# -*- coding: utf-8 -*-
"""Excercise 9.4"""
import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
import sys
import random
data = pd.read_csv(filepath_or_buffer = '../dataset/watermelon4.0.csv', sep = ',')[["密度","含糖率"]].values
########################################## K-means #######################################
k = int(sys.argv[1])
#Randomly choose k samples from data as mean vectors
mean_vectors = random.sample(data,k)
def dist(p1,p2):
return np.sqrt(sum((p1-p2)*(p1-p2)))
while True:
print mean_vectors
clusters = map ((lambda x:[x]), mean_vectors)
for sample in data:
distances = map((lambda m: dist(sample,m)), mean_vectors)
min_index = distances.index(min(distances))
clusters[min_index].append(sample)
new_mean_vectors = []
for c,v in zip(clusters,mean_vectors):
new_mean_vector = sum(c)/len(c)
#If the difference betweenthe new mean vector and the old mean vector is less than 0.0001
#then do not updata the mean vector
if all(np.divide((new_mean_vector-v),v) < np.array([0.0001,0.0001]) ):
new_mean_vectors.append(v)
else:
new_mean_vectors.append(new_mean_vector)
if np.array_equal(mean_vectors,new_mean_vectors):
break
else:
mean_vectors = new_mean_vectors
#Show the clustering result
total_colors = ['r','y','g','b','c','m','k']
colors = random.sample(total_colors,k)
for cluster,color in zip(clusters,colors):
density = map(lambda arr:arr[0],cluster)
sugar_content = map(lambda arr:arr[1],cluster)
plt.scatter(density,sugar_content,c = color)
plt.show()
