /usr/local/include/opencv2 /usr/local/include/opencv /usr/include/opencv /usr/include/opencv2 /usr/local/share/opencv /usr/local/share/OpenCV /usr/share/opencv /usr/share/OpenCV /usr/local/bin/opencv* /usr/local/lib/libopencv*​​

5. 执行 ​​sudo make -j16​​ 和 ​​sudo make install​​ ， 在make的时候我遇到一个问题就是​​fatal error: LAPACKE_H_PATH-NOTFOUND/lapacke.h​​: ​​No such file or directory #include “LAPACKE_H_PATH-NOTFOUND/lapacke.h​​” 原因：未找到lapacke.h文件 ，只需要​​sudo apt-get install liblapacke-dev checkinstall​​就可以解决继续make了。成功后进行第5步。

6. ​​cd /usr​​

7. ​​find . -name "*opencv*" | xargs sudo rm -rf​​

8. 成功后在终端中打开 /etc/ld.conf.d/opencv.conf 文件，并在最后一行添加 /usr/local/lib，如果没有这个文件那就新建一个。然后打开 /etc/bash.bashrc 文件，在最后一行中添加

PKG_CONFIG_PATH=$PKG_CONFIG_PATH:/usr/local/opencv320/lib/pkgconfig
export PKG_CONFIG_PATH

最后. ​​sudo ldconfig​​生效

备注：最后使用​​pkg-config --modversion opencv​​查询版本如果报错为：

Package opencv was not found in the pkg-config search path.
Perhaps you should add the directory containing `opencv.pc'
to the PKG_CONFIG_PATH environment variable
No package 'opencv' found

则需要运行下边语句：

sudo cp /usr/local/opencv320/lib/pkgconfig/opencv.pc /usr/lib/pkgconfig
