WPF 使用 DrawingContext 绘制温度计

框架使用大于等于.NET40；

Visual Studio 2022;

项目使用MIT开源许可协议；

定义Interval步长、MaxValue最大温度值、MinValue最小温度值。

CurrentGeometry重新绘制当前刻度的Path值。

CurrentValue当前值如果发生变化时则去重新CurrentGeometry。

OnRender绘制如下

• RoundedRectangle温度计的外边框。
• 使用方法DrawText单字绘制华氏温度文本Y轴变化。
• 使用方法DrawText单字绘制摄氏温度文本Y轴变化。
• 使用方法DrawText绘制温度计两侧的刻度数值。
• 使用方法DrawLine绘制温度计两侧的刻度线。

实现代码

1） 准备Thermometer.cs如下：

using System; using System.Windows; using System.Windows.Controls; using System.Windows.Media; namespace WPFDevelopers.Controls {     public class Thermometer : Control     {         public static readonly DependencyProperty MaxValueProperty =             DependencyProperty.Register("MaxValue", typeof(double), typeof(Thermometer), new UIPropertyMetadata(40.0));         public static readonly DependencyProperty MinValueProperty =             DependencyProperty.Register("MinValue", typeof(double), typeof(Thermometer), new UIPropertyMetadata(-10.0));         /// <summary>         ///     当前值         /// </summary>         public static readonly DependencyProperty CurrentValueProperty =             DependencyProperty.Register("CurrentValue", typeof(double), typeof(Thermometer),                 new UIPropertyMetadata(OnCurrentValueChanged));         /// <summary>         ///     步长         /// </summary>         public static readonly DependencyProperty IntervalProperty =             DependencyProperty.Register("Interval", typeof(double), typeof(Thermometer), new UIPropertyMetadata(10.0));         /// <summary>         ///     当前值的图形坐标点         /// </summary>         public static readonly DependencyProperty CurrentGeometryProperty =             DependencyProperty.Register("CurrentGeometry", typeof(Geometry), typeof(Thermometer), new PropertyMetadata(                 Geometry.Parse(@"M 2 132.8                               a 4 4 0 0 1 4 -4                               h 18                               a 4 4 0 0 1 4 4                               v 32.2                               a 4 4 0 0 1 -4 4                               h -18                               a 4 4 0 0 1 -4 -4 z")));         /// <summary>         ///     构造函数         /// </summary>         static Thermometer()         {             DefaultStyleKeyProperty.OverrideMetadata(typeof(Thermometer),                 new FrameworkPropertyMetadata(typeof(Thermometer)));         }         public double MaxValue         {             get => (double)GetValue(MaxValueProperty);             set => SetValue(MaxValueProperty, value);         }         public double MinValue         {             get => (double)GetValue(MinValueProperty);             set => SetValue(MinValueProperty, value);         }         public double CurrentValue         {             get => (double)GetValue(CurrentValueProperty);             set             {                 SetValue(CurrentValueProperty, value);                 PaintPath();             }         }         public double Interval         {             get => (double)GetValue(IntervalProperty);             set => SetValue(IntervalProperty, value);         }         public Geometry CurrentGeometry         {             get => (Geometry)GetValue(CurrentGeometryProperty);             set => SetValue(CurrentGeometryProperty, value);         }         private static void OnCurrentValueChanged(DependencyObject d, DependencyPropertyChangedEventArgs e)         {             var thermometer = d as Thermometer;             thermometer.CurrentValue = Convert.ToDouble(e.NewValue);         }         public override void OnApplyTemplate()         {             base.OnApplyTemplate();             PaintPath();         }         protected override void OnRender(DrawingContext drawingContext)         {             var brush = new SolidColorBrush((Color)ColorConverter.ConvertFromString("#82848A"));             var rect = new Rect();             rect.Width = 30;             rect.Height = 169;             drawingContext.DrawRoundedRectangle(Brushes.Transparent,                 new Pen(brush, 2d),                 rect, 8d, 8d);             #region 华氏温度             drawingContext.DrawText(                 DrawingContextHelper.GetFormattedText("华",                     (Brush)DrawingContextHelper.BrushConverter.ConvertFromString("#82848A"), textSize: 14D),                 new Point(-49, 115));             drawingContext.DrawText(                 DrawingContextHelper.GetFormattedText("氏",                     (Brush)DrawingContextHelper.BrushConverter.ConvertFromString("#82848A"), textSize: 14D),                 new Point(-49, 115 + 14));             drawingContext.DrawText(                 DrawingContextHelper.GetFormattedText("温",                     (Brush)DrawingContextHelper.BrushConverter.ConvertFromString("#82848A"), textSize: 14D),                 new Point(-49, 115 + 28));             drawingContext.DrawText(                 DrawingContextHelper.GetFormattedText("度",                     (Brush)DrawingContextHelper.BrushConverter.ConvertFromString("#82848A"), textSize: 14D),                 new Point(-49, 115 + 42));             #endregion             #region 摄氏温度             drawingContext.DrawText(                 DrawingContextHelper.GetFormattedText("摄",                     (Brush)DrawingContextHelper.BrushConverter.ConvertFromString("#82848A"), FlowDirection.LeftToRight,                     14D), new Point(75, 115));             drawingContext.DrawText(                 DrawingContextHelper.GetFormattedText("氏",                     (Brush)DrawingContextHelper.BrushConverter.ConvertFromString("#82848A"), FlowDirection.LeftToRight,                     14D), new Point(75, 115 + 14));             drawingContext.DrawText(                 DrawingContextHelper.GetFormattedText("温",                     (Brush)DrawingContextHelper.BrushConverter.ConvertFromString("#82848A"), FlowDirection.LeftToRight,                     14D), new Point(75, 115 + 28));             drawingContext.DrawText(                 DrawingContextHelper.GetFormattedText("度",                     (Brush)DrawingContextHelper.BrushConverter.ConvertFromString("#82848A"), FlowDirection.LeftToRight,                     14D), new Point(75, 115 + 42));             #endregion             #region 画刻度             var total_Value = MaxValue - MinValue;             var cnt = total_Value / Interval;             var one_value = 161d / cnt;             for (var i = 0; i <= cnt; i++)             {                 var formattedText = DrawingContextHelper.GetFormattedText($"{MaxValue - i * Interval}",                     (Brush)DrawingContextHelper.BrushConverter.ConvertFromString("#82848A"), FlowDirection.LeftToRight,                     14D);                 drawingContext.DrawText(formattedText,                     new Point(43, i * one_value - formattedText.Height / 2d)); //减去字体高度的一半                 formattedText = DrawingContextHelper.GetFormattedText($"{(MaxValue - i * Interval) * 1.8d + 32d}",                     (Brush)DrawingContextHelper.BrushConverter.ConvertFromString("#82848A"), textSize: 14D);                 drawingContext.DrawText(formattedText, new Point(-13, i * one_value - formattedText.Height / 2d));                 if (i != 0 && i != 5)                 {                     drawingContext.DrawLine(new Pen(Brushes.Black, 1d),                         new Point(4, i * one_value), new Point(6, i * one_value));                     drawingContext.DrawLine(new Pen(Brushes.Black, 1d),                         new Point(24, i * one_value), new Point(26, i * one_value));                 }             }             #endregion         }         /// <summary>         ///     动态计算当前值图形坐标点         /// </summary>         private void PaintPath()         {             var one_value = 161d / ((MaxValue - MinValue) / Interval);             var width = 26d;             var height = 169d - (MaxValue - CurrentValue) * (one_value / Interval);             var x = 2d;             var y = 169d - (169d - (MaxValue - CurrentValue) * (one_value / Interval));             CurrentGeometry = Geometry.Parse($@"M 2 {y + 4}                               a 4 4 0 0 1 4 -4                               h {width - 8}                               a 4 4 0 0 1 4 4                               v {height - 8}                               a 4 4 0 0 1 -4 4                               h -{width - 8}                               a 4 4 0 0 1 -4 -4 z");         }     } }

2） 使用ThermometerExample.xaml.cs如下：

<UserControl x:Class="WPFDevelopers.Samples.ExampleViews.ThermometerExample"              xmlns="schemas.microsoft.com/winfx/2006/xaml/presentation"              xmlns:x="schemas.microsoft.com/winfx/2006/xaml"              xmlns:mc="schemas.openxmlformats.org/markup-compatibility/2006"               xmlns:d="schemas.microsoft.com/expression/blend/2008"               xmlns:wpfdev="github.com/WPFDevelopersOrg/WPFDevelopers"              xmlns:local="clr-namespace:WPFDevelopers.Samples.ExampleViews"              mc:Ignorable="d"               d:DesignHeight="450" d:DesignWidth="800">     <Grid>         <Border Background="{DynamicResource BackgroundSolidColorBrush}"                  CornerRadius="12"                 Width="400" Height="400"                 Effect="{StaticResource NormalShadowDepth}">             <Grid>                 <Grid.ColumnDefinitions>                     <ColumnDefinition/>                     <ColumnDefinition/>                 </Grid.ColumnDefinitions>                 <Slider x:Name="PART_Slider" IsSnapToTickEnabled="True"                 Value="10"                 Minimum="-10"                 Maximum="40"                  Orientation="Vertical"                 Height="300"/>                 <Grid VerticalAlignment="Center"                       Margin="160,0,0,0">                     <Path Fill="{StaticResource PrimaryMouseOverSolidColorBrush}"                            Stroke="{StaticResource PrimaryMouseOverSolidColorBrush}"                           StrokeThickness="1" Opacity=".6"                           Data="{Binding ElementName=PART_Thermometer, Path=CurrentGeometry,Mode=TwoWay}"/>                     <wpfdev:Thermometer x:Name="PART_Thermometer"                                         CurrentValue="{Binding ElementName=PART_Slider,Path=Value,Mode=TwoWay}"/>                 </Grid>                 <TextBlock Text="{Binding ElementName=PART_Thermometer,Path=CurrentValue,StringFormat={}{0}℃}"                             FontSize="24" Grid.Column="1"                            Foreground="{StaticResource PrimaryPressedSolidColorBrush}" FontFamily="Bahnschrift"                            HorizontalAlignment="Center" VerticalAlignment="Center"/>             </Grid>         </Border>     </Grid> </UserControl>

实现效果
