如何搭建并测试MyBatis框架？

本文共计1641个文字，预计阅读时间需要7分钟。

1. 开发环境+新建工程-配置JDK版本-配置Maven

2.创建Maven工程+修改打包方式为jar+导入依赖：

...

1.开发环境 新建一个工程-配置jdk版本-配置maven 2.创建maven工程 修改打包方式为jar

导入依赖：

<?xml version="1.0" encoding="UTF-8"?> <project xmlns="maven.apache.org/POM/4.0.0" xmlns:xsi="www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="maven.apache.org/POM/4.0.0 maven.apache.org/xsd/maven-4.0.0.xsd"> <modelVersion>4.0.0</modelVersion> <groupId>com.tinstu.mybatis</groupId> <artifactId>MyBatis_demo1</artifactId> <version>1.0-SNAPSHOT</version> <packaging>jar</packaging> <dependencies> <!-- Mybatis核心 --> <dependency> <groupId>org.mybatis</groupId> <artifactId>mybatis</artifactId> <version>3.5.7</version> </dependency> <!-- junit测试 --> <dependency> <groupId>junit</groupId> <artifactId>junit</artifactId> <version>4.12</version> <scope>test</scope> </dependency> <!-- MySQL驱动 --> <dependency> <groupId>mysql</groupId> <artifactId>mysql-connector-java</artifactId> <version>5.1.3</version> </dependency> </dependencies> </project>

3.创建MyBatis的核心配置文件 mybatis-config.xml 在resources下创建mybatis-config.xml

<?xml version="1.0" encoding="UTF-8" ?> <!DOCTYPE configuration PUBLIC "-//mybatis.org//DTD Config 3.0//EN" "mybatis.org/dtd/mybatis-3-config.dtd"> <configuration> <!--设置连接数据库的环境--> <environments default="development"> <environment id="development"> <transactionManager type="JDBC"/> <dataSource type="POOLED"> <property name="driver" value="com.mysql.jdbc.Driver"/> <property name="url" value="jdbc:mysql://localhost:3306/MyBatis"/> <property name="username" value="root"/> <property name="password" value="123456"/> </dataSource> </environment> </environments> <!--引入映射文件--> <mappers> <mapper resource="mappers/UserMapper.xml"/> </mappers> </configuration> 4.创建mapper接口 UserMapper.java MyBatis中的mapper接口相当于以前的dao，但是区别于，mapper仅仅是接口，我们不需要提供实现类

先在 mybatis-config.xml中配置好数据库信息，创建一个数据库，创建实体类User.java

创建一个接口 UserMapper.java

package com.tinstu.mybatis.mapper; public interface UserMapper { //添加用户信息 int insertUser(); } 5.创建MyBatis的映射文件 UserMapper.xml MyBatis面向接口编程的两个一致

• 1.映射文件UserMapper.xml的 namespace和mapper接口UserMapper.java的全类名保持一致 <mapper namespace="com.tinstu.mybatis.mapper.UserMapper">
• 2.映射文件中sql语句的id要和mapper接口中的方法名一致 （此映射文件中事务id=insertUser和上面接口中的方法名insertUser一样）

表---实体类---mapper接口---映射文件

mapper接口的全类名和映射文件的命名空间（namespace）保持一致

• • mapper接口中方法的方法名和映射文件中编写SQL的标签的id属性保持一致

<?xml version="1.0" encoding="UTF-8" ?> <!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN" "mybatis.org/dtd/mybatis-3-mapper.dtd"> <mapper namespace="com.tinstu.mybatis.mapper.UserMapper"> <!--int insertUser();--> <insert id="insertUser"> insert into t_user values(null,'张三','123','123123@qq.com') </insert> </mapper> 最后还要在配置文件mybatis-config.xml中引入映射文件

<!--引入映射文件--> <mappers> <mapper resource="mappers/UserMapper.xml"/> </mappers> 6.测试添加功能 创建一个测试类

package com.tinstu.mybatis;

import com.tinstu.mybatis.mapper.UserMapper;
import org.apache.ibatis.io.Resources;
import org.apache.ibatis.session.SqlSession;
import org.apache.ibatis.session.SqlSessionFactory;
import org.apache.ibatis.session.SqlSessionFactoryBuilder;
import org.junit.Test;

import java.io.IOException;
import java.io.InputStream;

public class Mybatistest {
@Test
public void testmybatis() throws IOException{
//加载核心配置文件
InputStream is = Resources.getResourceAsStream("mybatis-config.xml");
//获取SqlSessionFactoryBuilder
SqlSessionFactoryBuilder sqlSessionFactoryBuilder = new SqlSessionFactoryBuilder();
//获取sqlSessionFactory
SqlSessionFactory sqlSessionFactory = sqlSessionFactoryBuilder.build(is);
//获取SqlSession
SqlSession sqlSession = sqlSessionFactory.openSession();
//获取mapper接口对象
UserMapper mapper = sqlSession.getMapper(UserMapper.class) ;
//测试功能
int result = mapper.insertUser();
//提交事务
sqlSession.commit();

}

}

7.优化功能 1.SqlSession默认不自动提交事务，如需要自动提交事务，可以使用SqlSessionFactory.openSession(true);

//获取SqlSession(加入true) SqlSession sqlSession = sqlSessionFactory.openSession(true); //获取mapper接口对象 UserMapper mapper = sqlSession.getMapper(UserMapper.class) ; //测试功能 int result = mapper.insertUser(); //提交事务（删掉） // sqlSession.commit(); 2.加入log4j日志功能 （1）加入依赖

<!-- log4j日志 --> <dependency> <groupId>log4j</groupId> <artifactId>log4j</artifactId> <version>1.2.17</version> </dependency>

（2）加入log4j的配置文件

• log4j的配置文件名为log4j.xml，存放的位置是src/main/resources目录下

• 日志的级别：FATAL(致命)>ERROR(错误)>WARN(警告)>INFO(信息)>DEBUG(调试) 从左到右打印的内容越来越详细

• <?xml version="1.0" encoding="UTF-8" ?> <!DOCTYPE log4j:configuration SYSTEM "log4j.dtd"> <log4j:configuration xmlns:log4j="jakarta.apache.org/log4j/"> <appender name="STDOUT" class="org.apache.log4j.ConsoleAppender"> <param name="Encoding" value="UTF-8" /> <layout class="org.apache.log4j.PatternLayout"> <param name="ConversionPattern" value="%-5p %d{MM-dd HH:mm:ss,SSS} %m (%F:%L) \n" /> </layout> </appender> <logger name="java.sql"> <level value="debug" /> </logger> <logger name="org.apache.ibatis"> <level value="info" /> </logger> <root> <level value="debug" /> <appender-ref ref="STDOUT" /> </root> </log4j:configuration>

8.测试删除修改功能 （1）修改

UserMapper.xml中加入

<!--void updateUser();--> <update id="updateUser"> update user set username = '张三55' where id = 3 ; </update>

测试类

@Test public void testuodate() throws IOException{ InputStream is = Resources.getResourceAsStream("mybatis-config.xml"); SqlSessionFactoryBuilder sqlSessionFactoryBuilder = new SqlSessionFactoryBuilder(); SqlSessionFactory sqlSessionFactory = sqlSessionFactoryBuilder.build(is); SqlSession sqlSession = sqlSessionFactory.openSession(true); UserMapper mapper = sqlSession.getMapper(UserMapper.class); mapper.updateUser(); }

删除：

<!--void deleteUser();--> <delete id="deleteUser"> delete from user where id = 5 </delete>

9.测试查询功能 （1）根据id查询

UserMapper.java中添加查询方法

//查询功能 User getUser();

UserMapper.xml中写sql语句

<!--void getUser();--> <!-- 查询功能的标签必须设置resultType或resultMap resultType：设置默认的映射关系 resultMap:设置自定义的映射关系 --> <select id="getUser" resultType="com.tinstu.mybatis.pojo.User"> select * from user where id=3 </select>

测试类：

@Test public void testuodate() throws IOException{ InputStream is = Resources.getResourceAsStream("mybatis-config.xml"); SqlSessionFactoryBuilder sqlSessionFactoryBuilder = new SqlSessionFactoryBuilder(); SqlSessionFactory sqlSessionFactory = sqlSessionFactoryBuilder.build(is); SqlSession sqlSession = sqlSessionFactory.openSession(true); UserMapper mapper = sqlSession.getMapper(UserMapper.class); User user = mapper.getUser(); System.out.println(user); }

（2）查询所有

UserMapper.java中添加查询方法

//查询所有 List<User> getUserAll();

UserMapper.xml中写sql语句

<!--List<User> getUserAll();--> <select id="getUserAll" resultType="com.tinstu.mybatis.pojo.User"> select * from user </select>

测试类：

@Test public void testuodate() throws IOException{ InputStream is = Resources.getResourceAsStream("mybatis-config.xml"); SqlSessionFactoryBuilder sqlSessionFactoryBuilder = new SqlSessionFactoryBuilder(); SqlSessionFactory sqlSessionFactory = sqlSessionFactoryBuilder.build(is); SqlSession sqlSession = sqlSessionFactory.openSession(true); UserMapper mapper = sqlSession.getMapper(UserMapper.class); List<User> userList = mapper.getUserAll(); System.out.println(userList); //lanmbda表达式 userList.forEach(user -> System.out.println(user)); }

我的java笔记：mybatis环境搭建及测试： www.tinstu.com/1218.html
