SSM框架如何与Thymeleaf模板引擎实现集成？

• 创建项目
• Spring+SpringMVC+MyBatis的配置文件
• 数据库内容
• dao层+service层+controller层
• 映射文件
• 前端简单页面
• 配置tomcat，运行显示
• 总体项目架构
• 补充

目前很多后端技术栈采用Spring+SpringMVC+MyBatis的项目,其模板引擎大多使用JSP。基于现在前后端分离趋势，我们使用Thymeleaf这个模板引擎和SSM框架配合。但是Thymeleaf不算是真正意义上的前后端分离。

1. 创建一个maven项目，在例子中，我们创建一个名为SSMAndThymeleaf的项目。

2. 引入全部依赖

   <?xmlversion="1.0"encoding="UTF-8"?>
<projectxmlns="maven.apache.org/POM/4.0.0"
xmlns:xsi="www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="maven.apache.org/POM/4.0.0maven.apache.org/xsd/maven-4.0.0.xsd">
<modelVersion>4.0.0</modelVersion>
<groupId>com.wang</groupId>
<artifactId>SSMAndThymeleaf</artifactId>
<version>1.0-SNAPSHOT</version>
<properties>
<maven.compiler.source>8</maven.compiler.source>
<maven.compiler.target>8</maven.compiler.target>
</properties>
<dependencies>
<!--导入spring,下面几个为spring和springmvc需要的依赖-->
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-context</artifactId>
<version>5.1.9.RELEASE</version>
</dependency>
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-jdbc</artifactId>
<version>5.1.9.RELEASE</version>
</dependency>
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-aop</artifactId>
<version>5.1.9.RELEASE</version>
</dependency>
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-core</artifactId>
<version>5.1.9.RELEASE</version>
</dependency>
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-tx</artifactId>
<version>5.1.9.RELEASE</version>
</dependency>
<dependency>
<groupId>org.aspectj</groupId>
<artifactId>aspectjweaver</artifactId>
<version>1.9.4</version>
</dependency>
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-beans</artifactId>
<version>5.1.9.RELEASE</version>
</dependency>
<!--导入springmvc-->
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-web</artifactId>
<version>5.1.9.RELEASE</version>
</dependency>
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-webmvc</artifactId>
<version>5.1.9.RELEASE</version>
</dependency>

<!--导入mybatis-->
<dependency>
<groupId>org.mybatis</groupId>
<artifactId>mybatis-spring</artifactId>
<version>1.3.2</version>
</dependency>
<dependency>
<groupId>org.mybatis</groupId>
<artifactId>mybatis</artifactId>
<version>3.5.2</version>
</dependency>
<!--mysql数据库的依赖-->
<dependency>
<groupId>mysql</groupId>
<artifactId>mysql-connector-java</artifactId>
<version>8.0.17</version>
</dependency>
<!--例子中使用的数据库连接池是C3P0,当然，你也可以选择Druid数据库连接池-->
<dependency>
<groupId>com.mchange</groupId>
<artifactId>c3p0</artifactId>
<version>0.9.5.2</version>
</dependency>

<!--导入Thymeleaf模板引擎-->
<dependency>
<groupId>org.thymeleaf</groupId>
<artifactId>thymeleaf-spring5</artifactId>
<version>3.0.9.RELEASE</version>
</dependency>
<!--servletapi-->
<dependency>
<groupId>javax.servlet</groupId>
<artifactId>javax.servlet-api</artifactId>
<version>4.0.0</version>
<scope>provided</scope>
</dependency>
<dependency>
<groupId>org.thymeleaf</groupId>
<artifactId>thymeleaf</artifactId>
<version>3.0.11.RELEASE</version>
</dependency>

<!--导入jackson注解-->
<dependency>
<groupId>com.fasterxml.jackson.core</groupId>
<artifactId>jackson-core</artifactId>
<version>2.9.8</version>
</dependency>
<dependency>
<groupId>com.fasterxml.jackson.core</groupId>
<artifactId>jackson-databind</artifactId>
<version>2.9.8</version>
</dependency>
<dependency>
<groupId>com.fasterxml.jackson.core</groupId>
<artifactId>jackson-annotations</artifactId>
<version>2.9.8</version>
</dependency>
</dependencies>
</project>


3. 为项目添加web框架支持。

1. Spring的配置文件

   主要是扫描数据持久层和业务层，然后数据库的相关配置。

   <?xmlversion="1.0"encoding="utf-8"?>

<beansxmlns="www.springframework.org/schema/beans"
xmlns:xsi="www.w3.org/2001/XMLSchema-instance"
xmlns:context="www.springframework.org/schema/context"
xmlns:aop="www.springframework.org/schema/aop"
xmlns:tx="www.springframework.org/schema/tx"
xsi:schemaLocation="www.springframework.org/schema/beans
www.springframework.org/schema/beans/spring-beans.xsd
www.springframework.org/schema/context
www.springframework.org/schema/context/spring-context.xsd
www.springframework.org/schema/aop
www.springframework.org/schema/aop/spring-aop.xsd
www.springframework.org/schema/tx
www.springframework.org/schema/tx/spring-tx.xsd">

<!--扫描dao层-->
<context:component-scanbase-package="com.wang.dao"/>
<context:component-scanbase-package="com.wang.service"/>

<!--加载properties文件,这里的properties文件是数据源配置需要的内容-->
<context:property-placeholderlocation="classpath:properties/db.properties"/>

<!--配置数据源-->
<beanid="dataSource"class="com.mchange.v2.c3p0.ComboPooledDataSource">
<propertyname="driverClass"value="${jdbc.driver}"/>
<propertyname="jdbcUrl"value="${jdbc.url}"/>
<propertyname="user"value="${jdbc.username}"/>
<propertyname="password"value="${jdbc.password}"/>
<!--初始连接池大小-->
<propertyname="initialPoolSize"value="10"/>
<!--连接池中连接最小个数-->
<propertyname="minPoolSize"value="5"/>
<propertyname="maxPoolSize"value="20"/>
</bean>

<!--配置SqlSession工厂对象,MyBatis配置SqlSessionFactory,Spring中将它封装成了一个Bean-->
<beanid="sqlSessionFactory"class="org.mybatis.spring.SqlSessionFactoryBean">
<propertyname="dataSource"ref="dataSource"/>
<!--MyBatis配置文件的位置-->
<propertyname="configLocation"value="classpath:mybatis/mybatis-SqlMapConfig.xml"/>
<!--MyBatis映射文件的位置-->
<propertyname="mapperLocations"value="classpath*:mapper/*Dao.xml"/>
</bean>

<!--加载dao的接口对象,这一配置是为了让他能通过反射创建mapper对象-->
<beanid="mapperScannerConfigurer"class="org.mybatis.spring.mapper.MapperScannerConfigurer">
<propertyname="basePackage"value="com.wang.dao"/>
<propertyname="sqlSessionFactoryBeanName"value="sqlSessionFactory"/>
</bean>
</beans>


2. SpringMVC的配置文件

   <?xmlversion="1.0"encoding="UTF-8"?>
<beansxmlns="www.springframework.org/schema/beans"
xmlns:mvc="www.springframework.org/schema/mvc"
xmlns:xsi="www.w3.org/2001/XMLSchema-instance"
xmlns:context="www.springframework.org/schema/context"
xsi:schemaLocation="www.springframework.org/schema/beans
www.springframework.org/schema/beans/spring-beans.xsd
www.springframework.org/schema/mvc
www.springframework.org/schema/mvc/spring-mvc.xsdwww.springframework.org/schema/contextwww.springframework.org/schema/context/spring-context.xsd">

<!--扫描controller层注解-->
<context:component-scanbase-package="com.wang"/>

<!--配置模板引擎-->
<beanid="springResourceTemplateResolver"class="org.thymeleaf.spring5.templateresolver.SpringResourceTemplateResolver">
<propertyname="prefix"value="/WEB-INF/templates/"/>
<propertyname="suffix"value=".html"/>
<!--解决页面的中文乱码-->
<propertyname="characterEncoding"value="UTF-8"/>
<propertyname="order"value="1"/>
<propertyname="templateMode"value="HTML5"/>
<propertyname="cacheable"value="false"/>
</bean>
<beanid="springTemplateEngine"class="org.thymeleaf.spring5.SpringTemplateEngine">
<propertyname="templateResolver"ref="springResourceTemplateResolver"/>
</bean>

<!--配置thymeleaf视图解析器-->
<beanid="thymeleafViewResolver"class="org.thymeleaf.spring5.view.ThymeleafViewResolver">
<propertyname="templateEngine"ref="springTemplateEngine"/>
<propertyname="characterEncoding"value="UTF-8"/>
</bean>

<!--开启注解驱动-->
<mvc:annotation-driven/>
</beans>


3. MyBatis的配置文件

   其实MyBatis的配置在Spring中都已经配置完，即使我们使用事务，也是使用Spring的事务处理，所以这里只需要配置一点点东西。

   <?xmlversion="1.0"encoding="UTF-8"?>
<!DOCTYPEconfiguration
PUBLIC"-//mybatis.org//DTDConfig3.0//EN"
"mybatis.org/dtd/mybatis-3-config.dtd">
<configuration>
<!--扫描pojo对象,起个别名-->
<typeAliases>
<packagename="com.wang.model"/>
</typeAliases>
</configuration>


1. 创建一个实体类(Country)

   packagecom.wang.model;

/**
*@authorwya
*@version1.0
*@schoolhhu
*@date2022/3/2119:10
*/
publicclassCountry{
privateIntegerid;

privateStringcountryName;

privateStringcountryCode;

publicIntegergetId(){
returnid;
}

publicvoidsetId(Integerid){
this.id=id;
}

publicStringgetCountryName(){
returncountryName;
}

publicvoidsetCountryName(StringcountryName){
this.countryName=countryName;
}

publicStringgetCountryCode(){
returncountryCode;
}

publicvoidsetCountryCode(StringcountryCode){
this.countryCode=countryCode;
}

}


2. 创建dao接口

   importcom.wang.model.Country;
importorg.apache.ibatis.annotations.Param;
importorg.springframework.stereotype.Repository;

/**
*@authorwya
*@version1.0
*@schoolhhu
*@date2022/3/2119:11
*/
@Repository
publicinterfaceCountryDao{

CountryselectACountry(@Param("countryId")intid);

}


3. 创建service接口

   packagecom.wang.service;

importcom.wang.model.Country;

/**
*@authorwya
*@version1.0
*@schoolhhu
*@date2022/3/2119:11
*/
publicinterfaceCountryService{

CountrygetCountryById(intid);

}


4. 实现service接口

   packagecom.wang.service.impl;

importcom.wang.dao.CountryDao;
importcom.wang.model.Country;
importcom.wang.service.CountryService;
importorg.springframework.beans.factory.annotation.Autowired;
importorg.springframework.stereotype.Service;

/**
*@authorwya
*@version1.0
*@schoolhhu
*@date2022/3/2119:11
*/
@Service
publicclassCountryServiceImplimplementsCountryService{

@Autowired
CountryDaocountryDao;

@Override
publicCountrygetCountryById(intid){
/**
*这里是业务层的操作，我们这里省略
*/
returncountryDao.selectACountry(id);
}
}



5. 创建controller

   packagecom.wang.controller;

importcom.wang.model.Country;
importcom.wang.service.CountryService;
importorg.springframework.beans.factory.annotation.Autowired;
importorg.springframework.stereotype.Controller;
importorg.springframework.ui.Model;
importorg.springframework.web.bind.annotation.RequestMapping;

/**
*@authorwya
*@version1.0
*@schoolhhu
*@date2022/3/2119:09
*/
@Controller
publicclassCountryController{

@Autowired
CountryServicecountryService;

@RequestMapping("hello")
publicStringtest(Modelmodel){
Countrycountry=countryService.getCountryById(1);
model.addAttribute("country",country);
return"hello";
}

}


<?xmlversion="1.0"encoding="UTF8"?>
<!DOCTYPEmapper
PUBLIC"-//mybatis.org//DTDMapper3.0//EN"
"mybatis.org/dtd/mybatis-3-mapper.dtd">
<!--定义为当前的命名空间-->
<mappernamespace="com.wang.dao.CountryDao">
<selectid="selectACountry"resultType="com.wang.model.Country">
select*fromcountrywhereid=#{countryId};
</select>

</mapper>
前端简单页面

<!DOCTYPEhtml>
<htmllang="en"xmlns:th="www.thymeleaf.org">
<head>
<metacharset="UTF-8">
<title>Title</title>
</head>
<body>
<center><h1>显示成功!!!</h1>
国家名字:<pth:text="${country.countryName}"></p>
国家ID:<pth:text="${country.countryCode}"></p>
</body>
</html>
配置tomcat，运行显示 总体项目架构

后续需要其他依赖的再加入即可，像文件的上传下载依赖等。

有问题请联系我。
