如何搭建015-管理后台框架的长尾布局？

本文共计3776个文字，预计阅读时间需要16分钟。

1. 功能分析 + 管理后台界面概览 + 包含左侧菜单栏、头部导航栏、Tab窗口、内容展示区域及页面脚本。+ 2. 基本实现 + 2.1 文件引入 + 2.2 页面引入 + 引入hplus下的index. + 2.3 页面内容 + 页面内容

1.功能分析

管理后台我们先看下大体页面布局如下

包含左侧菜单栏,头部导航栏，tab窗体,还有内容显示区域,以及页脚.

2.基本实现

2.1. 文件引入

2.2. 页面引入

引入hplus下的index.html

2.3. 页面调整

我们需要对css,js等做调整,可以使用thymeleaf方式引入

<!-- css相关调整 --> <link rel="shortcut icon" href="favicon.ico"> <link href="../../static/lib/bootstrap/css/bootstrap.min.css" th:href="@{/lib/bootstrap/css/bootstrap.min.css}" rel="stylesheet"> <link href="../../static/lib/font-awesome/css/font-awesome.min.css" th:href="@{/lib/font-awesome/css/font-awesome.min.css?v=4.7.0}" rel="stylesheet"> <link href="../../static/lib/animate/animate.min.css" th:href="@{/lib/animate/animate.min.css}" rel="stylesheet"> <link href="../../static/lib/hplus/css/hplus.css" th:href="@{/lib/hplus/css/hplus.css}" rel="stylesheet">

<!-- js相关调整 --> <script src="../../static/lib/jquery/jquery.min.js" th:src="@{/lib/jquery/jquery.min.js}"></script> <script src="../../static/lib/bootstrap/js/bootstrap.min.js" th:src="@{/lib/bootstrap/js/bootstrap.min.js}"></script> <script src="../../static/lib/metismenu/jquery.metisMenu.js" th:src="@{/lib/metismenu/jquery.metisMenu.js}"></script> <script src="../../static/lib/slimscroll/jquery.slimscroll.min.js" th:src="@{/lib/slimscroll/jquery.slimscroll.min.js}"></script> <script src="../../static/lib/layer/layer.min.js" th:src="@{/lib/layer/layer.min.js}" ></script> <script src="../../static/lib/hplus/js/hplus.js" th:src="@{/lib/hplus/js/hplus.js}" ></script> <script src="../../static/local/js/contabs.js" th:src="@{/local/js/contabs.js}" ></script>

2.4.查看效果

3.功能改造

3.1.左侧导航栏改造

<!-- 首页 一级--> <!-- 博客管理 一级--> <!-- 文章管理 二级--> <!-- 分类管理 二级--> <!-- 标签管理 二级--> <!-- 站点管理 一级--> <!-- 导航管理 二级--> <!-- 站点配置 二级--> <!-- 系统管理 一级--> <!-- 日志管理 二级-->

<nav class="navbar-default navbar-static-side" role="navigation"> <div class="nav-close"> <i class="fa fa-times-circle"></i> </div> <div class="sidebar-collapse"> <ul class="nav" id="side-menu"> <li class="nav-header"> <div class="dropdown profile-element"> <span><img alt="image" class="img-circle" th:src="@{/img/profile_small.jpg}" /></span> <a data-toggle="dropdown" class="dropdown-toggle" href="#"> <span class="clear"> <span class="block m-t-xs"><strong class="font-bold">Beaut-zihan</strong></span> <span class="text-muted text-xs block">超级管理员<b class="caret"></b></span> </span> </a> <ul class="dropdown-menu animated fadeInRight m-t-xs"> <li><a class="zh-menu-item" href="form_avatar.html">个人信息</a></li> <li><a class="zh-menu-item" href="profile.html">修改密码</a></li> <li class="divider"></li> <li><a th:href="@{/m/logout}">安全退出</a></li> </ul> </div> <div class="logo-element">ZH </div> </li> <li> <a th:href="@{/m/version}" class="zh-menu-item"> <i class="fa fa-home"></i> <span class="nav-label">主页</span> </a> </li> <li> <a href="#"> <i class="fa fa-bookmark"></i> <span class="nav-label">博客管理</span> <span class="fa arrow"></span> </a> <ul class="nav nav-second-level"> <li><a class="zh-menu-item" th:href="#"><i class="fa fa-book"></i>文章管理</a></li> <li><a class="zh-menu-item" th:href="#"><i class="fa fa-clone"></i>分类管理</a></li> <li><a class="zh-menu-item" th:href="#"><i class="fa fa-tags"></i>标签管理</a></li> </ul> </li> <li> <a href="#"> <i class="fa fa-desktop"></i> <span class="nav-label">站点管理</span> <span class="fa arrow"></span> </a> <ul class="nav nav-second-level"> <li><a class="zh-menu-item" th:href="#"><i class="fa fa-paper-plane"></i>导航管理</a></li> <li><a class="zh-menu-item" th:href="#"><i class="fa fa-cogs"></i>站点配置</a></li> </ul> </li> <li> <a href="#"> <i class="fa fa-cubes"></i> <span class="nav-label">系统管理</span> <span class="fa arrow"></span> </a> <ul class="nav nav-second-level"> <li><a class="zh-menu-item" th:href="#"><i class="fa fa-navicon"></i>日志管理</a>< </ul> </li> </ul> </div> </nav>

3.2.头部导航栏改造

3.3.tab窗体改造

说是改造,其实是把相关class进行美化/格式化一下,不然在class里面大小写都存在不美观

<div class="row content-tabs"> <button class="roll-nav roll-left zh-tab-left"><i class="fa fa-backward"></i></button> <nav class="page-tabs zh-tab-menus"> <div class="page-tabs-content"> <a href="javascript:;" class="active zh-tab-menu" data-id="index_v1.html">首页</a> </div> </nav> <button class="roll-nav roll-right zh-tab-right"><i class="fa fa-forward"></i></button> <div class="btn-group roll-nav roll-right"> <button class="dropdown tab-close" data-toggle="dropdown">关闭操作<span class="caret"></span></button> <ul role="menu" class="dropdown-menu dropdown-menu-right"> <li class="zh-tab-show-active"><a>定位当前选项卡</a></li> <li class="divider"></li> <li class="zh-tab-close-all"><a>关闭全部选项卡</a></li> <li class="zh-tab-close-other"><a>关闭其他选项卡</a></li> </ul> </div> </div>

3.4.内容区域改造

3.5.页脚改造

<div class="footer" th:fragment="footerbar"> <div class="pull-right">© 2023 <a href="www.chenyakj.com" target="_blank">玖零</a> All rights reserved. </div> </div>

4.代码美化

4.1. 抽取css

<!-- css 引入--> <div th:fragment = "core-css"> <link rel="shortcut icon" href="favicon.ico"> <link href="../../static/lib/bootstrap/css/bootstrap.min.css" th:href="@{/lib/bootstrap/css/bootstrap.min.css}" rel="stylesheet"> <link href="../../static/lib/font-awesome/css/font-awesome.min.css" th:href="@{/lib/font-awesome/css/font-awesome.min.css?v=4.7.0}" rel="stylesheet"> <link href="../../static/lib/animate/animate.min.css" th:href="@{/lib/animate/animate.min.css}" rel="stylesheet"> <link href="../../static/lib/hplus/css/hplus.css" th:href="@{/lib/hplus/css/hplus.css}" rel="stylesheet"> </div>

4.2. 抽取js

<!-- script 引入 --> <div th:fragment = "core-js"> <script src="../../static/lib/jquery/jquery.min.js" th:src="@{/lib/jquery/jquery.min.js}"></script> <script src="../../static/lib/bootstrap/js/bootstrap.min.js" th:src="@{/lib/bootstrap/js/bootstrap.min.js}"></script> <script src="../../static/lib/metismenu/jquery.metisMenu.js" th:src="@{/lib/metismenu/jquery.metisMenu.js}"></script> <script src="../../static/lib/slimscroll/jquery.slimscroll.min.js" th:src="@{/lib/slimscroll/jquery.slimscroll.min.js}"></script> <script src="../../static/lib/layer/layer.min.js" th:src="@{/lib/layer/layer.min.js}" ></script> <script src="../../static/lib/hplus/js/hplus.js" th:src="@{/lib/hplus/js/hplus.js}" ></script> <script src="../../static/local/js/contabs.js" th:src="@{/local/js/contabs.js}" ></script> </div>

4.3. 抽取左侧导航栏

<div th:fragment="sidebar"> <nav class="navbar-default navbar-static-side" role="navigation"> <div class="nav-close"> <i class="fa fa-times-circle"></i> </div> <div class="sidebar-collapse"> <ul class="nav" id="side-menu"> <li class="nav-header"> <div class="dropdown profile-element"> <span><img alt="image" class="img-circle" th:src="@{/img/profile_small.jpg}" /></span> <a data-toggle="dropdown" class="dropdown-toggle" href="#"> <span class="clear"> <span class="block m-t-xs"><strong class="font-bold">Beaut-zihan</strong></span> <span class="text-muted text-xs block">超级管理员<b class="caret"></b></span> </span> </a> <ul class="dropdown-menu animated fadeInRight m-t-xs"> <li><a class="zh-menu-item" href="form_avatar.html">个人信息</a></li> <li><a class="zh-menu-item" href="profile.html">修改密码</a></li> <li class="divider"></li> <li><a th:href="@{/m/logout}">安全退出</a></li> </ul> </div> <div class="logo-element">ZH </div> </li> <li> <a th:href="@{/m/version}" class="zh-menu-item"> <i class="fa fa-home"></i> <span class="nav-label">主页</span> </a> </li> <li> <a href="#"> <i class="fa fa-bookmark"></i> <span class="nav-label">博客管理</span> <span class="fa arrow"></span> </a> <ul class="nav nav-second-level"> <li><a class="zh-menu-item" th:href="#"><i class="fa fa-book"></i>文章管理</a></li> <li><a class="zh-menu-item" href="#"><i class="fa fa-clone"></i>分类管理</a></li> <li><a class="zh-menu-item" th:href="#"><i class="fa fa-tags"></i>标签管理</a></li> </ul> </li> <li> <a href="#"> <i class="fa fa-desktop"></i> <span class="nav-label">站点管理</span> <span class="fa arrow"></span> </a> <ul class="nav nav-second-level"> <li><a class="zh-menu-item" th:href="#"><i class="fa fa-paper-plane"></i>导航管理</a</li> <li><a class="zh-menu-item" href="#"><i class="fa fa-cogs"></i>站点配置</a></li> </ul> </li> <li> <a href="#"> <i class="fa fa-cubes"></i> <span class="nav-label">系统管理</span> <span class="fa arrow"></span> </a> <ul class="nav nav-second-level"> <li><a class="zh-menu-item" href="#"><i class="fa fa-navicon"></i>日志管理</a></li> <li><a class="zh-menu-item" href="#"><i class="fa fa-database"></i>备份管理</a></li> </ul> </li> </ul> </div> </nav> </div>

4.4. 抽取头部导航栏

<div class="row border-bottom" th:fragment="topbar"> <nav class="navbar navbar-static-top" role="navigation" style="margin-bottom: 0"> <div class="navbar-header"> <a class="navbar-minimalize minimalize-styl-2 btn btn-primary " href="#"><i class="fa fa-bars"></i> </a> </div> <ul class="nav navbar-top-links navbar-right"> <li class="dropdown"> <a class="dropdown-toggle count-info" data-toggle="dropdown" href="#"> <i class="fa fa-envelope"></i> <span class="label label-warning">16</span> </a> <ul class="dropdown-menu dropdown-messages"> <li class="m-t-xs"> <div class="dropdown-messages-box"> <a href="profile.html" class="pull-left"> <img alt="image" class="img-circle" src="img/a7.jpg"> </a> <div class="media-body"> <small class="pull-right">46小时前</small> <strong>小四</strong> <br> <small class="text-muted">3天前 2014.11.8</small> </div> </div> </li> <li class="divider"></li> <li> <div class="dropdown-messages-box"> <a href="profile.html" class="pull-left"> <img alt="image" class="img-circle" src="img/a4.jpg"> </a> <div class="media-body "> <small class="pull-right text-navy">25小时前</small> <strong>国民岳父</strong> 如何看待“男子不满自己爱犬被称为狗，刺伤路人”？——这人比犬还凶 <br> <small class="text-muted">昨天</small> </div> </div> </li> <li class="divider"></li> <li> <div class="text-center link-block"> <a class="zh-menu-item" href="mailbox.html"> <i class="fa fa-envelope"></i> <strong> 查看所有消息</strong> </a> </div> </li> </ul> </li> <li class="dropdown"> <a class="dropdown-toggle count-info" data-toggle="dropdown" href="#"> <i class="fa fa-bell"></i> <span class="label label-primary">8</span> </a> <ul class="dropdown-menu dropdown-alerts"> <li> <a href="mailbox.html"> <div> <i class="fa fa-envelope fa-fw"></i> 您有16条未读消息 <span class="pull-right text-muted small">4分钟前</span> </div> </a> </li> <li class="divider"></li> <li> <a href="profile.html"> <div> <i class="fa fa-qq fa-fw"></i> 3条新回复 <span class="pull-right text-muted small">12分钟钱</span> </div> </a> </li> <li class="divider"></li> <li> <div class="text-center link-block"> <a class="zh-menu-item" href="notifications.html"> <strong>查看所有 </strong> <i class="fa fa-angle-right"></i> </a> </div> </li> </ul> </li> <li class="dropdown hidden-xs"> <a class="right-sidebar-toggle" aria-expanded="false"> <i class="fa fa-tasks"></i> 主题 </a> </li> </ul> </nav> </div>

4.5. 抽取页脚

<div class="footer" th:fragment="footerbar"> <div class="pull-right">© 2023 <a href="www.chenyakj.com" target="_blank">玖零</a> All rights reserved. </div> </div>

4.6. 抽取tab窗体

<div class="row content-tabs" th:fragment="tabbar"> <button class="roll-nav roll-left zh-tab-left"><i class="fa fa-backward"></i> </button> <nav class="page-tabs zh-tab-menus"> <div class="page-tabs-content"> <a href="javascript:;" class="active zh-tab-menu" data-id="index_v1.html">首页</a> </div> </nav> <button class="roll-nav roll-right zh-tab-right"><i class="fa fa-forward"></i></button> <div class="btn-group roll-nav roll-right"> <button class="dropdown tab-close" data-toggle="dropdown">关闭操作<span class="caret"></span></button> <ul role="menu" class="dropdown-menu dropdown-menu-right"> <li class="zh-tab-show-active"><a>定位当前选项卡</a></li> <li class="divider"></li> <li class="zh-tab-close-all"><a>关闭全部选项卡</a></li> <li class="zh-tab-close-other"><a>关闭其他选项卡</a></li> </ul> </div> <a href="login.html" class="roll-nav roll-right J_tabExit"><i class="fa fa fa-sign-out"></i> 退出</a> </div>

4.7.组装

<!DOCTYPE html> <html> <head> <div th:replace="/manager/common/common :: core-head('首页','blog','烛火博客是一套开源的博客系统')"></div> <div th:replace="/manager/common/common :: core-css"></div> </head> <body class="fixed-sidebar full-height-layout gray-bg" style="overflow:hidden"> <div id="wrapper"> <div th:replace="/manager/common/sidebar :: sidebar"></div> <!--右侧部分开始--> <div id="page-wrapper" class="gray-bg dashbard-1"> <div th:replace="/manager/common/topbar :: topbar"></div> <div th:replace="/manager/common/tabbar :: tabbar"></div> <!-- main 方法区域 --> <div class="row zh-main-content" id="content-main"> <iframe class="zh-iframe" name="iframe0" width="100%" height="100%" src="main.html" frameborder="0" data-id="main.html" seamless></iframe> </div> <div th:replace="/manager/common/footerbar :: footerbar"></div> </div> </div> <div th:replace="/manager/common/common :: core-js"></div> </body> </html>

4.8. 查看效果
