WPF 使用 DrawingContext 绘制刻度条

• 框架使用大于等于.NET40；
• Visual Studio 2022;
• 项目使用MIT开源许可协议；
• 定义Interval步长、SpanInterval间隔步长、MiddleMask中间步长。
• 当步长/间隔步长=需要绘制的小刻度。
• 循环绘制小刻度，判断当前j并取中间步长的模，如果模！=零就绘制中高线。
• 从StartValue开始绘制刻度到EndValue结束刻度。
• CurrentGeometry重新绘制当前刻度的Path值。
• CurrentValue当前值如果发生变化时则去重新CurrentGeometry。

1） 准备Ruler.cs如下：

using System; using System.Windows; using System.Windows.Controls; using System.Windows.Media; namespace WPFDevelopers.Controls {     public class Ruler : Control     {         public static readonly DependencyProperty IntervalProperty =             DependencyProperty.Register("Interval", typeof(double), typeof(Ruler), new UIPropertyMetadata(30.0));         public static readonly DependencyProperty SpanIntervalProperty =             DependencyProperty.Register("SpanInterval", typeof(double), typeof(Ruler), new UIPropertyMetadata(5.0));         public static readonly DependencyProperty MiddleMaskProperty =             DependencyProperty.Register("MiddleMask", typeof(int), typeof(Ruler), new UIPropertyMetadata(2));         public static readonly DependencyProperty CurrentValueProperty =             DependencyProperty.Register("CurrentValue", typeof(double), typeof(Ruler),                 new UIPropertyMetadata(OnCurrentValueChanged));         public static readonly DependencyProperty StartValueProperty =             DependencyProperty.Register("StartValue", typeof(double), typeof(Ruler), new UIPropertyMetadata(120.0));         public static readonly DependencyProperty EndValueProperty =             DependencyProperty.Register("EndValue", typeof(double), typeof(Ruler), new UIPropertyMetadata(240.0));         public static readonly DependencyProperty CurrentGeometryProperty =             DependencyProperty.Register("CurrentGeometry", typeof(Geometry), typeof(Ruler),                 new PropertyMetadata(Geometry.Parse("M 257,0 257,25 264,49 250,49 257,25")));         static Ruler()         {             DefaultStyleKeyProperty.OverrideMetadata(typeof(Ruler), new FrameworkPropertyMetadata(typeof(Ruler)));         }         public Ruler()         {             Loaded += Ruler_Loaded;         }         public double Interval         {             get => (double)GetValue(IntervalProperty);             set => SetValue(IntervalProperty, value);         }         public double SpanInterval         {             get => (double)GetValue(SpanIntervalProperty);             set => SetValue(SpanIntervalProperty, value);         }         public int MiddleMask         {             get => (int)GetValue(MiddleMaskProperty);             set => SetValue(MiddleMaskProperty, value);         }         public double CurrentValue         {             get => (double)GetValue(CurrentValueProperty);             set             {                 SetValue(CurrentValueProperty, value);                 PaintPath();             }         }         public double StartValue         {             get => (double)GetValue(StartValueProperty);             set => SetValue(StartValueProperty, value);         }         public double EndValue         {             get => (double)GetValue(EndValueProperty);             set => SetValue(EndValueProperty, value);         }         public Geometry CurrentGeometry         {             get => (Geometry)GetValue(CurrentGeometryProperty);             set => SetValue(CurrentGeometryProperty, value);         }         private static void OnCurrentValueChanged(DependencyObject d, DependencyPropertyChangedEventArgs e)         {             var ruler = d as Ruler;             ruler.CurrentValue = Convert.ToDouble(e.NewValue);         }         protected override void OnRender(DrawingContext drawingContext)         {             RenderOptions.SetEdgeMode(this, EdgeMode.Aliased);             var nextLineValue = 0d;             var one_Width = ActualWidth / ((EndValue - StartValue) / Interval);             for (var i = 0; i <= (EndValue - StartValue) / Interval; i++)             {                 var numberText = DrawingContextHelper.GetFormattedText((StartValue + i * Interval).ToString(),                     (Brush)DrawingContextHelper.BrushConverter.ConvertFromString("#FFFFFF"), FlowDirection.LeftToRight,                     10);                 drawingContext.DrawText(numberText, new Point(i * one_Width - 8, 0));                 drawingContext.DrawLine(new Pen(new SolidColorBrush(Colors.White), 1), new Point(i * one_Width, 25),                     new Point(i * one_Width, ActualHeight - 2));                 var cnt = Interval / SpanInterval;                 for (var j = 1; j <= cnt; j++)                     if (j % MiddleMask == 0)                         drawingContext.DrawLine(new Pen(new SolidColorBrush(Colors.White), 1),                             new Point(j * (one_Width / cnt) + nextLineValue, ActualHeight - 2),                             new Point(j * (one_Width / cnt) + nextLineValue, ActualHeight - 10));                     else                         drawingContext.DrawLine(new Pen(new SolidColorBrush(Colors.White), 1),                             new Point(j * (one_Width / cnt) + nextLineValue, ActualHeight - 2),                             new Point(j * (one_Width / cnt) + nextLineValue, ActualHeight - 5));                 nextLineValue = i * one_Width;             }         }         private void Ruler_Loaded(object sender, RoutedEventArgs e)         {             PaintPath();         }         private void PaintPath()         {             var d_Value = CurrentValue - StartValue;             var one_Value = ActualWidth / (EndValue - StartValue);             var x_Point = one_Value * d_Value + ((double)Parent.GetValue(ActualWidthProperty) - ActualWidth) / 2d;             CurrentGeometry =                 Geometry.Parse($"M {x_Point},0 {x_Point},25 {x_Point + 7},49 {x_Point - 7},49 {x_Point},25");         }     } }

2） 使用RulerControlExample.xaml.cs如下：

<UserControl x:Class="WPFDevelopers.Samples.ExampleViews.RulerControlExample"              xmlns="schemas.microsoft.com/winfx/2006/xaml/presentation"              xmlns:x="schemas.microsoft.com/winfx/2006/xaml"              xmlns:mc="schemas.openxmlformats.org/markup-compatibility/2006"               xmlns:d="schemas.microsoft.com/expression/blend/2008"               xmlns:local="clr-namespace:WPFDevelopers.Samples.ExampleViews"              xmlns:wpfdev="github.com/WPFDevelopersOrg/WPFDevelopers"              mc:Ignorable="d"               d:DesignHeight="450" d:DesignWidth="800">     <Grid>         <Slider x:Name="PART_Slider" IsSnapToTickEnabled="True"                 Value="40"                 Minimum="10"                 Maximum="210"/>         <UniformGrid Rows="3">             <Grid Background="{StaticResource CircularDualSolidColorBrush}" Height="51" Margin="40,0">                 <Path Stroke="{StaticResource SuccessPressedSolidColorBrush}" StrokeThickness="1" Fill="{StaticResource SuccessPressedSolidColorBrush}"                   Data="{Binding ElementName=PART_Ruler, Path=CurrentGeometry,Mode=TwoWay}" />                 <wpfdev:Ruler x:Name="PART_Ruler" Margin="40,0" Interval="20" StartValue="10" EndValue="210"                           CurrentValue="{Binding ElementName=PART_Slider,Path=Value,Mode=TwoWay}"/>             </Grid>             <Grid Background="{StaticResource DangerPressedSolidColorBrush}" Height="51" Margin="40,0">                 <Path Stroke="{StaticResource SuccessPressedSolidColorBrush}" StrokeThickness="1" Fill="{StaticResource SuccessPressedSolidColorBrush}"                   Data="{Binding ElementName=PART_Ruler1, Path=CurrentGeometry,Mode=TwoWay}" />                 <wpfdev:Ruler x:Name="PART_Ruler1" Margin="40,0" Interval="20" StartValue="10" EndValue="210"                           CurrentValue="{Binding ElementName=PART_Slider,Path=Value,Mode=TwoWay}"/>             </Grid>             <Grid Background="{StaticResource WarningPressedSolidColorBrush}" Height="51" Margin="40,0">                 <Path Stroke="{StaticResource SuccessPressedSolidColorBrush}" StrokeThickness="1" Fill="{StaticResource SuccessPressedSolidColorBrush}"                   Data="{Binding ElementName=PART_Ruler2, Path=CurrentGeometry,Mode=TwoWay}" />                 <wpfdev:Ruler x:Name="PART_Ruler2" Margin="40,0" Interval="20" StartValue="10" EndValue="210"                           CurrentValue="{Binding ElementName=PART_Slider,Path=Value,Mode=TwoWay}"/>             </Grid>         </UniformGrid>                       </Grid> </UserControl>

以上就是WPF使用DrawingContext实现绘制刻度条的详细内容，更多关于WPF刻度条的资料请关注自由互联其它相关文章！
