本文实例为大家分享了Unity Shader实现水波纹的具体代码，供大家参考，具体内容如下

效果：

Shader代码：

Shader "Custom/shuibowen"{ Properties{ _MainTex("Base (RGB)",2D)="white"{} _distanceFactor("Distancefactor",float)=1 _timeFactor("time factor",float)=2 _totalFactor("total factor",float)=3 _waveWidth("wave width",float)=4 _curWaveDis("curwave dis",float)=5 _startPos("star pos",Vector) = (1,1,1,1) _MainTex_TexelSize("Maintex_texelSize",vector)=(1,1,1,1) } CGINCLUDE #include "UnityCG.cginc" uniform sampler2D _MainTex; float4 _MainTex_TexelSize; uniform float _distanceFactor; uniform float _timeFactor; uniform float _totalFactor; uniform float _waveWidth; uniform float _curWaveDis; uniform float4 _startPos; fixed4 frag(v2f_img i) : SV_Target { //DX下纹理坐标反向问题 #if UNITY_UV_STARTS_AT_TOP if (_MainTex_TexelSize.y < 0) _startPos.y = 1 - _startPos.y; #endif //计算uv到中间点的向量(向外扩，反过来就是向里缩) float2 dv = _startPos.xy - i.uv; //按照屏幕长宽比进行缩放 dv = dv * float2(_ScreenParams.x / _ScreenParams.y, 1); //计算像素点距中点的距离 float dis = sqrt(dv.x * dv.x + dv.y * dv.y); //用sin函数计算出波形的偏移值factor //dis在这里都是小于1的，所以我们需要乘以一个比较大的数，比如60，这样就有多个波峰波谷 //sin函数是（-1，1）的值域，我们希望偏移值很小，所以这里我们缩小100倍，据说乘法比较快,so... float sinFactor = sin(dis * _distanceFactor + _Time.y * _timeFactor) * _totalFactor * 0.01; //距离当前波纹运动点的距离，如果小于waveWidth才予以保留，否则已经出了波纹范围，factor通过clamp设置为0 float discardFactor = clamp(_waveWidth - abs(_curWaveDis - dis), 0, 1) / _waveWidth; //归一化 float2 dv1 = normalize(dv); //计算每个像素uv的偏移值 float2 offset = dv1 * sinFactor * discardFactor; //像素采样时偏移offset float2 uv = offset + i.uv; return tex2D(_MainTex, uv); } ENDCG SubShader { Pass { ZTest Always Cull Off ZWrite Off Fog { Mode off } CGPROGRAM #pragma vertex vert_img #pragma fragment frag #pragma fragmentoption ARB_precision_hint_fastest ENDCG } } Fallback off }

C#代码：

using System.Collections; using System.Collections.Generic; using UnityEngine; public class WaterWaveEffect : PostEffectsBase { //距离系数 public float distanceFactor = 60.0f; //时间系数 public float timeFactor = -30.0f; //sin函数结果系数 public float totalFactor = 1.0f; //波纹宽度 public float waveWidth = 0.3f; //波纹扩散的速度 public float waveSpeed = 0.3f; private float waveStartTime; private Vector4 startPos = new Vector4(0.5f, 0.5f, 0, 0); public Material _Material; void OnRenderImage(RenderTexture source, RenderTexture destination) { //计算波纹移动的距离，根据enable到目前的时间*速度求解 float curWaveDistance = (Time.time - waveStartTime) * waveSpeed; //设置一系列参数 _Material.SetFloat("_distanceFactor", distanceFactor); _Material.SetFloat("_timeFactor", timeFactor); _Material.SetFloat("_totalFactor", totalFactor); _Material.SetFloat("_waveWidth", waveWidth); _Material.SetFloat("_curWaveDis", curWaveDistance); _Material.SetVector("_startPos", startPos); Graphics.Blit(source, destination, _Material); } void Update() { if (Input.GetMouseButton(0)) { Vector2 mousePos = Input.mousePosition; //将mousePos转化为（0，1）区间 startPos = new Vector4(mousePos.x / Screen.width, mousePos.y / Screen.height, 0, 0); waveStartTime = Time.time; } } }

新建一个材质球，选择此shader，并赋值给这个脚本，点击屏幕即可看到效果
