如何用Unity手机摄像机实现二维码识别功能？

本文共计801个文字，预计阅读时间需要4分钟。

Unity中实现手机调用摄像头拍照，识别二维码，并显示二维码内容的简单示例：

首先，导入zxing.unity.dll文件到项目中。

以下是一个简化的脚本示例，用于调用手机摄像头拍照，识别二维码，并显示二维码内容：

csharpusing UnityEngine;using ZXing;using ZXing.QrCode;using ZXing.Common;using UnityEngine.UI;

public class QRCodeScanner : MonoBehaviour{ private WebCamTexture webcamTexture; private Texture2D cameraTexture; private QRCodeReader qrCodeReader; public RawImage qrCodeImage;

void Start() { // 初始化二维码读取器 qrCodeReader=new QRCodeReader();

// 初始化摄像头 webcamTexture=new WebCamTexture(); webcamTexture.requestedWidth=Screen.width; webcamTexture.requestedHeight=Screen.height; webcamTexture.Play();

// 创建Texture2D用于显示摄像头预览 cameraTexture=new Texture2D(webcamTexture.width, webcamTexture.height); qrCodeImage.texture=cameraTexture;

// 开启一个线程，用于处理摄像头数据 StartCoroutine(ScanQRCode()); }

IEnumerator ScanQRCode() { while (true) { // 从摄像头获取图像 yield return new WaitForEndOfFrame(); cameraTexture.SetPixels(webcamTexture.GetPixels(), 0);

// 将Texture2D转换为码流 byte[] pixels=cameraTexture.GetPixels32().ToArray(); LuminanceSource source=new LuminanceSource(pixels, cameraTexture.width, cameraTexture.height, true); BinaryBitmap bitmap=new BinaryBitmap(source);

// 识别二维码 Result result=qrCodeReader.Decode(bitmap);

if (result !=null) { // 显示二维码内容 qrCodeImage.color=Color.white; qrCodeImage.texture=cameraTexture; Debug.Log(QR Code Content: + result.Text); } else { // 清除显示 qrCodeImage.color=new Color(0, 0, 0, 0); } } }

void OnDestroy() { // 停止摄像头 if (webcamTexture !=null) { webcamTexture.Stop(); } }}

此脚本需要在Unity项目中使用，并确保已经正确导入zxing.unity.dll文件。脚本将启动摄像头，并在摄像头预览中显示二维码内容。当识别到二维码时，会在控制台中输出二维码的内容。

本文实现Unity调用手机摄像，拍摄，然后识别二维码，显示二维码的内容。

需要导入一个zxing.unity.dll文件,现在这个脚本的识别数据是放在Updata里边扫描的 数据量特别大会卡 要是用的话就自己做一下一秒执行一次。我这里没有弄

下载地址：zxing.unity.dll

代码：

using System.Threading; using UnityEngine; using ZXing; public class WebCameraScript : MonoBehaviour { public string LastResult; public string Lastresult; public Color32[] data; private bool isQuit; public GUITexture myCameraTexture; private WebCamTexture webCameraTexture; private void Start() { // bool success = CameraDevice.Instance.SetFocusMode(CameraDevice.FocusMode.FOCUS_MODE_CONTINUOUSAUTO); // Checks how many and which cameras are available on the device for (int cameraIndex = 0; cameraIndex < WebCamTexture.devices.Length; cameraIndex++) { // We want the back camera if (!WebCamTexture.devices[cameraIndex].isFrontFacing) { //webCameraTexture = new WebCamTexture(cameraIndex, Screen.width, Screen.height); webCameraTexture = new WebCamTexture(cameraIndex, 200, 200); // Here we flip the GuiTexture by applying a localScale transformation // works only in Landscape mode myCameraTexture.transform.localScale = new Vector3(1, 1, 1); } } // Here we tell that the texture of coming from the camera should be applied // to our GUITexture. As we have flipped it before the camera preview will have the // correct orientation myCameraTexture.texture = webCameraTexture; // Starts the camera webCameraTexture.Play(); //enabled=WebCamTexture.s } public void ShowCamera() { myCameraTexture.guiTexture.enabled = true; webCameraTexture.Play(); } public void HideCamera() { myCameraTexture.guiTexture.enabled = false; webCameraTexture.Stop(); } private void OnGUI() { GUI.Label(new Rect(60, 30*1, Screen.width, 20), "LastResult:" + LastResult); if (GUI.Button(new Rect(0, 0, 100, 100), "ON/OFF")) { if (webCameraTexture.isPlaying) HideCamera(); else ShowCamera(); } } private void Update() { //data = new Color32[webCameraTexture.width * webCameraTexture.height]; data = webCameraTexture.GetPixels32(); DecodeQR(webCameraTexture.width, webCameraTexture.height); } private void DecodeQR(int W, int H) { if (isQuit) return; // create a reader with a custom luminance source var barcodeReader = new BarcodeReader {AutoRotate = true, TryHarder = true}; // while (true) { try { // decode the current frame Result result = barcodeReader.Decode(data, W, H); if (result != null) { LastResult = result.Text; // shouldEncodeNow = true; print("i read out::" + result.Text); } // Sleep a little bit and set the signal to get the next frame Thread.Sleep(200); data = null; } catch { } } } }
