扇形统计图+绘制扇形原理也基于Canvas进行绘制；绘制弧段形状；绘制指示线；绘制文本；鼠标移入动画；显示详情Popup；源码Github[2]Gitee[3]示例代码1）SectorChart.cs代码

扇形统计图

• 绘制一个扇形原理也是基于Canvas进行绘制;
• ArcSegment[1]绘制弧形;
• 绘制指示线；
• 绘制文本；
• 鼠标移入动画；
• 显示详情Popup；
• 源码Github[2]Gitee[3]

示例代码

1）SectorChart.cs代码如下;

using System; using System.Collections.Generic; using System.Collections.ObjectModel; using System.Linq; using System.Windows; using System.Windows.Controls; using System.Windows.Controls.Primitives; using System.Windows.Input; using System.Windows.Media; using System.Windows.Media.Animation; using System.Windows.Media.Effects; using System.Windows.Shapes; using WPFDevelopers.Charts.Models; namespace WPFDevelopers.Charts.Controls {     [TemplatePart(Name = CanvasTemplateName, Type = typeof(Canvas))]     [TemplatePart(Name = PopupTemplateName, Type = typeof(Popup))]     public class SectorChart : Control     {         const string CanvasTemplateName = "PART_Canvas";         const string PopupTemplateName = "PART_Popup";         private Canvas _canvas;         private Popup _popup;         private double centenrX, centenrY, radius, offsetX, offsetY;         private Point minPoint;         private double fontsize = 12;         private bool flg = false;         public Brush Fill         {             get { return (Brush)GetValue(FillProperty); }             set { SetValue(FillProperty, value); }         }         public static readonly DependencyProperty FillProperty =             DependencyProperty.Register("Fill", typeof(Brush), typeof(SectorChart), new PropertyMetadata(null));         public string Text         {             get { return (string)GetValue(TextProperty); }             set { SetValue(TextProperty, value); }         }         public static readonly DependencyProperty TextProperty =             DependencyProperty.Register("Text", typeof(string), typeof(SectorChart), new PropertyMetadata(null));         public ObservableCollection<PieSerise> ItemsSource         {             get { return (ObservableCollection<PieSerise>)GetValue(ItemsSourceProperty); }             set { SetValue(ItemsSourceProperty, value); }         }         public static readonly DependencyProperty ItemsSourceProperty =             DependencyProperty.Register("ItemsSource", typeof(ObservableCollection<PieSerise>), typeof(SectorChart), new PropertyMetadata(null, new PropertyChangedCallback(ItemsSourceChanged)));         private static void ItemsSourceChanged(DependencyObject d, DependencyPropertyChangedEventArgs e)         {             var view = d as SectorChart;             if (e.NewValue != null)                 view.DrawArc();         }         static SectorChart()         {             DefaultStyleKeyProperty.OverrideMetadata(typeof(SectorChart), new FrameworkPropertyMetadata(typeof(SectorChart)));         }         public override void OnApplyTemplate()         {             base.OnApplyTemplate();             _canvas = GetTemplateChild(CanvasTemplateName) as Canvas;             _popup = GetTemplateChild(PopupTemplateName) as Popup;         }         void DrawArc()         {             if (ItemsSource is null || !ItemsSource.Any() || _canvas is null)                 return;             _canvas.Children.Clear();             var pieWidth = _canvas.ActualWidth > _canvas.ActualHeight ? _canvas.ActualHeight : _canvas.ActualWidth;             var pieHeight = _canvas.ActualWidth > _canvas.ActualHeight ? _canvas.ActualHeight : _canvas.ActualWidth;             centenrX = pieWidth / 2;             centenrY = pieHeight / 2;             radius = this.ActualWidth > this.ActualHeight ? this.ActualHeight / 2 : this.ActualWidth / 2;             double angle = 0;             double prevAngle = 0;             var sum = ItemsSource.Select(ser => ser.Percentage).Sum();             foreach (var item in ItemsSource)             {                 var line1X = radius * Math.Cos(angle * Math.PI / 180) + centenrX;                 var line1Y = radius * Math.Sin(angle * Math.PI / 180) + centenrY;                 angle = item.Percentage / sum * 360 + prevAngle;                 double arcX = 0;                 double arcY = 0;                 if (ItemsSource.Count() == 1 && angle == 360)                 {                     arcX = centenrX + Math.Cos(359.99999 * Math.PI / 180) * radius;                     arcY = (radius * Math.Sin(359.99999 * Math.PI / 180)) + centenrY;                 }                 else                 {                     arcX = centenrX + Math.Cos(angle * Math.PI / 180) * radius;                     arcY = (radius * Math.Sin(angle * Math.PI / 180)) + centenrY;                 }                 var line1Segment = new LineSegment(new Point(line1X, line1Y), false);                 bool isLargeArc = item.Percentage / sum > 0.5;                 var arcWidth = radius;                 var arcHeight = radius;                 var arcSegment = new ArcSegment();                 arcSegment.Size = new Size(arcWidth, arcHeight);                 arcSegment.Point = new Point(arcX, arcY);                 arcSegment.SweepDirection = SweepDirection.Clockwise;                 arcSegment.IsLargeArc = isLargeArc;                 var line2Segment = new LineSegment(new Point(centenrX, centenrY), false);                 PieBase piebase = new PieBase();                 piebase.Title = item.Title;                 piebase.Percentage = item.Percentage;                 piebase.PieColor = item.PieColor;                 piebase.LineSegmentStar = line1Segment;                 piebase.ArcSegment = arcSegment;                 piebase.LineSegmentEnd = line2Segment;                 piebase.Angle = item.Percentage / sum * 360;                 piebase.StarPoint = new Point(line1X, line1Y);                 piebase.EndPoint = new Point(arcX, arcY);                 var pathFigure = new PathFigure(new Point(centenrX, centenrY), new List<PathSegment>()                 {                     line1Segment,                     arcSegment,                    line2Segment,                 }, true);                 var pathFigures = new List<PathFigure>()                 {                     pathFigure,                 };                 var pathGeometry = new PathGeometry(pathFigures);                 var path = new Path() { Fill = item.PieColor, Data = pathGeometry, DataContext = piebase };                 _canvas.Children.Add(path);                 prevAngle = angle;                 var line3 = DrawLine(path);                 if (line3 != null)                     piebase.Line = line3;                 var textPathGeo = DrawText(path);                 var textpath = new Path() { Fill = item.PieColor, Data = textPathGeo };                 piebase.TextPath = textpath;                 _canvas.Children.Add(textpath);                 path.MouseMove += Path_MouseMove1;                 path.MouseLeave += Path_MouseLeave;                 if (ItemsSource.Count() == 1 && angle == 360)                 {                     _canvas.Children.Add(line3);                 }                 else                 {                     var outline1 = new Line()                     {                         X1 = centenrX,                         Y1 = centenrY,                         X2 = line1Segment.Point.X,                         Y2 = line1Segment.Point.Y,                         Stroke = Brushes.White,                         StrokeThickness = 0.8,                     };                     var outline2 = new Line()                     {                         X1 = centenrX,                         Y1 = centenrY,                         X2 = arcSegment.Point.X,                         Y2 = arcSegment.Point.Y,                         Stroke = Brushes.White,                         StrokeThickness = 0.8,                     };                     _canvas.Children.Add(outline1);                     _canvas.Children.Add(outline2);                     _canvas.Children.Add(line3);                 }             }         }         private void Path_MouseLeave(object sender, MouseEventArgs e)         {             _popup.IsOpen = false;             var path = sender as Path;             var dt = path.DataContext as PieBase;             TranslateTransform ttf = new TranslateTransform();             ttf.X = 0;             ttf.Y = 0;             path.RenderTransform = ttf;             dt.Line.RenderTransform = new TranslateTransform()             {                 X = 0,                 Y = 0,             };             dt.TextPath.RenderTransform = new TranslateTransform()             {                 X = 0,                 Y = 0,             };             path.Effect = new DropShadowEffect()             {                 Color = (Color)ColorConverter.ConvertFromString("#FF949494"),                 BlurRadius = 20,                 Opacity = 0,                 ShadowDepth = 0             };             flg = false;         }         private void Path_MouseMove1(object sender, MouseEventArgs e)         {             Path path = sender as Path;             //动画             if (!flg)             {                 BegionOffsetAnimation(path);             }             ShowMousePopup(path, e);         }         void ShowMousePopup(Path path, MouseEventArgs e)         {             var data = path.DataContext as PieBase;             if (!_popup.IsOpen)                 _popup.IsOpen = true;             var mousePosition = e.GetPosition((UIElement)_canvas.Parent);             _popup.HorizontalOffset = mousePosition.X + 20;             _popup.VerticalOffset = mousePosition.Y + 20;             Text = (data.Title + " : " + data.Percentage);//显示鼠标当前坐标点             Fill = data.PieColor;         }         void BegionOffsetAnimation(Path path)         {             NameScope.SetNameScope(this, new NameScope());             var pathDataContext = path.DataContext as PieBase;             var angle = pathDataContext.Angle;             minPoint = new Point(Math.Round(pathDataContext.StarPoint.X + pathDataContext.EndPoint.X) / 2, Math.Round(pathDataContext.StarPoint.Y + pathDataContext.EndPoint.Y) / 2);             var v1 = minPoint - new Point(centenrX, centenrY);             var v2 = new Point(2000, 0) - new Point(0, 0);             double vAngle = 0;             if (180 < angle && angle <= 360 && pathDataContext.Percentage / ItemsSource.Select(p => p.Percentage).Sum() >= 0.5)             {                 vAngle = Math.Round(Vector.AngleBetween(v2, -v1));             }             else             {                 vAngle = Math.Round(Vector.AngleBetween(v2, v1));             }             offsetX = 10 * Math.Cos(vAngle * Math.PI / 180);             offsetY = 10 * Math.Sin(vAngle * Math.PI / 180);             var line3 = pathDataContext.Line;             var textPath = pathDataContext.TextPath;             TranslateTransform LineAnimatedTranslateTransform =                 new TranslateTransform();             this.RegisterName("LineAnimatedTranslateTransform", LineAnimatedTranslateTransform);             line3.RenderTransform = LineAnimatedTranslateTransform;             TranslateTransform animatedTranslateTransform =                 new TranslateTransform();             this.RegisterName("AnimatedTranslateTransform", animatedTranslateTransform);             path.RenderTransform = animatedTranslateTransform;             TranslateTransform TextAnimatedTranslateTransform =                new TranslateTransform();             this.RegisterName("TextAnimatedTranslateTransform", animatedTranslateTransform);             textPath.RenderTransform = animatedTranslateTransform;             DoubleAnimation daX = new DoubleAnimation();             Storyboard.SetTargetProperty(daX, new PropertyPath(TranslateTransform.XProperty));             daX.Duration = new Duration(TimeSpan.FromSeconds(0.2));             daX.From = 0;             daX.To = offsetX;             DoubleAnimation daY = new DoubleAnimation();             Storyboard.SetTargetName(daY, nameof(animatedTranslateTransform));             Storyboard.SetTargetProperty(daY, new PropertyPath(TranslateTransform.YProperty));             daY.Duration = new Duration(TimeSpan.FromSeconds(0.2));             daY.From = 0;             daY.To = offsetY;             path.Effect = new DropShadowEffect()             {                 Color = (Color)ColorConverter.ConvertFromString("#2E2E2E"),                 BlurRadius = 33,                 Opacity = 0.6,                 ShadowDepth = 0             };             animatedTranslateTransform.BeginAnimation(TranslateTransform.XProperty, daX);             animatedTranslateTransform.BeginAnimation(TranslateTransform.YProperty, daY);             LineAnimatedTranslateTransform.BeginAnimation(TranslateTransform.XProperty, daX);             LineAnimatedTranslateTransform.BeginAnimation(TranslateTransform.YProperty, daY);             TextAnimatedTranslateTransform.BeginAnimation(TranslateTransform.XProperty, daX);             TextAnimatedTranslateTransform.BeginAnimation(TranslateTransform.YProperty, daY);             flg = true;         }         /// <summary>         /// 画指示线         /// </summary>         /// <param name="path"></param>         /// <returns></returns>         Polyline DrawLine(Path path)         {             NameScope.SetNameScope(this, new NameScope());             var pathDataContext = path.DataContext as PieBase;             var angle = pathDataContext.Angle;             pathDataContext.Line = null;             minPoint = new Point(Math.Round(pathDataContext.StarPoint.X + pathDataContext.EndPoint.X) / 2, Math.Round(pathDataContext.StarPoint.Y + pathDataContext.EndPoint.Y) / 2);             Vector v1;             if (angle > 180 && angle < 360)             {                 v1 = new Point(centenrX, centenrY) - minPoint;             }             else if (angle == 180 || angle == 360)             {                 if (Math.Round(pathDataContext.StarPoint.X) == Math.Round(pathDataContext.EndPoint.X))                 {                     v1 = new Point(radius * 2, radius) - new Point(centenrX, centenrY);                 }                 else                 {                     if (Math.Round(pathDataContext.StarPoint.X) - Math.Round(pathDataContext.EndPoint.X) == 2 * radius)                     {                         v1 = new Point(radius, 2 * radius) - new Point(centenrX, centenrY);                     }                     else                     {                         v1 = new Point(radius, 0) - new Point(centenrX, centenrY);                     }                 }             }             else             {                 v1 = minPoint - new Point(centenrX, centenrY);             }             v1.Normalize();             var Vmin = v1 * radius;             var RadiusToNodal = Vmin + new Point(centenrX, centenrY);             var v2 = new Point(2000, 0) - new Point(0, 0);             double vAngle = 0;             vAngle = Math.Round(Vector.AngleBetween(v2, v1));             offsetX = 10 * Math.Cos(vAngle * Math.PI / 180);             offsetY = 10 * Math.Sin(vAngle * Math.PI / 180);             var prolongPoint = new Point(RadiusToNodal.X + offsetX * 1, RadiusToNodal.Y + offsetY * 1);             if (RadiusToNodal.X == double.NaN || RadiusToNodal.Y == double.NaN || prolongPoint.X == double.NaN || prolongPoint.Y == double.NaN)                 return null;             var point1 = RadiusToNodal;             var point2 = prolongPoint;             Point point3;             if (prolongPoint.X >= radius)                 point3 = new Point(prolongPoint.X + 10, prolongPoint.Y);             else                 point3 = new Point(prolongPoint.X - 10, prolongPoint.Y);             PointCollection polygonPoints = new PointCollection();             polygonPoints.Add(point1);             polygonPoints.Add(point2);             polygonPoints.Add(point3);             var line3 = new Polyline();             line3.Points = polygonPoints;             line3.Stroke = pathDataContext.PieColor;             pathDataContext.PolylineEndPoint = point3;             return line3;         }         PathGeometry DrawText(Path path)         {             NameScope.SetNameScope(this, new NameScope());             var pathDataContext = path.DataContext as PieBase;             Typeface typeface = new Typeface                 (new FontFamily("Microsoft YaHei"),                 FontStyles.Normal,                 FontWeights.Normal, FontStretches.Normal);             FormattedText text = new FormattedText(                 pathDataContext.Title,                 new System.Globalization.CultureInfo("zh-cn"),                 FlowDirection.LeftToRight, typeface, fontsize, Brushes.RosyBrown                 );             var textWidth = text.Width;             Geometry geo = null;             if (pathDataContext.PolylineEndPoint.X > radius)                 geo = text.BuildGeometry(new Point(pathDataContext.PolylineEndPoint.X + 4, pathDataContext.PolylineEndPoint.Y - fontsize / 1.8));             else                 geo = text.BuildGeometry(new Point(pathDataContext.PolylineEndPoint.X - textWidth - 4, pathDataContext.PolylineEndPoint.Y - fontsize / 1.8));             PathGeometry pathGeometry = geo.GetFlattenedPathGeometry();             return pathGeometry;         }     } }

2)SectorChart.xaml 代码如下；

<ResourceDictionary xmlns="schemas.microsoft.com/winfx/2006/xaml/presentation"                     xmlns:x="schemas.microsoft.com/winfx/2006/xaml"                     xmlns:controls="clr-namespace:WPFDevelopers.Charts.Controls">     <Style TargetType="{x:Type controls:SectorChart}">         <Setter Property="Width" Value="300"/>         <Setter Property="Height" Value="300"/>         <Setter Property="Template">             <Setter.Value>                 <ControlTemplate TargetType="{x:Type controls:SectorChart}">                     <Grid>                         <Popup x:Name="PART_Popup"                                 IsOpen="False"                                Placement="Relative"                                 AllowsTransparency="True">                             <Border Background="White"                                      CornerRadius="5"                                      Padding="14"                                     BorderThickness="0"                                     BorderBrush="Transparent">                                 <StackPanel >                                     <Ellipse Width="20" Height="20"                                              Fill="{TemplateBinding Fill}"/>                                     <TextBlock Background="White"                                                 Padding="9,4,9,4" TextWrapping="Wrap"                                                 Text="{TemplateBinding Text}"/>                                 </StackPanel>                             </Border>                         </Popup>                         <Canvas x:Name="PART_Canvas"  HorizontalAlignment="{TemplateBinding HorizontalContentAlignment}"                                 Width="{TemplateBinding ActualWidth}"                                 Height="{TemplateBinding ActualHeight}">                         </Canvas>                     </Grid>                 </ControlTemplate>             </Setter.Value>         </Setter>     </Style> </ResourceDictionary>

3） MainWindow.xaml使用如下；

 xmlns:wsCharts="github.com/WPFDevelopersOrg.WPFDevelopers.Charts" <wsCharts:SectorChart  ItemsSource="{Binding ItemsSource,RelativeSource={RelativeSource AncestorType=local:MainWindow}}"                                   Margin="30" />

4） MainWindow.xaml.cs代码如下；

using System.Collections.ObjectModel; using System.Windows; using System.Windows.Media; using WPFDevelopers.Charts.Models; namespace WPFDevelopers.Charts.Samples {     /// <summary>     /// MainWindow.xaml 的交互逻辑     /// </summary>     public partial class MainWindow      {         public ObservableCollection<PieSerise> ItemsSource         {             get { return (ObservableCollection<PieSerise>)GetValue(ItemsSourceProperty); }             set { SetValue(ItemsSourceProperty, value); }         }         public static readonly DependencyProperty ItemsSourceProperty =             DependencyProperty.Register("ItemsSource", typeof(ObservableCollection<PieSerise>), typeof(MainWindow), new PropertyMetadata(null));         public MainWindow()         {             InitializeComponent();             Loaded += MainWindow_Loaded;         }         private void MainWindow_Loaded(object sender, RoutedEventArgs e)         {             ItemsSource = new ObservableCollection<PieSerise>();             var collection1 = new ObservableCollection<PieSerise>();             collection1.Add(new PieSerise             {                 Title = "2012",                 Percentage = 30,                 PieColor = new SolidColorBrush((Color)ColorConverter.ConvertFromString("#5B9BD5")),             });             collection1.Add(                 new PieSerise                 {                     Title = "2013",                     Percentage = 140,                     PieColor = new SolidColorBrush((Color)ColorConverter.ConvertFromString("#4472C4")),                 });             collection1.Add(new PieSerise             {                 Title = "2014",                 Percentage = 49,                 PieColor = new SolidColorBrush((Color)ColorConverter.ConvertFromString("#007fff")),             });             collection1.Add(new PieSerise             {                 Title = "2015",                 Percentage = 50,                 PieColor = new SolidColorBrush((Color)ColorConverter.ConvertFromString("#ED7D31")),             });             collection1.Add(new PieSerise             {                 Title = "2016",                 Percentage = 30,                 PieColor = new SolidColorBrush((Color)ColorConverter.ConvertFromString("#FFC000")),             });             collection1.Add(new PieSerise             {                 Title = "2017",                 Percentage = 30,                 PieColor = new SolidColorBrush((Color)ColorConverter.ConvertFromString("#ff033e")),             });             ItemsSource = collection1;         }     } }

以上就是WPF实现绘制扇形统计图的示例代码的详细内容，更多关于WPF扇形统计图的资料请关注自由互联其它相关文章！
