本文共计8048个文字，预计阅读时间需要33分钟。
为方便学习测试，在没有服务器部署的情况下，容器方式可帮助我们快速启动一个学习测试环境。可依据需要启动一个单机模式，或采用集群模式。
以下是两种启动方式的介绍：
1. 单机模式： - 独立运行，无需网络依赖。 - 简单易用，适合个人学习测试。
2. 集群模式： - 分散部署，实现负载均衡。 - 高可用性，适合团队协作和大规模测试。
1. 单机模式为了方便学习测试，在没有服务器部署的情况，容器方式可以帮助我们快速启动一个学习测试环境。可以根据需要启一个单机模式，或者分片集群模式。下面分别介绍两种启动方式：
- 单机模式
- 副本模式
- 分片模式
其实可以通过docker-compose 快速起一个clickhouse集群环境，但是为了学习部署过程还是分步操作
本次试验clickhouse版本为 22.3.2.1
单机模式很简单 hub.docker.com/r/clickhouse/clickhouse-server
1.1 服务端容器启动方式之前镜像是yandex/clickhouse-server,现在clickhouse/clickhouse-server
可以根据需要选择合适启动命令
docker run -d --name single-clickhouse-server --ulimit nofile=262144:262144 clickhouse/clickhouse-server
方式二：指定端口映射
docker run -d --name single-clickhouse-server --ulimit nofile=262144:262144 -p 8123:8123 -p 9000:9000 -p 9009:9009 clickhouse/clickhouse-server
方式三：挂载目录
## 数据目录 /var/lib/clickhouse/
$ mkdir -p /Users/momo/studySpace/docker/clickhouse/single-volume/data
$ docker run -d --name single-clickhouse-server \
--ulimit nofile=262144:262144 \
-p 8123:8123 -p 9000:9000 -p 9009:9009 \
--volume=/Users/momo/studySpace/docker/clickhouse/single-volume/data:/var/lib/clickhouse \
--platform linux/amd64 \
clickhouse/clickhouse-server
方式四：挂载配置如果报该错，并且在mac m1环境，可尝试在docker run命令中添加选项**--platform linux/amd64 **
官方解释：docs.docker.com/desktop/mac/apple-silicon/
WARNING: The requested image's platform (linux/amd64) does not match the detected host platform (linux/arm64/v8) and no specific platform was requested
为了在本机修改配置方便，可将配置挂载到本机
- 容器中配置目录: /etc/clickhouse-server
- 需要提前准备好配置放到挂载目录，否则会有启动报错： Configuration file '/etc/clickhouse-server/config.xml' isn't readable by user with id '101'
- 查看clickhouse版本：select version() 查看版本 22.3.2.1
# 创建配置目录在本机挂载目录
$ mkdir -p /Users/momo/studySpace/docker/clickhouse/single-volume/{config,logs}
# 可先能过以上方式启动容器，然后将容器配置拷贝出来, docker cp 容器id:容器目录 本机目录
$ docker cp b723e2da1368:/etc/clickhouse-server /Users/momo/studySpace/docker/clickhouse/single-volume/config
$ docker run -d --name single-clickhouse-server \
--ulimit nofile=262144:262144 \
-p 8123:8123 -p 9000:9000 -p 9009:9009 \
--volume=/Users/momo/studySpace/docker/clickhouse/single-volume/data:/var/lib/clickhouse \
--volume=/Users/momo/studySpace/docker/clickhouse/single-volume/config/clickhouse-server:/etc/clickhouse-server \
--volume=/Users/momo/studySpace/docker/clickhouse/single-volume/logs:/var/log/clickhouse-server \
--platform linux/amd64 \
clickhouse/clickhouse-server
删除容器
## 删除容器
docker stop single-clickhouse-server && docker rm single-clickhouse-server
1.2 客户端连接命令
docker run -it --rm --link single-clickhouse-server:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server
2. 副本模式
副本的目的主要是保障数据的高可用性，即使一台 ClickHouse 节点宕机，那么也可以从 其他服务器获得相同的数据。clickhouse.com/docs/en/engines/table-engines/mergetree-family/replication/
2.1 zookeeperzookeeper
host1
host2
standalone方式启动，详细使用说明：hub.docker.com/_/zookeeper
# 创建专有网络,zk,clickhouse容器都加入该网络
docker network create clickhouse
# 方式一：快速启动
$ docker run --name zk-standalone --network clickhouse --restart always -d zookeeper
# 方式二：挂载目录，防止重启数据丢失
## 数据目录 /data，日志目录 /datalog
$ mkdir -p /Users/momo/studySpace/docker/zookeeper/data
$ mkdir -p /Users/momo/studySpace/docker/zookeeper/datalog
$ docker run --name zk-standalone \
--restart always \
-v /Users/momo/studySpace/docker/zookeeper/data:/data \
-v /Users/momo/studySpace/docker/zookeeper/datalog:/datalog \
-d zookeeper
2.2 clickhouse
2.2.1 准备配置
创建本地挂载目录
mkdir -p /Users/momo/studySpace/docker/clickhouse/replica-volume1/config
mkdir -p /Users/momo/studySpace/docker/clickhouse/replica-volume2/config
# 可先通过单机模式启动容器，然后将容器配置拷贝出来, docker cp 容器id:容器目录 本机目录
$ docker cp b723e2da1368:/etc/clickhouse-server /Users/momo/studySpace/docker/clickhouse/replica-volume1/config
$ docker cp b723e2da1368:/etc/clickhouse-server /Users/momo/studySpace/docker/clickhouse/replica-volume2/config
$ tree replica-volume1
replica-volume1
└── config
└── clickhouse-server
├── config.d
│ └── docker_related_config.xml
├── config.xml
├── users.d
└── users.xml
4 directories, 3 files
clickhouse-server/config.xml 添加内容如下：
<zookeeper>
<node>
<host>zookeeper</host>
<port>2181</port>
</node>
</zookeeper>
修改docker_related_config.xml
<clickhouse>
<!-- Listen wildcard address to allow accepting connections from other containers and host network. -->
<listen_host>::</listen_host> <!--删除这一条，ipv6时保留该配置-->
<listen_host>0.0.0.0</listen_host> <!--当前使用ipv4, 保留该配置-->
<listen_try>1</listen_try>
<!--
<logger>
<console>1</console>
</logger>
-->
</clickhouse>
同步replica-volume1和replica-volume2下的配置
2.2.2 启动clickhouse server# 创建相应的挂载目录
mkdir -p /Users/momo/studySpace/docker/clickhouse/replica-volume1/data
mkdir -p /Users/momo/studySpace/docker/clickhouse/replica-volume2/data
mkdir -p /Users/momo/studySpace/docker/clickhouse/replica-volume1/logs
mkdir -p /Users/momo/studySpace/docker/clickhouse/replica-volume2/logs
$ docker run -d --name replica-host1 \
-h replica-host1 \
--ulimit nofile=262144:262144 \
--volume=/Users/momo/studySpace/docker/clickhouse/replica-volume1/data:/var/lib/clickhouse \
--volume=/Users/momo/studySpace/docker/clickhouse/replica-volume1/logs:/var/log/clickhouse-server \
--volume=/Users/momo/studySpace/docker/clickhouse/replica-volume1/config/clickhouse-server:/etc/clickhouse-server \
--link zk-standalone:zookeeper \
--network clickhouse \
--platform linux/amd64 \
clickhouse/clickhouse-server
$ docker run -d --name replica-host2 \
-h replica-host2 \
--ulimit nofile=262144:262144 \
--volume=/Users/momo/studySpace/docker/clickhouse/replica-volume2/data:/var/lib/clickhouse \
--volume=/Users/momo/studySpace/docker/clickhouse/replica-volume2/logs:/var/log/clickhouse-server \
--volume=/Users/momo/studySpace/docker/clickhouse/replica-volume2/config/clickhouse-server:/etc/clickhouse-server \
--link zk-standalone:zookeeper \
--network clickhouse \
--platform linux/amd64 \
clickhouse/clickhouse-server
2.2.3 启动客户端
客户端连接
副本只能同步数据，不能同步表结构，所以我们需要在每台机器上自己手动建表
### 1. 连接replica-host1
$ docker run -it --rm --network clickhouse --link replica-host1:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server
### 1. replica-host1建表
replica-host1 :) create table t_order_rep2 (
id UInt32,
sku_id String,
total_amount Decimal(16,2),
create_time Datetime
) engine =ReplicatedMergeTree('/clickhouse/tables/01/t_order_rep','rep_001')
partition by toYYYYMMDD(create_time)
primary key (id)
order by (id,sku_id);
### 2. 连接replica-host1
$ docker run -it --rm --network clickhouse --link replica-host2:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server
### 2. 这时候查看replica-host2，是没有表的
replica-host2 :) show tables
SHOW TABLES
Query id: e688ae0a-d457-4446-a014-c2f4fdd0a9e4
Ok.
0 rows in set. Elapsed: 0.017 sec.
### 2. replica-host2建表
replica-host2 :) create table t_order_rep2 (
id UInt32,
sku_id String,
total_amount Decimal(16,2),
create_time Datetime
) engine =ReplicatedMergeTree('/clickhouse/tables/01/t_order_rep','rep_002')
partition by toYYYYMMDD(create_time)
primary key (id)
order by (id,sku_id);
### 3. 这个时候可以检查zookeeper上是否已有元数据, 如果没有，检查zookeeper相关配置是否正常
$ docker exec -it zk-standalone /bin/bash
$ ./bin/zkCli.sh
[zk: localhost:2181(CONNECTED) 12] ls /clickhouse
tables task_queue
[zk: localhost:2181(CONNECTED) 12] ls /clickhouse/tables
[01]
[zk: localhost:2181(CONNECTED) 13] ls /clickhouse/tables/01
[t_order_rep]
[zk: localhost:2181(CONNECTED) 14] ls /clickhouse/tables/01/t_order_rep
[alter_partition_version, block_numbers, blocks, columns, leader_election, log, metadata, mutations, nonincrement_block_numbers, part_moves_shard, pinned_part_uuids, quorum, replicas, table_shared_id, temp, zero_copy_hdfs, zero_copy_s3]
### 3. 也可以在clickhouse client执行sql查询
replica-host1 :) select * from system.zookeeper where path='/'
SELECT *
FROM system.zookeeper
WHERE path = '/'
Query id: 30f82647-2d59-42b7-b48b-5c46eba16d72
┌─name───────┬─value─┬─czxid─┬─mzxid─┬───────────────ctime─┬───────────────mtime─┬─version─┬─cversion─┬─aversion─┬─ephemeralOwner─┬─dataLength─┬─numChildren─┬─pzxid─┬─path─┐
│ zookeeper │ │ 0 │ 0 │ 1970-01-01 00:00:00 │ 1970-01-01 00:00:00 │ 0 │ -2 │ 0 │ 0 │ 0 │ 2 │ 0 │ / │
│ clickhouse │ │ 2 │ 2 │ 2022-03-31 03:36:02 │ 2022-03-31 03:36:02 │ 0 │ 2 │ 0 │ 0 │ 0 │ 2 │ 11 │ / │
└────────────┴───────┴───────┴───────┴─────────────────────┴─────────────────────┴─────────┴──────────┴──────────┴────────────────┴────────────┴─────────────┴───────┴──────┘
2 rows in set. Elapsed: 0.028 sec.
clickhouse.com/docs/en/engines/table-engines/mergetree-family/replication/
参数说明:
ReplicatedMergeTree中：
- 第一个参数是分片的zk_path一般按照:/clickhouse/table/{shard}/{table_name} 的格式写，如果只有一个分片就写 01 即可。
- 第二个参数是副本名称，相同的分片副本名称不能相同。
实例插入数据，验证数据是否同步
# 1. 在replica_host1插入数据
insert into t_order_rep2 values
(101,'sku_001',1000.00,'2022-03-01 12:00:00'),
(102,'sku_002',2000.00,'2022-03-01 12:00:00'),
(103,'sku_004',2500.00,'2022-03-01 12:00:00'),
(104,'sku_002',2000.00,'2022-03-01 12:00:00'),
(105,'sku_003',600.00,'2022-03-02 12:00:00');
# 2. 在replica_host1查询数据，已经插入成功
replica-host1 :) select * from t_order_rep2
SELECT *
FROM t_order_rep2
Query id: b9dc6dc0-891b-4b68-8d6b-44cd835da82a
┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐
│ 105 │ sku_003 │ 600 │ 2022-03-02 12:00:00 │
└─────┴─────────┴──────────────┴─────────────────────┘
┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐
│ 101 │ sku_001 │ 1000 │ 2022-03-01 12:00:00 │
│ 102 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │
│ 103 │ sku_004 │ 2500 │ 2022-03-01 12:00:00 │
│ 104 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │
└─────┴─────────┴──────────────┴─────────────────────┘
5 rows in set. Elapsed: 0.059 sec.
# 3. 在replica_host2查询数据，发现数据自动同步过来了
replica-host2 :) select * from t_order_rep2
SELECT *
FROM t_order_rep2
Query id: a2f6a208-5986-48d8-b50b-15779d4e3da4
┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐
│ 101 │ sku_001 │ 1000 │ 2022-03-01 12:00:00 │
│ 102 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │
│ 103 │ sku_004 │ 2500 │ 2022-03-01 12:00:00 │
│ 104 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │
└─────┴─────────┴──────────────┴─────────────────────┘
┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐
│ 105 │ sku_003 │ 600 │ 2022-03-02 12:00:00 │
└─────┴─────────┴──────────────┴─────────────────────┘
5 rows in set. Elapsed: 0.095 sec.
2.2.4 停止删除容器
# 停止
docker stop replica-host1
docker stop replica-host2
# 重启
docker restart replica-host1
docker restart replica-host2
# 停止并删除
docker stop replica-host1 && docker rm replica-host1
docker stop replica-host2 && docker rm replica-host2
2.2.5 错误处理
No interserver IO endpoint named DataPartsExchange
2022.03.31 03:40:52.215028 [ 121 ] {} <Error> InterserverIOHTTPHandler: Code: 221. DB::Exception: No interserver IO endpoint named DataPartsExchange:/clickhouse/tables/01/t_order_rep/replicas/rep_001. (
NO_SUCH_INTERSERVER_IO_ENDPOINT), Stack trace (when copying this message, always include the lines below):
0. DB::Exception::Exception(std::__1::basic_string<char, std::__1::char_traits<char>, std::__1::allocator<char> > const&, int, bool) @ 0xa4dde1a in /usr/bin/clickhouse
1. DB::InterserverIOHandler::getEndpoint(std::__1::basic_string<char, std::__1::char_traits<char>, std::__1::allocator<char> > const&) @ 0x151e36db in /usr/bin/clickhouse
2. DB::InterserverIOHTTPHandler::processQuery(DB::HTTPServerRequest&, DB::HTTPServerResponse&, DB::InterserverIOHTTPHandler::Output&) @ 0x151e2f29 in /usr/bin/clickhouse
3. DB::InterserverIOHTTPHandler::handleRequest(DB::HTTPServerRequest&, DB::HTTPServerResponse&) @ 0x151e3a51 in /usr/bin/clickhouse
4. DB::HTTPServerConnection::run() @ 0x1545979b in /usr/bin/clickhouse
5. Poco::Net::TCPServerConnection::start() @ 0x164b264f in /usr/bin/clickhouse
6. Poco::Net::TCPServerDispatcher::run() @ 0x164b4aa1 in /usr/bin/clickhouse
7. Poco::PooledThread::run() @ 0x16671e49 in /usr/bin/clickhouse
8. Poco::ThreadImpl::runnableEntry(void*) @ 0x1666f1a0 in /usr/bin/clickhouse
9. ? @ 0x400086b609 in ?
10. clone @ 0x40009a5163 in ?
解决办法：
3.1 zookeeper
配置config.xml里interserver_clickhouse.com/docs/en/engines/table-engines/special/distributed/standalone方式启动，详细使用说明：hub.docker.com/_/zookeeper
# 创建专有网络,zk,clickhouse容器都加入该网络 docker network create clickhouse # 方式一：快速启动 $ docker run --name zk-standalone --network clickhouse --restart always -d zookeeper # 方式二：挂载目录，防止重启数据丢失 ## 数据目录 /data，日志目录 /datalog $ mkdir -p /Users/momo/studySpace/docker/zookeeper/data $ mkdir -p /Users/momo/studySpace/docker/zookeeper/datalog $ docker run --name zk-standalone \ --restart always \ -v /Users/momo/studySpace/docker/zookeeper/data:/data \ -v /Users/momo/studySpace/docker/zookeeper/datalog:/datalog \ -d zookeeper3.2 clickhouse(1分片2副本-1分片1副本-共6节点) 3.2.1 准备配置创建本地挂载目录
# 创建相应的挂载目录 for ((i=1;i<=3;i++));do echo ch-host$i;mkdir -p /Users/momo/studySpace/docker/clickhouse/ch-volume$i/{data,logs,config};done # 可先通过单机模式启动容器，然后将容器配置拷贝出来, docker cp 容器id:容器目录 本机目录 $ docker cp b723e2da1368:/etc/clickhouse-server /Users/momo/studySpace/docker/clickhouse/ch-volume1/config $ tree ch-volume1 ch-volume1 ├── config │ └── clickhouse-server │ ├── config.d │ │ ├── docker_related_config.xml │ │ ├── metrika-shard.xml 内容如下 │ │ └── ssl.xml，参考2.2.5第2个报错解决办法 │ ├── config.xml │ ├── users.d │ └── users.xml ├── data └── logs 6 directories, 5 files/etc/clickhouse-server/config.d/metrika-shard.xml(也可以直接配置在config.xml中)
<?xml version="1.0"?> <clickhouse> <remote_servers> <jiazz_cluster> <!-- 集群名称--> <shard> <!--集群的第一个分片--> <internal_replication>true</internal_replication> <replica> <!--该分片的第一个副本--> <host>ch-host1</host> <port>9000</port> </replica> <replica> <!--该分片的第二个副本--> <host>ch-host2</host> <port>9000</port> </replica> </shard> <shard> <!--集群的第二个分片--> <internal_replication>true</internal_replication> <replica> <!--该分片的第一个副本--> <host>ch-host3</host> <port>9000</port> </replica> </shard> </jiazz_cluster> </remote_servers> <zookeeper-servers> <node index="1"> <host>zookeeper</host> <port>2181</port> </node> </zookeeper-servers> <macros> <shard>01</shard> <!--不同机器放的分片数不一样--> <replica>rep_1_1</replica> <!--不同机器放的副本数不一样--> </macros> </clickhouse>/etc/clickhouse-server/config.xml 添加如下配置：
<zookeeper incl="zookeeper-servers" optional="true" /> <include_from>/etc/clickhouse-server/config.d/metrika-shard.xml</include_from>同步配置config.xml 到每个节点，并按节点修改配置metrika-shard.xml的macros
3.2.2 启动clickhouse server
# 启动 for ((i=1;i<=3;i++));do \ echo "start ch-host$i";\ docker run -d --name ch-host$i \ -h ch-host$i \ --ulimit nofile=262144:262144 \ --volume=/Users/momo/studySpace/docker/clickhouse/ch-volume$i/data:/var/lib/clickhouse \ --volume=/Users/momo/studySpace/docker/clickhouse/ch-volume$i/logs:/var/log/clickhouse-server \ --volume=/Users/momo/studySpace/docker/clickhouse/ch-volume$i/config/clickhouse-server:/etc/clickhouse-server \ --link zk-standalone:zookeeper \ --network clickhouse \ --platform linux/amd64 \ clickhouse/clickhouse-server; \ done # 停止 for ((i=1;i<=3;i++));do echo "stop ch-host$i"; docker stop ch-host$i;done # 重启 for ((i=1;i<=3;i++));do echo "restart ch-host$i"; docker restart ch-host$i;done # 删除 for ((i=1;i<=3;i++));do echo "rm ch-host$i"; docker stop ch-host$i && docker rm ch-host$i;done # 清空挂载目录 for ((i=1;i<=3;i++));do echo "clear ch-host$i"; rm -rf /Users/momo/studySpace/docker/clickhouse/ch-volume$i/{data,logs}/*;done3.2.3 启动客户端 3.2.3.1 启动连接指定clickhouse server的客户端
# 连接ch-host1 docker run -it --rm --network clickhouse --link ch-host1:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server # 连接ch-host2 docker run -it --rm --network clickhouse --link ch-host2:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server # 连接ch-host3 docker run -it --rm --network clickhouse --link ch-host3:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server3.2.3.2 在ch-host1上建表
- 会自动同步到ch-host2和ch-host2上
- 集群名字要和配置文件中的一致
- 分片和副本名称从配置文件的宏定义中获取
# 在一个节点建表 ch-host1 :) create table st_order_mt on cluster jiazz_cluster ( id UInt32, sku_id String, total_amount Decimal(16,2), create_time Datetime ) engine=ReplicatedMergeTree('/clickhouse/tables/{shard}/st_order_mt','{replica}') partition by toYYYYMMDD(create_time) primary key (id) order by (id,sku_id); CREATE TABLE st_order_mt ON CLUSTER jiazz_cluster ( `id` UInt32, `sku_id` String, `total_amount` Decimal(16, 2), `create_time` Datetime ) ENGINE = ReplicatedMergeTree('/clickhouse/tables/{shard}/st_order_mt', '{replica}') PARTITION BY toYYYYMMDD(create_time) PRIMARY KEY id ORDER BY (id, sku_id) Query id: 366f51ae-f5eb-4773-ba5e-beb4df56cf1a ┌─host─────┬─port─┬─status─┬─error─┬─num_hosts_remaining─┬─num_hosts_active─┐ │ ch-host1 │ 9000 │ 0 │ │ 2 │ 0 │ │ ch-host2 │ 9000 │ 0 │ │ 1 │ 0 │ │ ch-host3 │ 9000 │ 0 │ │ 0 │ 0 │ └──────────┴──────┴────────┴───────┴─────────────────────┴──────────────────┘ 3 rows in set. Elapsed: 0.292 sec. # ch-host2 ch-host3 表都有了 ch-host2 :) show tables SHOW TABLES Query id: e4c9d46c-476c-423a-ba0f-ab2c3984b6b4 ┌─name────────┐ │ st_order_mt │ └─────────────┘ 1 rows in set. Elapsed: 0.037 sec.3.2.3.3 在ch-host1上建分布式表参数含义:
Distributed(集群名称，库名，本地表名，分片键)
分片键必须是整型数字，所以用 hiveHash 函数转换，也可以 rand()
ch-host1 :) create table st_order_mt_all on cluster jiazz_cluster( id UInt32, sku_id String, total_amount Decimal(16,2), create_time Datetime )engine = Distributed(jiazz_cluster,default,st_order_mt,hiveHash(sku_id)); CREATE TABLE st_order_mt_all ON CLUSTER jiazz_cluster ( `id` UInt32, `sku_id` String, `total_amount` Decimal(16, 2), `create_time` Datetime ) ENGINE = Distributed(jiazz_cluster, default, st_order_mt, hiveHash(sku_id)) Query id: 655b7f5d-ea2c-42c0-bfde-358ef50192bd ┌─host─────┬─port─┬─status─┬─error─┬─num_hosts_remaining─┬─num_hosts_active─┐ │ ch-host1 │ 9000 │ 0 │ │ 2 │ 0 │ │ ch-host2 │ 9000 │ 0 │ │ 1 │ 0 │ │ ch-host3 │ 9000 │ 0 │ │ 0 │ 0 │ └──────────┴──────┴────────┴───────┴─────────────────────┴──────────────────┘ 3 rows in set. Elapsed: 0.155 sec. # 在其它节点确认建表成功 ch-host2 :) show tables SHOW TABLES Query id: 0c5d7ee9-80a0-46e6-aee7-7b06afb17729 ┌─name────────────┐ │ st_order_mt │ │ st_order_mt_all │ └─────────────────┘ 2 rows in set. Elapsed: 0.044 sec.3.2.3.4 在ch-host1插入测试数据
ch-host1 :) insert into st_order_mt_all values (201,'sku_001',1000.00,'2022-03-01 12:00:00') , (202,'sku_002',2000.00,'2022-03-01 12:00:00'), (203,'sku_004',2500.00,'2022-03-01 12:00:00'), (204,'sku_002',2000.00,'2022-03-01 12:00:00'), (205,'sku_003',600.00,'2022-03-02 12:00:00'); INSERT INTO st_order_mt_all FORMAT Values Query id: 0c886dc1-066c-402a-804e-0cbb9d004b5d Ok. 5 rows in set. Elapsed: 0.156 sec.3.2.3.5 通过查询分布式表和本地表观察输出结果
####### 查询分布式表，所有节点查询结果都一样 ch-host2 :) SELECT * FROM st_order_mt_all; SELECT * FROM st_order_mt_all Query id: 72a08fec-5477-4c9c-941b-6bc471400467 ┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐ │ 202 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │ │ 203 │ sku_004 │ 2500 │ 2022-03-01 12:00:00 │ │ 204 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │ └─────┴─────────┴──────────────┴─────────────────────┘ ┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐ │ 201 │ sku_001 │ 1000 │ 2022-03-01 12:00:00 │ └─────┴─────────┴──────────────┴─────────────────────┘ ┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐ │ 205 │ sku_003 │ 600 │ 2022-03-02 12:00:00 │ └─────┴─────────┴──────────────┴─────────────────────┘ 5 rows in set. Elapsed: 0.099 sec. ####### 查询本地表，ch-host1和ch-host2结果一样，因为是第一分片互为复本，ch-host3结果是第二个分片内容 ch-host1 :) select * from st_order_mt; SELECT * FROM st_order_mt Query id: f728b8b0-46ec-4b02-8eca-825173c82dab ┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐ │ 202 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │ │ 203 │ sku_004 │ 2500 │ 2022-03-01 12:00:00 │ │ 204 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │ └─────┴─────────┴──────────────┴─────────────────────┘ 3 rows in set. Elapsed: 0.041 sec. ch-host2 :) select * from st_order_mt; SELECT * FROM st_order_mt Query id: e67512ea-1b43-498d-97b0-5bc57e5172be ┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐ │ 202 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │ │ 203 │ sku_004 │ 2500 │ 2022-03-01 12:00:00 │ │ 204 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │ └─────┴─────────┴──────────────┴─────────────────────┘ 3 rows in set. Elapsed: 0.041 sec. ch-host3 :) select * from st_order_mt; SELECT * FROM st_order_mt Query id: f097753a-4d28-46d8-8d52-82a46908d9af ┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐ │ 205 │ sku_003 │ 600 │ 2022-03-02 12:00:00 │ └─────┴─────────┴──────────────┴─────────────────────┘ ┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐ │ 201 │ sku_001 │ 1000 │ 2022-03-01 12:00:00 │ └─────┴─────────┴──────────────┴─────────────────────┘ 2 rows in set. Elapsed: 0.021 sec.3.3 clickhouse(3分片2副本-共6节点)3分片2副本部署参考：zhuanlan.zhihu.com/p/461792873
此设置仅用于理论验证，不建议在生产中进行此设置。
Clickhouse支持分片和复本：
- Data distribution是指将非常大的数据集拆分为多个存储在不同服务器上的碎片（数据集的较小部分）。ClickHouse根据分片键将数据集分为多个分片。每个分片保存并处理一部分数据，然后将来自多个分片的查询结果组合在一起，给出最终结果。
Data replication是指在其他服务器节点上保留一份数据副本，以确保在服务器节点出现故障时可用。这还可以通过允许多台服务器并行处理数据查询来提高性能。
Circular Replication这里介绍的循环复本是将数据分布在3个分片，并复制2次
这需要在每个节点上放置2个不同的分片。由于每个分片都有相同的表名，因此当碎片/副本位于同一服务器上时，ClickHouse无法区分它们。
解决这个问题的办法：
- 将每个分片放入单独的数据库
- 为每个分片设置默认数据库
- 在分布式表ddl中设置空数据库参数，在查询时系统将使用默认数据库将特定表的查询路由到正确的数据库
- 设置每个分片的internal_replication=true
3.3.1 准备配置
- 生产中的这种拓扑通常需要6个服务器节点，因为每个服务器只存储一个分片的数据，不需要单独的数据库解决方案。
3.3.1.1 创建本地挂载目录
- 在config.d和users.d目录下的.xml文件都会被自动加载到clickhouse中，所以我们可以将不同配置放到不同文件中，再起一个代表性的名字，比如zookeeper.xml表示zk相关配置。
- 尽管默认配置是config.xml 和user.xml，但是不建议直接编辑修改该文件，因为
- 这些文件可能会在下次升级时被覆盖
- 一个文件中配置非常多的时候，查找某个配置比较困难
- 只需复制XML文件即可轻松复制用户配置文件
- 便于在节点间复制配置文件
# 创建相应的挂载目录 for ((i=1;i<=3;i++));do echo ch2-host$i;mkdir -p /Users/momo/studySpace/docker/clickhouse/ch2-volume$i/{data,logs,config};done # 可先通过单机模式启动容器，然后将容器配置拷贝出来, docker cp 容器id:容器目录 本机目录 $ docker cp b723e2da1368:/etc/clickhouse-server /Users/momo/studySpace/docker/clickhouse/ch2-volume1/config $ tree ch2-volume1 ch-volume1 ├── config │ └── clickhouse-server │ ├── config.d │ │ ├── docker_related_config.xml │ │ ├── metrika-shard.xml 内容如下 │ │ └── ssl.xml，参考2.2.5第2个报错解决办法 │ ├── config.xml │ ├── users.d │ └── users.xml ├── data └── logs 6 directories, 5 files3.3.1.2 cluster.xml/etc/clickhouse-server/config.d/cluster.xml
<?xml version="1.0"?> <clickhouse> <remote_servers> <jiazz_cluster_3s_2r> <!-- 集群名称--> <shard> <!--集群的第一个分片--> <internal_replication>true</internal_replication> <replica> <!--该分片的第一个副本--> <default_database>dwh01</default_database> <host>ch-host1</host> <port>9000</port> </replica> <replica> <!--该分片的第二个副本--> <default_database>dwh01</default_database> <host>ch-host2</host> <port>9000</port> </replica> </shard> <shard> <!--集群的第二个分片--> <internal_replication>true</internal_replication> <replica> <!--该分片的第一个副本--> <default_database>dwh02</default_database> <host>ch-host2</host> <port>9000</port> </replica> <replica> <!--该分片的第二个副本--> <default_database>dwh02</default_database> <host>ch-host3</host> <port>9000</port> </replica> </shard> <shard> <!--集群的第三个分片--> <internal_replication>true</internal_replication> <replica> <!--该分片的第一个副本--> <default_database>dwh03</default_database> <host>ch-host3</host> <port>9000</port> </replica> <replica> <!--该分片的第二个副本--> <default_database>dwh03</default_database> <host>ch-host1</host> <port>9000</port> </replica> </shard> </jiazz_cluster_3s_2r> </remote_servers> </clickhouse>3.3.1.3 zookeeper.xml/etc/clickhouse-server/config.d/zookeeper.xml
<?xml version="1.0"?> <clickhouse> <zookeeper> <node index="1"> <host>zookeeper</host> <port>2181</port> </node> </zookeeper> </clickhouse>3.3.1.4 macro.xml/etc/clickhouse-server/config.d/macro.xml
3.3.2 启动clickhouse server
<?xml version="1.0"?> <clickhouse> <macros> <cluster01>jiazz_cluster_3s_2r</cluster01> <!--不同机器放的分片数不一样--> <shard01>s1</shard01> <shard02>s3</shard02> <!--不同机器放的副本数不一样--> <replica01>ch1_s1_r1</replica01> <replica02>ch1_s3_r1</replica02> </macros> </clickhouse>
# 启动 for ((i=1;i<=3;i++));do \ echo "start ch-host$i";\ docker run -d --name ch-host$i \ -h ch-host$i \ --ulimit nofile=262144:262144 \ --volume=/Users/momo/studySpace/docker/clickhouse/ch2-volume$i/data:/var/lib/clickhouse \ --volume=/Users/momo/studySpace/docker/clickhouse/ch2-volume$i/logs:/var/log/clickhouse-server \ --volume=/Users/momo/studySpace/docker/clickhouse/ch2-volume$i/config/clickhouse-server:/etc/clickhouse-server \ --link zk-standalone:zookeeper \ --network clickhouse \ --platform linux/amd64 \ clickhouse/clickhouse-server; \ done # 停止 for ((i=1;i<=3;i++));do echo "stop ch-host$i"; docker stop ch-host$i;done # 重启 for ((i=1;i<=3;i++));do echo "restart ch-host$i"; docker restart ch-host$i;done # 删除 for ((i=1;i<=3;i++));do echo "rm ch-host$i"; docker stop ch-host$i && docker rm ch-host$i;done # 清空挂载目录 for ((i=1;i<=3;i++));do echo "clear ch-host$i"; rm -rf /Users/momo/studySpace/docker/clickhouse/ch2-volume$i/{data,logs}/*;done3.3.3 启动客户端 3.3.3.1 启动连接指定clickhouse server的客户端
# 连接ch-host1 docker run -it --rm --network clickhouse --link ch-host1:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server # 连接ch-host2 docker run -it --rm --network clickhouse --link ch-host2:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server # 连接ch-host3 docker run -it --rm --network clickhouse --link ch-host3:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server3.3.3.2 创建database检查配置
SELECT * FROM system.macros m ;
SELECT * FROM system.clusters c WHERE cluster = 'jiazz_3s_2r';
每个分片有各自的database，如shard01属于dwh01
--ch-host1 CREATE DATABASE IF NOT EXISTS dwh CREATE DATABASE IF NOT EXISTS dwh01 CREATE DATABASE IF NOT EXISTS dwh03 --ch-host2 CREATE DATABASE IF NOT EXISTS dwh CREATE DATABASE IF NOT EXISTS dwh02 CREATE DATABASE IF NOT EXISTS dwh01 --ch-host3 CREATE DATABASE IF NOT EXISTS dwh CREATE DATABASE IF NOT EXISTS dwh03 CREATE DATABASE IF NOT EXISTS dwh02 show databases3.3.3.3 创建本地表创建表模板，根据每个节点，修改database名称即可，一个节点创建两个表
CREATE TABLE dwh03.hits_shard ( `WatchID` UInt64, `JavaEnable` UInt8, `Title` String, `GoodEvent` Int16, `EventTime` DateTime, `EventDate` Date, `CounterID` UInt32, `ClientIP` UInt32, `ClientIP6` FixedString(16), `RegionID` UInt32, `UserID` UInt64, `CounterClass` Int8, `OS` UInt8, `UserAgent` UInt8, `URL` String, `Referer` String, `URLDomain` String, `RefererDomain` String, `Refresh` UInt8, `IsRobot` UInt8, `RefererCategories` Array(UInt16), `URLCategories` Array(UInt16), `URLRegions` Array(UInt32), `RefererRegions` Array(UInt32), `ResolutionWidth` UInt16, `ResolutionHeight` UInt16, `ResolutionDepth` UInt8, `FlashMajor` UInt8, `FlashMinor` UInt8, `FlashMinor2` String, `NetMajor` UInt8, `NetMinor` UInt8, `UserAgentMajor` UInt16, `UserAgentMinor` FixedString(2), `CookieEnable` UInt8, `JavascriptEnable` UInt8, `IsMobile` UInt8, `MobilePhone` UInt8, `MobilePhoneModel` String, `Params` String, `IPNetworkID` UInt32, `TraficSourceID` Int8, `SearchEngineID` UInt16, `SearchPhrase` String, `AdvEngineID` UInt8, `IsArtifical` UInt8, `WindowClientWidth` UInt16, `WindowClientHeight` UInt16, `ClientTimeZone` Int16, `ClientEventTime` DateTime, `SilverlightVersion1` UInt8, `SilverlightVersion2` UInt8, `SilverlightVersion3` UInt32, `SilverlightVersion4` UInt16, `PageCharset` String, `CodeVersion` UInt32, `IsLink` UInt8, `IsDownload` UInt8, `IsNotBounce` UInt8, `FUniqID` UInt64, `HID` UInt32, `IsOldCounter` UInt8, `IsEvent` UInt8, `IsParameter` UInt8, `DontCountHits` UInt8, `WithHash` UInt8, `HitColor` FixedString(1), `UTCEventTime` DateTime, `Age` UInt8, `Sex` UInt8, `Income` UInt8, `Interests` UInt16, `Robotness` UInt8, `GeneralInterests` Array(UInt16), `RemoteIP` UInt32, `RemoteIP6` FixedString(16), `WindowName` Int32, `OpenerName` Int32, `HistoryLength` Int16, `BrowserLanguage` FixedString(2), `BrowserCountry` FixedString(2), `SocialNetwork` String, `SocialAction` String, `HTTPError` UInt16, `SendTiming` Int32, `DNSTiming` Int32, `ConnectTiming` Int32, `ResponseStartTiming` Int32, `ResponseEndTiming` Int32, `FetchTiming` Int32, `RedirectTiming` Int32, `DOMInteractiveTiming` Int32, `DOMContentLoadedTiming` Int32, `DOMCompleteTiming` Int32, `LoadEventStartTiming` Int32, `LoadEventEndTiming` Int32, `NSToDOMContentLoadedTiming` Int32, `FirstPaintTiming` Int32, `RedirectCount` Int8, `SocialSourceNetworkID` UInt8, `SocialSourcePage` String, `ParamPrice` Int64, `ParamOrderID` String, `ParamCurrency` FixedString(3), `ParamCurrencyID` UInt16, `GoalsReached` Array(UInt32), `OpenstatServiceName` String, `OpenstatCampaignID` String, `OpenstatAdID` String, `OpenstatSourceID` String, `UTMSource` String, `UTMMedium` String, `UTMCampaign` String, `UTMContent` String, `UTMTerm` String, `FromTag` String, `HasGCLID` UInt8, `RefererHash` UInt64, `URLHash` UInt64, `CLID` UInt32, `YCLID` UInt64, `ShareService` String, `ShareURL` String, `ShareTitle` String, `ParsedParams` Nested( Key1 String, Key2 String, Key3 String, Key4 String, Key5 String, ValueDouble Float64), `IslandID` FixedString(16), `RequestNum` UInt32, `RequestTry` UInt8 ) ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard01}/tables/hits', '{replica01}') PARTITION BY toYYYYMM(EventDate) ORDER BY (CounterID, EventDate, intHash32(UserID)) SAMPLE BY intHash32(UserID); CREATE TABLE dwh02.hits_shard ( `WatchID` UInt64, `JavaEnable` UInt8, `Title` String, `GoodEvent` Int16, `EventTime` DateTime, `EventDate` Date, `CounterID` UInt32, `ClientIP` UInt32, `ClientIP6` FixedString(16), `RegionID` UInt32, `UserID` UInt64, `CounterClass` Int8, `OS` UInt8, `UserAgent` UInt8, `URL` String, `Referer` String, `URLDomain` String, `RefererDomain` String, `Refresh` UInt8, `IsRobot` UInt8, `RefererCategories` Array(UInt16), `URLCategories` Array(UInt16), `URLRegions` Array(UInt32), `RefererRegions` Array(UInt32), `ResolutionWidth` UInt16, `ResolutionHeight` UInt16, `ResolutionDepth` UInt8, `FlashMajor` UInt8, `FlashMinor` UInt8, `FlashMinor2` String, `NetMajor` UInt8, `NetMinor` UInt8, `UserAgentMajor` UInt16, `UserAgentMinor` FixedString(2), `CookieEnable` UInt8, `JavascriptEnable` UInt8, `IsMobile` UInt8, `MobilePhone` UInt8, `MobilePhoneModel` String, `Params` String, `IPNetworkID` UInt32, `TraficSourceID` Int8, `SearchEngineID` UInt16, `SearchPhrase` String, `AdvEngineID` UInt8, `IsArtifical` UInt8, `WindowClientWidth` UInt16, `WindowClientHeight` UInt16, `ClientTimeZone` Int16, `ClientEventTime` DateTime, `SilverlightVersion1` UInt8, `SilverlightVersion2` UInt8, `SilverlightVersion3` UInt32, `SilverlightVersion4` UInt16, `PageCharset` String, `CodeVersion` UInt32, `IsLink` UInt8, `IsDownload` UInt8, `IsNotBounce` UInt8, `FUniqID` UInt64, `HID` UInt32, `IsOldCounter` UInt8, `IsEvent` UInt8, `IsParameter` UInt8, `DontCountHits` UInt8, `WithHash` UInt8, `HitColor` FixedString(1), `UTCEventTime` DateTime, `Age` UInt8, `Sex` UInt8, `Income` UInt8, `Interests` UInt16, `Robotness` UInt8, `GeneralInterests` Array(UInt16), `RemoteIP` UInt32, `RemoteIP6` FixedString(16), `WindowName` Int32, `OpenerName` Int32, `HistoryLength` Int16, `BrowserLanguage` FixedString(2), `BrowserCountry` FixedString(2), `SocialNetwork` String, `SocialAction` String, `HTTPError` UInt16, `SendTiming` Int32, `DNSTiming` Int32, `ConnectTiming` Int32, `ResponseStartTiming` Int32, `ResponseEndTiming` Int32, `FetchTiming` Int32, `RedirectTiming` Int32, `DOMInteractiveTiming` Int32, `DOMContentLoadedTiming` Int32, `DOMCompleteTiming` Int32, `LoadEventStartTiming` Int32, `LoadEventEndTiming` Int32, `NSToDOMContentLoadedTiming` Int32, `FirstPaintTiming` Int32, `RedirectCount` Int8, `SocialSourceNetworkID` UInt8, `SocialSourcePage` String, `ParamPrice` Int64, `ParamOrderID` String, `ParamCurrency` FixedString(3), `ParamCurrencyID` UInt16, `GoalsReached` Array(UInt32), `OpenstatServiceName` String, `OpenstatCampaignID` String, `OpenstatAdID` String, `OpenstatSourceID` String, `UTMSource` String, `UTMMedium` String, `UTMCampaign` String, `UTMContent` String, `UTMTerm` String, `FromTag` String, `HasGCLID` UInt8, `RefererHash` UInt64, `URLHash` UInt64, `CLID` UInt32, `YCLID` UInt64, `ShareService` String, `ShareURL` String, `ShareTitle` String, `ParsedParams` Nested( Key1 String, Key2 String, Key3 String, Key4 String, Key5 String, ValueDouble Float64), `IslandID` FixedString(16), `RequestNum` UInt32, `RequestTry` UInt8 ) ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard02}/tables/hits', '{replica02}') PARTITION BY toYYYYMM(EventDate) ORDER BY (CounterID, EventDate, intHash32(UserID)) SAMPLE BY intHash32(UserID);ch-host1
CREATE TABLE dwh01.hits_shard <!----- skipped, copy detail from previous -----> ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard01}/tables/hits', '{replica01}') <!----- skipped, copy detail from previous -----> CREATE TABLE dwh03.hits_shard <!----- skipped, copy detail from previous -----> ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard02}/tables/hits', '{replica02}') <!----- skipped, copy detail from previous ----->ch-host2
CREATE TABLE dwh02.hits_shard <!----- skipped, copy detail from previous -----> ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard01}/tables/hits', '{replica01}') <!----- skipped, copy detail from previous -----> CREATE TABLE dwh01.hits_shard <!----- skipped, copy detail from previous -----> ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard02}/tables/hits', '{replica02}') <!----- skipped, copy detail from previous ----->ch-host3
CREATE TABLE dwh03.hits_shard <!----- skipped, copy detail from previous -----> ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard01}/tables/hits', '{replica01}') <!----- skipped, copy detail from previous -----> CREATE TABLE dwh02.hits_shard <!----- skipped, copy detail from previous -----> ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard02}/tables/hits', '{replica02}') <!----- skipped, copy detail from previous ----->检查表配置是否正确
ch-host1 :) SELECT * FROM system.replicas r ; SELECT * FROM system.replicas AS r Query id: b1549b41-67c9-44fe-8bfd-ea05e8205992 ┌─database─┬─table──────┬─engine──────────────┬─is_leader─┬─can_become_leader─┬─is_readonly─┬─is_session_expired─┬─future_parts─┬─parts_to_check─┬─zookeeper_path─────────────────────────────────┬─replica_name─┬─replica_path──────────────────────────────────────────────────────┬─columns_version─┬─queue_size─┬─inserts_in_queue─┬─merges_in_queue─┬─part_mutations_in_queue─┬───queue_oldest_time─┬─inserts_oldest_time─┬──merges_oldest_time─┬─part_mutations_oldest_time─┬─oldest_part_to_get─┬─oldest_part_to_merge_to─┬─oldest_part_to_mutate_to─┬─log_max_index─┬─log_pointer─┬───last_queue_update─┬─absolute_delay─┬─total_replicas─┬─active_replicas─┬─last_queue_update_exception─┬─zookeeper_exception─┬─replica_is_active─────────────┐ │ dwh01 │ hits_shard │ ReplicatedMergeTree │ 1 │ 1 │ 0 │ 0 │ 0 │ 0 │ /clickhouse/jiazz_cluster_3s_2r/s1/tables/hits │ ch1_s1_r1 │ /clickhouse/jiazz_cluster_3s_2r/s1/tables/hits/replicas/ch1_s1_r1 │ -1 │ 0 │ 0 │ 0 │ 0 │ 1970-01-01 00:00:00 │ 1970-01-01 00:00:00 │ 1970-01-01 00:00:00 │ 1970-01-01 00:00:00 │ │ │ │ 0 │ 0 │ 1970-01-01 00:00:00 │ 0 │ 2 │ 2 │ │ │ {'ch2_s1_r2':1,'ch1_s1_r1':1} │ │ dwh03 │ hits_shard │ ReplicatedMergeTree │ 1 │ 1 │ 0 │ 0 │ 0 │ 0 │ /clickhouse/jiazz_cluster_3s_2r/s3/tables/hits │ ch1_s3_r1 │ /clickhouse/jiazz_cluster_3s_2r/s3/tables/hits/replicas/ch1_s3_r1 │ -1 │ 0 │ 0 │ 0 │ 0 │ 1970-01-01 00:00:00 │ 1970-01-01 00:00:00 │ 1970-01-01 00:00:00 │ 1970-01-01 00:00:00 │ │ │ │ 0 │ 0 │ 1970-01-01 00:00:00 │ 0 │ 2 │ 2 │ │ │ {'ch1_s3_r1':1,'ch3_s3_r1':1} │ └──────────┴────────────┴─────────────────────┴───────────┴───────────────────┴─────────────┴────────────────────┴──────────────┴────────────────┴────────────────────────────────────────────────┴──────────────┴───────────────────────────────────────────────────────────────────┴─────────────────┴────────────┴──────────────────┴─────────────────┴─────────────────────────┴─────────────────────┴─────────────────────┴─────────────────────┴────────────────────────────┴────────────────────┴─────────────────────────┴──────────────────────────┴───────────────┴─────────────┴─────────────────────┴────────────────┴────────────────┴─────────────────┴─────────────────────────────┴─────────────────────┴───────────────────────────────┘ 2 rows in set. Elapsed: 0.036 sec. # 只查重点信息，观查对应每个节点是否正常 SELECT database, table, zookeeper_path, replica_name, replica_path, total_replicas, active_replicas, replica_is_active FROM system.replicas r ;ch-host1
ch-host2
ch-host3
3.3.3.4 创建分布式表
注意：数据库参数是空字符串“”，它反过来使用每个分片的默认数据库来查找正确的数据库（例如dwh01、dwh02、dwh03）。
在正常配置（而不是这种循环复制）中，分片本地数据表和分布式表位于同一数据库上。
-- execute the follow DDL on ALL 3 nodes (ch-host1, ch-host2, ch-host3) CREATE TABLE dwh.hits_distributed ( `WatchID` UInt64, `JavaEnable` UInt8, `Title` String, `GoodEvent` Int16, `EventTime` DateTime, `EventDate` Date, `CounterID` UInt32, `ClientIP` UInt32, `ClientIP6` FixedString(16), `RegionID` UInt32, `UserID` UInt64, `CounterClass` Int8, `OS` UInt8, `UserAgent` UInt8, `URL` String, `Referer` String, `URLDomain` String, `RefererDomain` String, `Refresh` UInt8, `IsRobot` UInt8, `RefererCategories` Array(UInt16), `URLCategories` Array(UInt16), `URLRegions` Array(UInt32), `RefererRegions` Array(UInt32), `ResolutionWidth` UInt16, `ResolutionHeight` UInt16, `ResolutionDepth` UInt8, `FlashMajor` UInt8, `FlashMinor` UInt8, `FlashMinor2` String, `NetMajor` UInt8, `NetMinor` UInt8, `UserAgentMajor` UInt16, `UserAgentMinor` FixedString(2), `CookieEnable` UInt8, `JavascriptEnable` UInt8, `IsMobile` UInt8, `MobilePhone` UInt8, `MobilePhoneModel` String, `Params` String, `IPNetworkID` UInt32, `TraficSourceID` Int8, `SearchEngineID` UInt16, `SearchPhrase` String, `AdvEngineID` UInt8, `IsArtifical` UInt8, `WindowClientWidth` UInt16, `WindowClientHeight` UInt16, `ClientTimeZone` Int16, `ClientEventTime` DateTime, `SilverlightVersion1` UInt8, `SilverlightVersion2` UInt8, `SilverlightVersion3` UInt32, `SilverlightVersion4` UInt16, `PageCharset` String, `CodeVersion` UInt32, `IsLink` UInt8, `IsDownload` UInt8, `IsNotBounce` UInt8, `FUniqID` UInt64, `HID` UInt32, `IsOldCounter` UInt8, `IsEvent` UInt8, `IsParameter` UInt8, `DontCountHits` UInt8, `WithHash` UInt8, `HitColor` FixedString(1), `UTCEventTime` DateTime, `Age` UInt8, `Sex` UInt8, `Income` UInt8, `Interests` UInt16, `Robotness` UInt8, `GeneralInterests` Array(UInt16), `RemoteIP` UInt32, `RemoteIP6` FixedString(16), `WindowName` Int32, `OpenerName` Int32, `HistoryLength` Int16, `BrowserLanguage` FixedString(2), `BrowserCountry` FixedString(2), `SocialNetwork` String, `SocialAction` String, `HTTPError` UInt16, `SendTiming` Int32, `DNSTiming` Int32, `ConnectTiming` Int32, `ResponseStartTiming` Int32, `ResponseEndTiming` Int32, `FetchTiming` Int32, `RedirectTiming` Int32, `DOMInteractiveTiming` Int32, `DOMContentLoadedTiming` Int32, `DOMCompleteTiming` Int32, `LoadEventStartTiming` Int32, `LoadEventEndTiming` Int32, `NSToDOMContentLoadedTiming` Int32, `FirstPaintTiming` Int32, `RedirectCount` Int8, `SocialSourceNetworkID` UInt8, `SocialSourcePage` String, `ParamPrice` Int64, `ParamOrderID` String, `ParamCurrency` FixedString(3), `ParamCurrencyID` UInt16, `GoalsReached` Array(UInt32), `OpenstatServiceName` String, `OpenstatCampaignID` String, `OpenstatAdID` String, `OpenstatSourceID` String, `UTMSource` String, `UTMMedium` String, `UTMCampaign` String, `UTMContent` String, `UTMTerm` String, `FromTag` String, `HasGCLID` UInt8, `RefererHash` UInt64, `URLHash` UInt64, `CLID` UInt32, `YCLID` UInt64, `ShareService` String, `ShareURL` String, `ShareTitle` String, `ParsedParams.Key1` Array(String), `ParsedParams.Key2` Array(String), `ParsedParams.Key3` Array(String), `ParsedParams.Key4` Array(String), `ParsedParams.Key5` Array(String), `ParsedParams.ValueDouble` Array(Float64), `IslandID` FixedString(16), `RequestNum` UInt32, `RequestTry` UInt8 ) ENGINE = Distributed('jiazz_cluster_3s_2r', '', 'hits_shard', rand());3.3.3.5 加载数据数据集 clickhouse.com/docs/en/getting-started/tutorial/
- rand()为sharding key，数据将会随机分配到每个分片
- 由于internal_replication=true，一旦数据写入每个分片的第一个副本，ClickHouse系统将自动将数据复制到第二个副本中
# 在里选择ch-host1的挂载目录logs cd ~/studySpace/docker/clickhouse/ch2-volume1/logs curl datasets.clickhouse.com/hits/tsv/hits_v1.tsv.xz | unxz --threads=`nproc` > hits_v1.tsv docker exec -it ch-host1 /bin/bash root@ch-host1:/#cd /var/log/clickhouse-server # 数据文件比较大，导入时间要长 root@ch-host1:/var/log/clickhouse-server# clickhouse-client --query "INSERT INTO dwh.hits_distributed FORMAT TSV" --max_insert_block_size=100000 < hits_v1.tsv查数据
ch-host1 :) select * from dwh.hits_distributed limit 1; SELECT * FROM dwh.hits_distributed LIMIT 1 Query id: 126b3803-659e-48fb-a12f-9e0a261de1ca ┌─────────────WatchID─┬─JavaEnable─┬─Title───────────────────────────────────────────────────────────┬─GoodEvent─┬───────────EventTime─┬──EventDate─┬─CounterID─┬───ClientIP─┬─ClientIP6─┬─RegionID─┬─────────────UserID─┬─CounterClass─┬─OS─┬─UserAgent─┬─URL────────────────────────────────────────────────────────────┬─Referer────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────┬─URLDomain─────────┬─RefererDomain───────┬─Refresh─┬─IsRobot─┬─RefererCategories─┬─URLCategories────┬─URLRegions─┬─RefererRegions─┬─ResolutionWidth─┬─ResolutionHeight─┬─ResolutionDepth─┬─FlashMajor─┬─FlashMinor─┬─FlashMinor2─┬─NetMajor─┬─NetMinor─┬─UserAgentMajor─┬─UserAgentMinor─┬─CookieEnable─┬─JavascriptEnable─┬─IsMobile─┬─MobilePhone─┬─MobilePhoneModel─┬─Params─┬─IPNetworkID─┬─TraficSourceID─┬─SearchEngineID─┬─SearchPhrase─┬─AdvEngineID─┬─IsArtifical─┬─WindowClientWidth─┬─WindowClientHeight─┬─ClientTimeZone─┬─────ClientEventTime─┬─SilverlightVersion1─┬─SilverlightVersion2─┬─SilverlightVersion3─┬─SilverlightVersion4─┬─PageCharset─┬─CodeVersion─┬─IsLink─┬─IsDownload─┬─IsNotBounce─┬─────────────FUniqID─┬───────HID─┬─IsOldCounter─┬─IsEvent─┬─IsParameter─┬─DontCountHits─┬─WithHash─┬─HitColor─┬────────UTCEventTime─┬─Age─┬─Sex─┬─Income─┬─Interests─┬─Robotness─┬─GeneralInterests───────────────────────┬───RemoteIP─┬─RemoteIP6─┬─WindowName─┬─OpenerName─┬─HistoryLength─┬─BrowserLanguage─┬─BrowserCountry─┬─SocialNetwork─┬─SocialAction─┬─HTTPError─┬─SendTiming─┬─DNSTiming─┬─ConnectTiming─┬─ResponseStartTiming─┬─ResponseEndTiming─┬─FetchTiming─┬─RedirectTiming─┬─DOMInteractiveTiming─┬─DOMContentLoadedTiming─┬─DOMCompleteTiming─┬─LoadEventStartTiming─┬─LoadEventEndTiming─┬─NSToDOMContentLoadedTiming─┬─FirstPaintTiming─┬─RedirectCount─┬─SocialSourceNetworkID─┬─SocialSourcePage─┬─ParamPrice─┬─ParamOrderID─┬─ParamCurrency─┬─ParamCurrencyID─┬─GoalsReached─┬─OpenstatServiceName─┬─OpenstatCampaignID─┬─OpenstatAdID─┬─OpenstatSourceID─┬─UTMSource─┬─UTMMedium─┬─UTMCampaign─┬─UTMContent─┬─UTMTerm─┬─FromTag─┬─HasGCLID─┬─────────RefererHash─┬────────────URLHash─┬─CLID─┬─YCLID─┬─ShareService─┬─ShareURL─┬─ShareTitle─┬─ParsedParams.Key1─┬─ParsedParams.Key2─┬─ParsedParams.Key3─┬─ParsedParams.Key4─┬─ParsedParams.Key5─┬─ParsedParams.ValueDouble─┬─IslandID─┬─RequestNum─┬─RequestTry─┐ │ 4944118417295196513 │ 1 │ вышивка в Москве - Образовать фото мочия - Почта Mail.Ru: Силва │ 1 │ 2014-03-17 13:19:26 │ 2014-03-17 │ 57 │ 1581336367 │ ��:�[�Uc��m��� │ 54 │ 610708775678702928 │ 0 │ 1 │ 3 │ hurpasspx?EntityType=images.jpg,iconnId=140Z1BmWE9JVEdoQ2Zud01aa0f8b72a2cb141ad2fbb6bc0488a293f1c0b7bbfe6e0921396325_7860c5b30e0216&mb_url=svit/realesta.com/?do=news.ru/yandex.php?thread%2FEl0TTQQZIClEGYFcJG1F4XldSeWtvVkFkf38xIAEsQVgWCVtUe15_d34cemhbU0dIfji-RM │ hurpass.uaprod.hu │ incityadspix.com.vn │ 0 │ 0 │ [6,98,456,8586] │ [5,92,469,13425] │ [348,1010] │ [267,694] │ 1846 │ 952 │ 29 │ 8 │ 0 │ 0. │ 0 │ 0 │ 24 │ s� │ 1 │ 1 │ 0 │ 0 │ │ │ 3223479 │ -1 │ 0 │ │ 0 │ 1 │ 1246 │ 906 │ 157 │ 2014-03-17 16:32:09 │ 5 │ 1 │ 19832 │ 0 │ utf-8 │ 291 │ 0 │ 0 │ 0 │ 5970711023083247428 │ 117479153 │ 0 │ 0 │ 0 │ 1 │ 0 │ E │ 2014-03-17 13:03:08 │ 55 │ 1 │ 2 │ 16014 │ 8 │ [5,2,14,925,4,3993,72,6,9,27,1,3,1019] │ 2024189568 │ ���_Y����5Ӵ. │ 8687 │ -1 │ 1 │ nD │ Tp │ │ │ 0 │ -1 │ -1 │ -1 │ -1 │ -1 │ -1 │ -1 │ -1 │ -1 │ -1 │ -1 │ -1 │ 7557 │ -1 │ -1 │ 0 │ │ 0 │ │ � │ 0 │ [834016] │ │ │ │ │ │ │ │ │ │ │ 0 │ 7613536979754271517 │ 966296541083783832 │ 0 │ 0 │ │ │ │ [] │ [] │ [] │ [] │ [] │ [] │ ���+������bKQ9 │ 1324 │ 1 │ └─────────────────────┴────────────┴─────────────────────────────────────────────────────────────────┴───────────┴─────────────────────┴────────────┴───────────┴────────────┴───────────┴──────────┴────────────────────┴──────────────┴────┴───────────┴────────────────────────────────────────────────────────────────┴────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────┴───────────────────┴─────────────────────┴─────────┴─────────┴───────────────────┴──────────────────┴────────────┴────────────────┴─────────────────┴──────────────────┴─────────────────┴────────────┴────────────┴─────────────┴──────────┴──────────┴────────────────┴────────────────┴──────────────┴──────────────────┴──────────┴─────────────┴──────────────────┴────────┴─────────────┴────────────────┴────────────────┴──────────────┴─────────────┴─────────────┴───────────────────┴────────────────────┴────────────────┴─────────────────────┴─────────────────────┴─────────────────────┴─────────────────────┴─────────────────────┴─────────────┴─────────────┴────────┴────────────┴─────────────┴─────────────────────┴───────────┴──────────────┴─────────┴─────────────┴───────────────┴──────────┴──────────┴─────────────────────┴─────┴─────┴────────┴───────────┴───────────┴────────────────────────────────────────┴────────────┴───────────┴────────────┴────────────┴───────────────┴─────────────────┴────────────────┴───────────────┴──────────────┴───────────┴────────────┴───────────┴───────────────┴─────────────────────┴───────────────────┴─────────────┴────────────────┴──────────────────────┴────────────────────────┴───────────────────┴──────────────────────┴────────────────────┴────────────────────────────┴──────────────────┴───────────────┴───────────────────────┴──────────────────┴────────────┴──────────────┴───────────────┴─────────────────┴──────────────┴─────────────────────┴────────────────────┴──────────────┴──────────────────┴───────────┴───────────┴─────────────┴────────────┴─────────┴─────────┴──────────┴─────────────────────┴────────────────────┴──────┴───────┴──────────────┴──────────┴────────────┴───────────────────┴───────────────────┴───────────────────┴───────────────────┴───────────────────┴──────────────────────────┴──────────┴────────────┴────────────┘ 1 rows in set. Elapsed: 28.719 sec.如果以上有错误就删除数据库并重新开始
DROP DATABASE IF EXISTS dwh DROP DATABASE IF EXISTS dwh01 DROP DATABASE IF EXISTS dwh02 DROP DATABASE IF EXISTS dwh03Snow nothing, reap nothing.
本文共计8048个文字，预计阅读时间需要33分钟。
为方便学习测试，在没有服务器部署的情况下，容器方式可帮助我们快速启动一个学习测试环境。可依据需要启动一个单机模式，或采用集群模式。
以下是两种启动方式的介绍：
1. 单机模式： - 独立运行，无需网络依赖。 - 简单易用，适合个人学习测试。
2. 集群模式： - 分散部署，实现负载均衡。 - 高可用性，适合团队协作和大规模测试。
1. 单机模式为了方便学习测试，在没有服务器部署的情况，容器方式可以帮助我们快速启动一个学习测试环境。可以根据需要启一个单机模式，或者分片集群模式。下面分别介绍两种启动方式：
- 单机模式
- 副本模式
- 分片模式
其实可以通过docker-compose 快速起一个clickhouse集群环境，但是为了学习部署过程还是分步操作
本次试验clickhouse版本为 22.3.2.1
单机模式很简单 hub.docker.com/r/clickhouse/clickhouse-server
1.1 服务端容器启动方式之前镜像是yandex/clickhouse-server,现在clickhouse/clickhouse-server
可以根据需要选择合适启动命令
docker run -d --name single-clickhouse-server --ulimit nofile=262144:262144 clickhouse/clickhouse-server
方式二：指定端口映射
docker run -d --name single-clickhouse-server --ulimit nofile=262144:262144 -p 8123:8123 -p 9000:9000 -p 9009:9009 clickhouse/clickhouse-server
方式三：挂载目录
## 数据目录 /var/lib/clickhouse/
$ mkdir -p /Users/momo/studySpace/docker/clickhouse/single-volume/data
$ docker run -d --name single-clickhouse-server \
--ulimit nofile=262144:262144 \
-p 8123:8123 -p 9000:9000 -p 9009:9009 \
--volume=/Users/momo/studySpace/docker/clickhouse/single-volume/data:/var/lib/clickhouse \
--platform linux/amd64 \
clickhouse/clickhouse-server
方式四：挂载配置如果报该错，并且在mac m1环境，可尝试在docker run命令中添加选项**--platform linux/amd64 **
官方解释：docs.docker.com/desktop/mac/apple-silicon/
WARNING: The requested image's platform (linux/amd64) does not match the detected host platform (linux/arm64/v8) and no specific platform was requested
为了在本机修改配置方便，可将配置挂载到本机
- 容器中配置目录: /etc/clickhouse-server
- 需要提前准备好配置放到挂载目录，否则会有启动报错： Configuration file '/etc/clickhouse-server/config.xml' isn't readable by user with id '101'
- 查看clickhouse版本：select version() 查看版本 22.3.2.1
# 创建配置目录在本机挂载目录
$ mkdir -p /Users/momo/studySpace/docker/clickhouse/single-volume/{config,logs}
# 可先能过以上方式启动容器，然后将容器配置拷贝出来, docker cp 容器id:容器目录 本机目录
$ docker cp b723e2da1368:/etc/clickhouse-server /Users/momo/studySpace/docker/clickhouse/single-volume/config
$ docker run -d --name single-clickhouse-server \
--ulimit nofile=262144:262144 \
-p 8123:8123 -p 9000:9000 -p 9009:9009 \
--volume=/Users/momo/studySpace/docker/clickhouse/single-volume/data:/var/lib/clickhouse \
--volume=/Users/momo/studySpace/docker/clickhouse/single-volume/config/clickhouse-server:/etc/clickhouse-server \
--volume=/Users/momo/studySpace/docker/clickhouse/single-volume/logs:/var/log/clickhouse-server \
--platform linux/amd64 \
clickhouse/clickhouse-server
删除容器
## 删除容器
docker stop single-clickhouse-server && docker rm single-clickhouse-server
1.2 客户端连接命令
docker run -it --rm --link single-clickhouse-server:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server
2. 副本模式
副本的目的主要是保障数据的高可用性，即使一台 ClickHouse 节点宕机，那么也可以从 其他服务器获得相同的数据。clickhouse.com/docs/en/engines/table-engines/mergetree-family/replication/
2.1 zookeeperzookeeper
host1
host2
standalone方式启动，详细使用说明：hub.docker.com/_/zookeeper
# 创建专有网络,zk,clickhouse容器都加入该网络
docker network create clickhouse
# 方式一：快速启动
$ docker run --name zk-standalone --network clickhouse --restart always -d zookeeper
# 方式二：挂载目录，防止重启数据丢失
## 数据目录 /data，日志目录 /datalog
$ mkdir -p /Users/momo/studySpace/docker/zookeeper/data
$ mkdir -p /Users/momo/studySpace/docker/zookeeper/datalog
$ docker run --name zk-standalone \
--restart always \
-v /Users/momo/studySpace/docker/zookeeper/data:/data \
-v /Users/momo/studySpace/docker/zookeeper/datalog:/datalog \
-d zookeeper
2.2 clickhouse
2.2.1 准备配置
创建本地挂载目录
mkdir -p /Users/momo/studySpace/docker/clickhouse/replica-volume1/config
mkdir -p /Users/momo/studySpace/docker/clickhouse/replica-volume2/config
# 可先通过单机模式启动容器，然后将容器配置拷贝出来, docker cp 容器id:容器目录 本机目录
$ docker cp b723e2da1368:/etc/clickhouse-server /Users/momo/studySpace/docker/clickhouse/replica-volume1/config
$ docker cp b723e2da1368:/etc/clickhouse-server /Users/momo/studySpace/docker/clickhouse/replica-volume2/config
$ tree replica-volume1
replica-volume1
└── config
└── clickhouse-server
├── config.d
│ └── docker_related_config.xml
├── config.xml
├── users.d
└── users.xml
4 directories, 3 files
clickhouse-server/config.xml 添加内容如下：
<zookeeper>
<node>
<host>zookeeper</host>
<port>2181</port>
</node>
</zookeeper>
修改docker_related_config.xml
<clickhouse>
<!-- Listen wildcard address to allow accepting connections from other containers and host network. -->
<listen_host>::</listen_host> <!--删除这一条，ipv6时保留该配置-->
<listen_host>0.0.0.0</listen_host> <!--当前使用ipv4, 保留该配置-->
<listen_try>1</listen_try>
<!--
<logger>
<console>1</console>
</logger>
-->
</clickhouse>
同步replica-volume1和replica-volume2下的配置
2.2.2 启动clickhouse server# 创建相应的挂载目录
mkdir -p /Users/momo/studySpace/docker/clickhouse/replica-volume1/data
mkdir -p /Users/momo/studySpace/docker/clickhouse/replica-volume2/data
mkdir -p /Users/momo/studySpace/docker/clickhouse/replica-volume1/logs
mkdir -p /Users/momo/studySpace/docker/clickhouse/replica-volume2/logs
$ docker run -d --name replica-host1 \
-h replica-host1 \
--ulimit nofile=262144:262144 \
--volume=/Users/momo/studySpace/docker/clickhouse/replica-volume1/data:/var/lib/clickhouse \
--volume=/Users/momo/studySpace/docker/clickhouse/replica-volume1/logs:/var/log/clickhouse-server \
--volume=/Users/momo/studySpace/docker/clickhouse/replica-volume1/config/clickhouse-server:/etc/clickhouse-server \
--link zk-standalone:zookeeper \
--network clickhouse \
--platform linux/amd64 \
clickhouse/clickhouse-server
$ docker run -d --name replica-host2 \
-h replica-host2 \
--ulimit nofile=262144:262144 \
--volume=/Users/momo/studySpace/docker/clickhouse/replica-volume2/data:/var/lib/clickhouse \
--volume=/Users/momo/studySpace/docker/clickhouse/replica-volume2/logs:/var/log/clickhouse-server \
--volume=/Users/momo/studySpace/docker/clickhouse/replica-volume2/config/clickhouse-server:/etc/clickhouse-server \
--link zk-standalone:zookeeper \
--network clickhouse \
--platform linux/amd64 \
clickhouse/clickhouse-server
2.2.3 启动客户端
客户端连接
副本只能同步数据，不能同步表结构，所以我们需要在每台机器上自己手动建表
### 1. 连接replica-host1
$ docker run -it --rm --network clickhouse --link replica-host1:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server
### 1. replica-host1建表
replica-host1 :) create table t_order_rep2 (
id UInt32,
sku_id String,
total_amount Decimal(16,2),
create_time Datetime
) engine =ReplicatedMergeTree('/clickhouse/tables/01/t_order_rep','rep_001')
partition by toYYYYMMDD(create_time)
primary key (id)
order by (id,sku_id);
### 2. 连接replica-host1
$ docker run -it --rm --network clickhouse --link replica-host2:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server
### 2. 这时候查看replica-host2，是没有表的
replica-host2 :) show tables
SHOW TABLES
Query id: e688ae0a-d457-4446-a014-c2f4fdd0a9e4
Ok.
0 rows in set. Elapsed: 0.017 sec.
### 2. replica-host2建表
replica-host2 :) create table t_order_rep2 (
id UInt32,
sku_id String,
total_amount Decimal(16,2),
create_time Datetime
) engine =ReplicatedMergeTree('/clickhouse/tables/01/t_order_rep','rep_002')
partition by toYYYYMMDD(create_time)
primary key (id)
order by (id,sku_id);
### 3. 这个时候可以检查zookeeper上是否已有元数据, 如果没有，检查zookeeper相关配置是否正常
$ docker exec -it zk-standalone /bin/bash
$ ./bin/zkCli.sh
[zk: localhost:2181(CONNECTED) 12] ls /clickhouse
tables task_queue
[zk: localhost:2181(CONNECTED) 12] ls /clickhouse/tables
[01]
[zk: localhost:2181(CONNECTED) 13] ls /clickhouse/tables/01
[t_order_rep]
[zk: localhost:2181(CONNECTED) 14] ls /clickhouse/tables/01/t_order_rep
[alter_partition_version, block_numbers, blocks, columns, leader_election, log, metadata, mutations, nonincrement_block_numbers, part_moves_shard, pinned_part_uuids, quorum, replicas, table_shared_id, temp, zero_copy_hdfs, zero_copy_s3]
### 3. 也可以在clickhouse client执行sql查询
replica-host1 :) select * from system.zookeeper where path='/'
SELECT *
FROM system.zookeeper
WHERE path = '/'
Query id: 30f82647-2d59-42b7-b48b-5c46eba16d72
┌─name───────┬─value─┬─czxid─┬─mzxid─┬───────────────ctime─┬───────────────mtime─┬─version─┬─cversion─┬─aversion─┬─ephemeralOwner─┬─dataLength─┬─numChildren─┬─pzxid─┬─path─┐
│ zookeeper │ │ 0 │ 0 │ 1970-01-01 00:00:00 │ 1970-01-01 00:00:00 │ 0 │ -2 │ 0 │ 0 │ 0 │ 2 │ 0 │ / │
│ clickhouse │ │ 2 │ 2 │ 2022-03-31 03:36:02 │ 2022-03-31 03:36:02 │ 0 │ 2 │ 0 │ 0 │ 0 │ 2 │ 11 │ / │
└────────────┴───────┴───────┴───────┴─────────────────────┴─────────────────────┴─────────┴──────────┴──────────┴────────────────┴────────────┴─────────────┴───────┴──────┘
2 rows in set. Elapsed: 0.028 sec.
clickhouse.com/docs/en/engines/table-engines/mergetree-family/replication/
参数说明:
ReplicatedMergeTree中：
- 第一个参数是分片的zk_path一般按照:/clickhouse/table/{shard}/{table_name} 的格式写，如果只有一个分片就写 01 即可。
- 第二个参数是副本名称，相同的分片副本名称不能相同。
实例插入数据，验证数据是否同步
# 1. 在replica_host1插入数据
insert into t_order_rep2 values
(101,'sku_001',1000.00,'2022-03-01 12:00:00'),
(102,'sku_002',2000.00,'2022-03-01 12:00:00'),
(103,'sku_004',2500.00,'2022-03-01 12:00:00'),
(104,'sku_002',2000.00,'2022-03-01 12:00:00'),
(105,'sku_003',600.00,'2022-03-02 12:00:00');
# 2. 在replica_host1查询数据，已经插入成功
replica-host1 :) select * from t_order_rep2
SELECT *
FROM t_order_rep2
Query id: b9dc6dc0-891b-4b68-8d6b-44cd835da82a
┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐
│ 105 │ sku_003 │ 600 │ 2022-03-02 12:00:00 │
└─────┴─────────┴──────────────┴─────────────────────┘
┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐
│ 101 │ sku_001 │ 1000 │ 2022-03-01 12:00:00 │
│ 102 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │
│ 103 │ sku_004 │ 2500 │ 2022-03-01 12:00:00 │
│ 104 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │
└─────┴─────────┴──────────────┴─────────────────────┘
5 rows in set. Elapsed: 0.059 sec.
# 3. 在replica_host2查询数据，发现数据自动同步过来了
replica-host2 :) select * from t_order_rep2
SELECT *
FROM t_order_rep2
Query id: a2f6a208-5986-48d8-b50b-15779d4e3da4
┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐
│ 101 │ sku_001 │ 1000 │ 2022-03-01 12:00:00 │
│ 102 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │
│ 103 │ sku_004 │ 2500 │ 2022-03-01 12:00:00 │
│ 104 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │
└─────┴─────────┴──────────────┴─────────────────────┘
┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐
│ 105 │ sku_003 │ 600 │ 2022-03-02 12:00:00 │
└─────┴─────────┴──────────────┴─────────────────────┘
5 rows in set. Elapsed: 0.095 sec.
2.2.4 停止删除容器
# 停止
docker stop replica-host1
docker stop replica-host2
# 重启
docker restart replica-host1
docker restart replica-host2
# 停止并删除
docker stop replica-host1 && docker rm replica-host1
docker stop replica-host2 && docker rm replica-host2
2.2.5 错误处理
No interserver IO endpoint named DataPartsExchange
2022.03.31 03:40:52.215028 [ 121 ] {} <Error> InterserverIOHTTPHandler: Code: 221. DB::Exception: No interserver IO endpoint named DataPartsExchange:/clickhouse/tables/01/t_order_rep/replicas/rep_001. (
NO_SUCH_INTERSERVER_IO_ENDPOINT), Stack trace (when copying this message, always include the lines below):
0. DB::Exception::Exception(std::__1::basic_string<char, std::__1::char_traits<char>, std::__1::allocator<char> > const&, int, bool) @ 0xa4dde1a in /usr/bin/clickhouse
1. DB::InterserverIOHandler::getEndpoint(std::__1::basic_string<char, std::__1::char_traits<char>, std::__1::allocator<char> > const&) @ 0x151e36db in /usr/bin/clickhouse
2. DB::InterserverIOHTTPHandler::processQuery(DB::HTTPServerRequest&, DB::HTTPServerResponse&, DB::InterserverIOHTTPHandler::Output&) @ 0x151e2f29 in /usr/bin/clickhouse
3. DB::InterserverIOHTTPHandler::handleRequest(DB::HTTPServerRequest&, DB::HTTPServerResponse&) @ 0x151e3a51 in /usr/bin/clickhouse
4. DB::HTTPServerConnection::run() @ 0x1545979b in /usr/bin/clickhouse
5. Poco::Net::TCPServerConnection::start() @ 0x164b264f in /usr/bin/clickhouse
6. Poco::Net::TCPServerDispatcher::run() @ 0x164b4aa1 in /usr/bin/clickhouse
7. Poco::PooledThread::run() @ 0x16671e49 in /usr/bin/clickhouse
8. Poco::ThreadImpl::runnableEntry(void*) @ 0x1666f1a0 in /usr/bin/clickhouse
9. ? @ 0x400086b609 in ?
10. clone @ 0x40009a5163 in ?
解决办法：
3.1 zookeeper
配置config.xml里interserver_clickhouse.com/docs/en/engines/table-engines/special/distributed/standalone方式启动，详细使用说明：hub.docker.com/_/zookeeper
# 创建专有网络,zk,clickhouse容器都加入该网络 docker network create clickhouse # 方式一：快速启动 $ docker run --name zk-standalone --network clickhouse --restart always -d zookeeper # 方式二：挂载目录，防止重启数据丢失 ## 数据目录 /data，日志目录 /datalog $ mkdir -p /Users/momo/studySpace/docker/zookeeper/data $ mkdir -p /Users/momo/studySpace/docker/zookeeper/datalog $ docker run --name zk-standalone \ --restart always \ -v /Users/momo/studySpace/docker/zookeeper/data:/data \ -v /Users/momo/studySpace/docker/zookeeper/datalog:/datalog \ -d zookeeper3.2 clickhouse(1分片2副本-1分片1副本-共6节点) 3.2.1 准备配置创建本地挂载目录
# 创建相应的挂载目录 for ((i=1;i<=3;i++));do echo ch-host$i;mkdir -p /Users/momo/studySpace/docker/clickhouse/ch-volume$i/{data,logs,config};done # 可先通过单机模式启动容器，然后将容器配置拷贝出来, docker cp 容器id:容器目录 本机目录 $ docker cp b723e2da1368:/etc/clickhouse-server /Users/momo/studySpace/docker/clickhouse/ch-volume1/config $ tree ch-volume1 ch-volume1 ├── config │ └── clickhouse-server │ ├── config.d │ │ ├── docker_related_config.xml │ │ ├── metrika-shard.xml 内容如下 │ │ └── ssl.xml，参考2.2.5第2个报错解决办法 │ ├── config.xml │ ├── users.d │ └── users.xml ├── data └── logs 6 directories, 5 files/etc/clickhouse-server/config.d/metrika-shard.xml(也可以直接配置在config.xml中)
<?xml version="1.0"?> <clickhouse> <remote_servers> <jiazz_cluster> <!-- 集群名称--> <shard> <!--集群的第一个分片--> <internal_replication>true</internal_replication> <replica> <!--该分片的第一个副本--> <host>ch-host1</host> <port>9000</port> </replica> <replica> <!--该分片的第二个副本--> <host>ch-host2</host> <port>9000</port> </replica> </shard> <shard> <!--集群的第二个分片--> <internal_replication>true</internal_replication> <replica> <!--该分片的第一个副本--> <host>ch-host3</host> <port>9000</port> </replica> </shard> </jiazz_cluster> </remote_servers> <zookeeper-servers> <node index="1"> <host>zookeeper</host> <port>2181</port> </node> </zookeeper-servers> <macros> <shard>01</shard> <!--不同机器放的分片数不一样--> <replica>rep_1_1</replica> <!--不同机器放的副本数不一样--> </macros> </clickhouse>/etc/clickhouse-server/config.xml 添加如下配置：
<zookeeper incl="zookeeper-servers" optional="true" /> <include_from>/etc/clickhouse-server/config.d/metrika-shard.xml</include_from>同步配置config.xml 到每个节点，并按节点修改配置metrika-shard.xml的macros
3.2.2 启动clickhouse server
# 启动 for ((i=1;i<=3;i++));do \ echo "start ch-host$i";\ docker run -d --name ch-host$i \ -h ch-host$i \ --ulimit nofile=262144:262144 \ --volume=/Users/momo/studySpace/docker/clickhouse/ch-volume$i/data:/var/lib/clickhouse \ --volume=/Users/momo/studySpace/docker/clickhouse/ch-volume$i/logs:/var/log/clickhouse-server \ --volume=/Users/momo/studySpace/docker/clickhouse/ch-volume$i/config/clickhouse-server:/etc/clickhouse-server \ --link zk-standalone:zookeeper \ --network clickhouse \ --platform linux/amd64 \ clickhouse/clickhouse-server; \ done # 停止 for ((i=1;i<=3;i++));do echo "stop ch-host$i"; docker stop ch-host$i;done # 重启 for ((i=1;i<=3;i++));do echo "restart ch-host$i"; docker restart ch-host$i;done # 删除 for ((i=1;i<=3;i++));do echo "rm ch-host$i"; docker stop ch-host$i && docker rm ch-host$i;done # 清空挂载目录 for ((i=1;i<=3;i++));do echo "clear ch-host$i"; rm -rf /Users/momo/studySpace/docker/clickhouse/ch-volume$i/{data,logs}/*;done3.2.3 启动客户端 3.2.3.1 启动连接指定clickhouse server的客户端
# 连接ch-host1 docker run -it --rm --network clickhouse --link ch-host1:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server # 连接ch-host2 docker run -it --rm --network clickhouse --link ch-host2:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server # 连接ch-host3 docker run -it --rm --network clickhouse --link ch-host3:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server3.2.3.2 在ch-host1上建表
- 会自动同步到ch-host2和ch-host2上
- 集群名字要和配置文件中的一致
- 分片和副本名称从配置文件的宏定义中获取
# 在一个节点建表 ch-host1 :) create table st_order_mt on cluster jiazz_cluster ( id UInt32, sku_id String, total_amount Decimal(16,2), create_time Datetime ) engine=ReplicatedMergeTree('/clickhouse/tables/{shard}/st_order_mt','{replica}') partition by toYYYYMMDD(create_time) primary key (id) order by (id,sku_id); CREATE TABLE st_order_mt ON CLUSTER jiazz_cluster ( `id` UInt32, `sku_id` String, `total_amount` Decimal(16, 2), `create_time` Datetime ) ENGINE = ReplicatedMergeTree('/clickhouse/tables/{shard}/st_order_mt', '{replica}') PARTITION BY toYYYYMMDD(create_time) PRIMARY KEY id ORDER BY (id, sku_id) Query id: 366f51ae-f5eb-4773-ba5e-beb4df56cf1a ┌─host─────┬─port─┬─status─┬─error─┬─num_hosts_remaining─┬─num_hosts_active─┐ │ ch-host1 │ 9000 │ 0 │ │ 2 │ 0 │ │ ch-host2 │ 9000 │ 0 │ │ 1 │ 0 │ │ ch-host3 │ 9000 │ 0 │ │ 0 │ 0 │ └──────────┴──────┴────────┴───────┴─────────────────────┴──────────────────┘ 3 rows in set. Elapsed: 0.292 sec. # ch-host2 ch-host3 表都有了 ch-host2 :) show tables SHOW TABLES Query id: e4c9d46c-476c-423a-ba0f-ab2c3984b6b4 ┌─name────────┐ │ st_order_mt │ └─────────────┘ 1 rows in set. Elapsed: 0.037 sec.3.2.3.3 在ch-host1上建分布式表参数含义:
Distributed(集群名称，库名，本地表名，分片键)
分片键必须是整型数字，所以用 hiveHash 函数转换，也可以 rand()
ch-host1 :) create table st_order_mt_all on cluster jiazz_cluster( id UInt32, sku_id String, total_amount Decimal(16,2), create_time Datetime )engine = Distributed(jiazz_cluster,default,st_order_mt,hiveHash(sku_id)); CREATE TABLE st_order_mt_all ON CLUSTER jiazz_cluster ( `id` UInt32, `sku_id` String, `total_amount` Decimal(16, 2), `create_time` Datetime ) ENGINE = Distributed(jiazz_cluster, default, st_order_mt, hiveHash(sku_id)) Query id: 655b7f5d-ea2c-42c0-bfde-358ef50192bd ┌─host─────┬─port─┬─status─┬─error─┬─num_hosts_remaining─┬─num_hosts_active─┐ │ ch-host1 │ 9000 │ 0 │ │ 2 │ 0 │ │ ch-host2 │ 9000 │ 0 │ │ 1 │ 0 │ │ ch-host3 │ 9000 │ 0 │ │ 0 │ 0 │ └──────────┴──────┴────────┴───────┴─────────────────────┴──────────────────┘ 3 rows in set. Elapsed: 0.155 sec. # 在其它节点确认建表成功 ch-host2 :) show tables SHOW TABLES Query id: 0c5d7ee9-80a0-46e6-aee7-7b06afb17729 ┌─name────────────┐ │ st_order_mt │ │ st_order_mt_all │ └─────────────────┘ 2 rows in set. Elapsed: 0.044 sec.3.2.3.4 在ch-host1插入测试数据
ch-host1 :) insert into st_order_mt_all values (201,'sku_001',1000.00,'2022-03-01 12:00:00') , (202,'sku_002',2000.00,'2022-03-01 12:00:00'), (203,'sku_004',2500.00,'2022-03-01 12:00:00'), (204,'sku_002',2000.00,'2022-03-01 12:00:00'), (205,'sku_003',600.00,'2022-03-02 12:00:00'); INSERT INTO st_order_mt_all FORMAT Values Query id: 0c886dc1-066c-402a-804e-0cbb9d004b5d Ok. 5 rows in set. Elapsed: 0.156 sec.3.2.3.5 通过查询分布式表和本地表观察输出结果
####### 查询分布式表，所有节点查询结果都一样 ch-host2 :) SELECT * FROM st_order_mt_all; SELECT * FROM st_order_mt_all Query id: 72a08fec-5477-4c9c-941b-6bc471400467 ┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐ │ 202 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │ │ 203 │ sku_004 │ 2500 │ 2022-03-01 12:00:00 │ │ 204 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │ └─────┴─────────┴──────────────┴─────────────────────┘ ┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐ │ 201 │ sku_001 │ 1000 │ 2022-03-01 12:00:00 │ └─────┴─────────┴──────────────┴─────────────────────┘ ┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐ │ 205 │ sku_003 │ 600 │ 2022-03-02 12:00:00 │ └─────┴─────────┴──────────────┴─────────────────────┘ 5 rows in set. Elapsed: 0.099 sec. ####### 查询本地表，ch-host1和ch-host2结果一样，因为是第一分片互为复本，ch-host3结果是第二个分片内容 ch-host1 :) select * from st_order_mt; SELECT * FROM st_order_mt Query id: f728b8b0-46ec-4b02-8eca-825173c82dab ┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐ │ 202 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │ │ 203 │ sku_004 │ 2500 │ 2022-03-01 12:00:00 │ │ 204 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │ └─────┴─────────┴──────────────┴─────────────────────┘ 3 rows in set. Elapsed: 0.041 sec. ch-host2 :) select * from st_order_mt; SELECT * FROM st_order_mt Query id: e67512ea-1b43-498d-97b0-5bc57e5172be ┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐ │ 202 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │ │ 203 │ sku_004 │ 2500 │ 2022-03-01 12:00:00 │ │ 204 │ sku_002 │ 2000 │ 2022-03-01 12:00:00 │ └─────┴─────────┴──────────────┴─────────────────────┘ 3 rows in set. Elapsed: 0.041 sec. ch-host3 :) select * from st_order_mt; SELECT * FROM st_order_mt Query id: f097753a-4d28-46d8-8d52-82a46908d9af ┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐ │ 205 │ sku_003 │ 600 │ 2022-03-02 12:00:00 │ └─────┴─────────┴──────────────┴─────────────────────┘ ┌──id─┬─sku_id──┬─total_amount─┬─────────create_time─┐ │ 201 │ sku_001 │ 1000 │ 2022-03-01 12:00:00 │ └─────┴─────────┴──────────────┴─────────────────────┘ 2 rows in set. Elapsed: 0.021 sec.3.3 clickhouse(3分片2副本-共6节点)3分片2副本部署参考：zhuanlan.zhihu.com/p/461792873
此设置仅用于理论验证，不建议在生产中进行此设置。
Clickhouse支持分片和复本：
- Data distribution是指将非常大的数据集拆分为多个存储在不同服务器上的碎片（数据集的较小部分）。ClickHouse根据分片键将数据集分为多个分片。每个分片保存并处理一部分数据，然后将来自多个分片的查询结果组合在一起，给出最终结果。
Data replication是指在其他服务器节点上保留一份数据副本，以确保在服务器节点出现故障时可用。这还可以通过允许多台服务器并行处理数据查询来提高性能。
Circular Replication这里介绍的循环复本是将数据分布在3个分片，并复制2次
这需要在每个节点上放置2个不同的分片。由于每个分片都有相同的表名，因此当碎片/副本位于同一服务器上时，ClickHouse无法区分它们。
解决这个问题的办法：
- 将每个分片放入单独的数据库
- 为每个分片设置默认数据库
- 在分布式表ddl中设置空数据库参数，在查询时系统将使用默认数据库将特定表的查询路由到正确的数据库
- 设置每个分片的internal_replication=true
3.3.1 准备配置
- 生产中的这种拓扑通常需要6个服务器节点，因为每个服务器只存储一个分片的数据，不需要单独的数据库解决方案。
3.3.1.1 创建本地挂载目录
- 在config.d和users.d目录下的.xml文件都会被自动加载到clickhouse中，所以我们可以将不同配置放到不同文件中，再起一个代表性的名字，比如zookeeper.xml表示zk相关配置。
- 尽管默认配置是config.xml 和user.xml，但是不建议直接编辑修改该文件，因为
- 这些文件可能会在下次升级时被覆盖
- 一个文件中配置非常多的时候，查找某个配置比较困难
- 只需复制XML文件即可轻松复制用户配置文件
- 便于在节点间复制配置文件
# 创建相应的挂载目录 for ((i=1;i<=3;i++));do echo ch2-host$i;mkdir -p /Users/momo/studySpace/docker/clickhouse/ch2-volume$i/{data,logs,config};done # 可先通过单机模式启动容器，然后将容器配置拷贝出来, docker cp 容器id:容器目录 本机目录 $ docker cp b723e2da1368:/etc/clickhouse-server /Users/momo/studySpace/docker/clickhouse/ch2-volume1/config $ tree ch2-volume1 ch-volume1 ├── config │ └── clickhouse-server │ ├── config.d │ │ ├── docker_related_config.xml │ │ ├── metrika-shard.xml 内容如下 │ │ └── ssl.xml，参考2.2.5第2个报错解决办法 │ ├── config.xml │ ├── users.d │ └── users.xml ├── data └── logs 6 directories, 5 files3.3.1.2 cluster.xml/etc/clickhouse-server/config.d/cluster.xml
<?xml version="1.0"?> <clickhouse> <remote_servers> <jiazz_cluster_3s_2r> <!-- 集群名称--> <shard> <!--集群的第一个分片--> <internal_replication>true</internal_replication> <replica> <!--该分片的第一个副本--> <default_database>dwh01</default_database> <host>ch-host1</host> <port>9000</port> </replica> <replica> <!--该分片的第二个副本--> <default_database>dwh01</default_database> <host>ch-host2</host> <port>9000</port> </replica> </shard> <shard> <!--集群的第二个分片--> <internal_replication>true</internal_replication> <replica> <!--该分片的第一个副本--> <default_database>dwh02</default_database> <host>ch-host2</host> <port>9000</port> </replica> <replica> <!--该分片的第二个副本--> <default_database>dwh02</default_database> <host>ch-host3</host> <port>9000</port> </replica> </shard> <shard> <!--集群的第三个分片--> <internal_replication>true</internal_replication> <replica> <!--该分片的第一个副本--> <default_database>dwh03</default_database> <host>ch-host3</host> <port>9000</port> </replica> <replica> <!--该分片的第二个副本--> <default_database>dwh03</default_database> <host>ch-host1</host> <port>9000</port> </replica> </shard> </jiazz_cluster_3s_2r> </remote_servers> </clickhouse>3.3.1.3 zookeeper.xml/etc/clickhouse-server/config.d/zookeeper.xml
<?xml version="1.0"?> <clickhouse> <zookeeper> <node index="1"> <host>zookeeper</host> <port>2181</port> </node> </zookeeper> </clickhouse>3.3.1.4 macro.xml/etc/clickhouse-server/config.d/macro.xml
3.3.2 启动clickhouse server
<?xml version="1.0"?> <clickhouse> <macros> <cluster01>jiazz_cluster_3s_2r</cluster01> <!--不同机器放的分片数不一样--> <shard01>s1</shard01> <shard02>s3</shard02> <!--不同机器放的副本数不一样--> <replica01>ch1_s1_r1</replica01> <replica02>ch1_s3_r1</replica02> </macros> </clickhouse>
# 启动 for ((i=1;i<=3;i++));do \ echo "start ch-host$i";\ docker run -d --name ch-host$i \ -h ch-host$i \ --ulimit nofile=262144:262144 \ --volume=/Users/momo/studySpace/docker/clickhouse/ch2-volume$i/data:/var/lib/clickhouse \ --volume=/Users/momo/studySpace/docker/clickhouse/ch2-volume$i/logs:/var/log/clickhouse-server \ --volume=/Users/momo/studySpace/docker/clickhouse/ch2-volume$i/config/clickhouse-server:/etc/clickhouse-server \ --link zk-standalone:zookeeper \ --network clickhouse \ --platform linux/amd64 \ clickhouse/clickhouse-server; \ done # 停止 for ((i=1;i<=3;i++));do echo "stop ch-host$i"; docker stop ch-host$i;done # 重启 for ((i=1;i<=3;i++));do echo "restart ch-host$i"; docker restart ch-host$i;done # 删除 for ((i=1;i<=3;i++));do echo "rm ch-host$i"; docker stop ch-host$i && docker rm ch-host$i;done # 清空挂载目录 for ((i=1;i<=3;i++));do echo "clear ch-host$i"; rm -rf /Users/momo/studySpace/docker/clickhouse/ch2-volume$i/{data,logs}/*;done3.3.3 启动客户端 3.3.3.1 启动连接指定clickhouse server的客户端
# 连接ch-host1 docker run -it --rm --network clickhouse --link ch-host1:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server # 连接ch-host2 docker run -it --rm --network clickhouse --link ch-host2:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server # 连接ch-host3 docker run -it --rm --network clickhouse --link ch-host3:clickhouse-server clickhouse/clickhouse-client --host clickhouse-server3.3.3.2 创建database检查配置
SELECT * FROM system.macros m ;
SELECT * FROM system.clusters c WHERE cluster = 'jiazz_3s_2r';
每个分片有各自的database，如shard01属于dwh01
--ch-host1 CREATE DATABASE IF NOT EXISTS dwh CREATE DATABASE IF NOT EXISTS dwh01 CREATE DATABASE IF NOT EXISTS dwh03 --ch-host2 CREATE DATABASE IF NOT EXISTS dwh CREATE DATABASE IF NOT EXISTS dwh02 CREATE DATABASE IF NOT EXISTS dwh01 --ch-host3 CREATE DATABASE IF NOT EXISTS dwh CREATE DATABASE IF NOT EXISTS dwh03 CREATE DATABASE IF NOT EXISTS dwh02 show databases3.3.3.3 创建本地表创建表模板，根据每个节点，修改database名称即可，一个节点创建两个表
CREATE TABLE dwh03.hits_shard ( `WatchID` UInt64, `JavaEnable` UInt8, `Title` String, `GoodEvent` Int16, `EventTime` DateTime, `EventDate` Date, `CounterID` UInt32, `ClientIP` UInt32, `ClientIP6` FixedString(16), `RegionID` UInt32, `UserID` UInt64, `CounterClass` Int8, `OS` UInt8, `UserAgent` UInt8, `URL` String, `Referer` String, `URLDomain` String, `RefererDomain` String, `Refresh` UInt8, `IsRobot` UInt8, `RefererCategories` Array(UInt16), `URLCategories` Array(UInt16), `URLRegions` Array(UInt32), `RefererRegions` Array(UInt32), `ResolutionWidth` UInt16, `ResolutionHeight` UInt16, `ResolutionDepth` UInt8, `FlashMajor` UInt8, `FlashMinor` UInt8, `FlashMinor2` String, `NetMajor` UInt8, `NetMinor` UInt8, `UserAgentMajor` UInt16, `UserAgentMinor` FixedString(2), `CookieEnable` UInt8, `JavascriptEnable` UInt8, `IsMobile` UInt8, `MobilePhone` UInt8, `MobilePhoneModel` String, `Params` String, `IPNetworkID` UInt32, `TraficSourceID` Int8, `SearchEngineID` UInt16, `SearchPhrase` String, `AdvEngineID` UInt8, `IsArtifical` UInt8, `WindowClientWidth` UInt16, `WindowClientHeight` UInt16, `ClientTimeZone` Int16, `ClientEventTime` DateTime, `SilverlightVersion1` UInt8, `SilverlightVersion2` UInt8, `SilverlightVersion3` UInt32, `SilverlightVersion4` UInt16, `PageCharset` String, `CodeVersion` UInt32, `IsLink` UInt8, `IsDownload` UInt8, `IsNotBounce` UInt8, `FUniqID` UInt64, `HID` UInt32, `IsOldCounter` UInt8, `IsEvent` UInt8, `IsParameter` UInt8, `DontCountHits` UInt8, `WithHash` UInt8, `HitColor` FixedString(1), `UTCEventTime` DateTime, `Age` UInt8, `Sex` UInt8, `Income` UInt8, `Interests` UInt16, `Robotness` UInt8, `GeneralInterests` Array(UInt16), `RemoteIP` UInt32, `RemoteIP6` FixedString(16), `WindowName` Int32, `OpenerName` Int32, `HistoryLength` Int16, `BrowserLanguage` FixedString(2), `BrowserCountry` FixedString(2), `SocialNetwork` String, `SocialAction` String, `HTTPError` UInt16, `SendTiming` Int32, `DNSTiming` Int32, `ConnectTiming` Int32, `ResponseStartTiming` Int32, `ResponseEndTiming` Int32, `FetchTiming` Int32, `RedirectTiming` Int32, `DOMInteractiveTiming` Int32, `DOMContentLoadedTiming` Int32, `DOMCompleteTiming` Int32, `LoadEventStartTiming` Int32, `LoadEventEndTiming` Int32, `NSToDOMContentLoadedTiming` Int32, `FirstPaintTiming` Int32, `RedirectCount` Int8, `SocialSourceNetworkID` UInt8, `SocialSourcePage` String, `ParamPrice` Int64, `ParamOrderID` String, `ParamCurrency` FixedString(3), `ParamCurrencyID` UInt16, `GoalsReached` Array(UInt32), `OpenstatServiceName` String, `OpenstatCampaignID` String, `OpenstatAdID` String, `OpenstatSourceID` String, `UTMSource` String, `UTMMedium` String, `UTMCampaign` String, `UTMContent` String, `UTMTerm` String, `FromTag` String, `HasGCLID` UInt8, `RefererHash` UInt64, `URLHash` UInt64, `CLID` UInt32, `YCLID` UInt64, `ShareService` String, `ShareURL` String, `ShareTitle` String, `ParsedParams` Nested( Key1 String, Key2 String, Key3 String, Key4 String, Key5 String, ValueDouble Float64), `IslandID` FixedString(16), `RequestNum` UInt32, `RequestTry` UInt8 ) ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard01}/tables/hits', '{replica01}') PARTITION BY toYYYYMM(EventDate) ORDER BY (CounterID, EventDate, intHash32(UserID)) SAMPLE BY intHash32(UserID); CREATE TABLE dwh02.hits_shard ( `WatchID` UInt64, `JavaEnable` UInt8, `Title` String, `GoodEvent` Int16, `EventTime` DateTime, `EventDate` Date, `CounterID` UInt32, `ClientIP` UInt32, `ClientIP6` FixedString(16), `RegionID` UInt32, `UserID` UInt64, `CounterClass` Int8, `OS` UInt8, `UserAgent` UInt8, `URL` String, `Referer` String, `URLDomain` String, `RefererDomain` String, `Refresh` UInt8, `IsRobot` UInt8, `RefererCategories` Array(UInt16), `URLCategories` Array(UInt16), `URLRegions` Array(UInt32), `RefererRegions` Array(UInt32), `ResolutionWidth` UInt16, `ResolutionHeight` UInt16, `ResolutionDepth` UInt8, `FlashMajor` UInt8, `FlashMinor` UInt8, `FlashMinor2` String, `NetMajor` UInt8, `NetMinor` UInt8, `UserAgentMajor` UInt16, `UserAgentMinor` FixedString(2), `CookieEnable` UInt8, `JavascriptEnable` UInt8, `IsMobile` UInt8, `MobilePhone` UInt8, `MobilePhoneModel` String, `Params` String, `IPNetworkID` UInt32, `TraficSourceID` Int8, `SearchEngineID` UInt16, `SearchPhrase` String, `AdvEngineID` UInt8, `IsArtifical` UInt8, `WindowClientWidth` UInt16, `WindowClientHeight` UInt16, `ClientTimeZone` Int16, `ClientEventTime` DateTime, `SilverlightVersion1` UInt8, `SilverlightVersion2` UInt8, `SilverlightVersion3` UInt32, `SilverlightVersion4` UInt16, `PageCharset` String, `CodeVersion` UInt32, `IsLink` UInt8, `IsDownload` UInt8, `IsNotBounce` UInt8, `FUniqID` UInt64, `HID` UInt32, `IsOldCounter` UInt8, `IsEvent` UInt8, `IsParameter` UInt8, `DontCountHits` UInt8, `WithHash` UInt8, `HitColor` FixedString(1), `UTCEventTime` DateTime, `Age` UInt8, `Sex` UInt8, `Income` UInt8, `Interests` UInt16, `Robotness` UInt8, `GeneralInterests` Array(UInt16), `RemoteIP` UInt32, `RemoteIP6` FixedString(16), `WindowName` Int32, `OpenerName` Int32, `HistoryLength` Int16, `BrowserLanguage` FixedString(2), `BrowserCountry` FixedString(2), `SocialNetwork` String, `SocialAction` String, `HTTPError` UInt16, `SendTiming` Int32, `DNSTiming` Int32, `ConnectTiming` Int32, `ResponseStartTiming` Int32, `ResponseEndTiming` Int32, `FetchTiming` Int32, `RedirectTiming` Int32, `DOMInteractiveTiming` Int32, `DOMContentLoadedTiming` Int32, `DOMCompleteTiming` Int32, `LoadEventStartTiming` Int32, `LoadEventEndTiming` Int32, `NSToDOMContentLoadedTiming` Int32, `FirstPaintTiming` Int32, `RedirectCount` Int8, `SocialSourceNetworkID` UInt8, `SocialSourcePage` String, `ParamPrice` Int64, `ParamOrderID` String, `ParamCurrency` FixedString(3), `ParamCurrencyID` UInt16, `GoalsReached` Array(UInt32), `OpenstatServiceName` String, `OpenstatCampaignID` String, `OpenstatAdID` String, `OpenstatSourceID` String, `UTMSource` String, `UTMMedium` String, `UTMCampaign` String, `UTMContent` String, `UTMTerm` String, `FromTag` String, `HasGCLID` UInt8, `RefererHash` UInt64, `URLHash` UInt64, `CLID` UInt32, `YCLID` UInt64, `ShareService` String, `ShareURL` String, `ShareTitle` String, `ParsedParams` Nested( Key1 String, Key2 String, Key3 String, Key4 String, Key5 String, ValueDouble Float64), `IslandID` FixedString(16), `RequestNum` UInt32, `RequestTry` UInt8 ) ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard02}/tables/hits', '{replica02}') PARTITION BY toYYYYMM(EventDate) ORDER BY (CounterID, EventDate, intHash32(UserID)) SAMPLE BY intHash32(UserID);ch-host1
CREATE TABLE dwh01.hits_shard <!----- skipped, copy detail from previous -----> ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard01}/tables/hits', '{replica01}') <!----- skipped, copy detail from previous -----> CREATE TABLE dwh03.hits_shard <!----- skipped, copy detail from previous -----> ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard02}/tables/hits', '{replica02}') <!----- skipped, copy detail from previous ----->ch-host2
CREATE TABLE dwh02.hits_shard <!----- skipped, copy detail from previous -----> ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard01}/tables/hits', '{replica01}') <!----- skipped, copy detail from previous -----> CREATE TABLE dwh01.hits_shard <!----- skipped, copy detail from previous -----> ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard02}/tables/hits', '{replica02}') <!----- skipped, copy detail from previous ----->ch-host3
CREATE TABLE dwh03.hits_shard <!----- skipped, copy detail from previous -----> ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard01}/tables/hits', '{replica01}') <!----- skipped, copy detail from previous -----> CREATE TABLE dwh02.hits_shard <!----- skipped, copy detail from previous -----> ENGINE=ReplicatedMergeTree('/clickhouse/{cluster01}/{shard02}/tables/hits', '{replica02}') <!----- skipped, copy detail from previous ----->检查表配置是否正确
ch-host1 :) SELECT * FROM system.replicas r ; SELECT * FROM system.replicas AS r Query id: b1549b41-67c9-44fe-8bfd-ea05e8205992 ┌─database─┬─table──────┬─engine──────────────┬─is_leader─┬─can_become_leader─┬─is_readonly─┬─is_session_expired─┬─future_parts─┬─parts_to_check─┬─zookeeper_path─────────────────────────────────┬─replica_name─┬─replica_path──────────────────────────────────────────────────────┬─columns_version─┬─queue_size─┬─inserts_in_queue─┬─merges_in_queue─┬─part_mutations_in_queue─┬───queue_oldest_time─┬─inserts_oldest_time─┬──merges_oldest_time─┬─part_mutations_oldest_time─┬─oldest_part_to_get─┬─oldest_part_to_merge_to─┬─oldest_part_to_mutate_to─┬─log_max_index─┬─log_pointer─┬───last_queue_update─┬─absolute_delay─┬─total_replicas─┬─active_replicas─┬─last_queue_update_exception─┬─zookeeper_exception─┬─replica_is_active─────────────┐ │ dwh01 │ hits_shard │ ReplicatedMergeTree │ 1 │ 1 │ 0 │ 0 │ 0 │ 0 │ /clickhouse/jiazz_cluster_3s_2r/s1/tables/hits │ ch1_s1_r1 │ /clickhouse/jiazz_cluster_3s_2r/s1/tables/hits/replicas/ch1_s1_r1 │ -1 │ 0 │ 0 │ 0 │ 0 │ 1970-01-01 00:00:00 │ 1970-01-01 00:00:00 │ 1970-01-01 00:00:00 │ 1970-01-01 00:00:00 │ │ │ │ 0 │ 0 │ 1970-01-01 00:00:00 │ 0 │ 2 │ 2 │ │ │ {'ch2_s1_r2':1,'ch1_s1_r1':1} │ │ dwh03 │ hits_shard │ ReplicatedMergeTree │ 1 │ 1 │ 0 │ 0 │ 0 │ 0 │ /clickhouse/jiazz_cluster_3s_2r/s3/tables/hits │ ch1_s3_r1 │ /clickhouse/jiazz_cluster_3s_2r/s3/tables/hits/replicas/ch1_s3_r1 │ -1 │ 0 │ 0 │ 0 │ 0 │ 1970-01-01 00:00:00 │ 1970-01-01 00:00:00 │ 1970-01-01 00:00:00 │ 1970-01-01 00:00:00 │ │ │ │ 0 │ 0 │ 1970-01-01 00:00:00 │ 0 │ 2 │ 2 │ │ │ {'ch1_s3_r1':1,'ch3_s3_r1':1} │ └──────────┴────────────┴─────────────────────┴───────────┴───────────────────┴─────────────┴────────────────────┴──────────────┴────────────────┴────────────────────────────────────────────────┴──────────────┴───────────────────────────────────────────────────────────────────┴─────────────────┴────────────┴──────────────────┴─────────────────┴─────────────────────────┴─────────────────────┴─────────────────────┴─────────────────────┴────────────────────────────┴────────────────────┴─────────────────────────┴──────────────────────────┴───────────────┴─────────────┴─────────────────────┴────────────────┴────────────────┴─────────────────┴─────────────────────────────┴─────────────────────┴───────────────────────────────┘ 2 rows in set. Elapsed: 0.036 sec. # 只查重点信息，观查对应每个节点是否正常 SELECT database, table, zookeeper_path, replica_name, replica_path, total_replicas, active_replicas, replica_is_active FROM system.replicas r ;ch-host1
ch-host2
ch-host3
3.3.3.4 创建分布式表
注意：数据库参数是空字符串“”，它反过来使用每个分片的默认数据库来查找正确的数据库（例如dwh01、dwh02、dwh03）。
在正常配置（而不是这种循环复制）中，分片本地数据表和分布式表位于同一数据库上。
-- execute the follow DDL on ALL 3 nodes (ch-host1, ch-host2, ch-host3) CREATE TABLE dwh.hits_distributed ( `WatchID` UInt64, `JavaEnable` UInt8, `Title` String, `GoodEvent` Int16, `EventTime` DateTime, `EventDate` Date, `CounterID` UInt32, `ClientIP` UInt32, `ClientIP6` FixedString(16), `RegionID` UInt32, `UserID` UInt64, `CounterClass` Int8, `OS` UInt8, `UserAgent` UInt8, `URL` String, `Referer` String, `URLDomain` String, `RefererDomain` String, `Refresh` UInt8, `IsRobot` UInt8, `RefererCategories` Array(UInt16), `URLCategories` Array(UInt16), `URLRegions` Array(UInt32), `RefererRegions` Array(UInt32), `ResolutionWidth` UInt16, `ResolutionHeight` UInt16, `ResolutionDepth` UInt8, `FlashMajor` UInt8, `FlashMinor` UInt8, `FlashMinor2` String, `NetMajor` UInt8, `NetMinor` UInt8, `UserAgentMajor` UInt16, `UserAgentMinor` FixedString(2), `CookieEnable` UInt8, `JavascriptEnable` UInt8, `IsMobile` UInt8, `MobilePhone` UInt8, `MobilePhoneModel` String, `Params` String, `IPNetworkID` UInt32, `TraficSourceID` Int8, `SearchEngineID` UInt16, `SearchPhrase` String, `AdvEngineID` UInt8, `IsArtifical` UInt8, `WindowClientWidth` UInt16, `WindowClientHeight` UInt16, `ClientTimeZone` Int16, `ClientEventTime` DateTime, `SilverlightVersion1` UInt8, `SilverlightVersion2` UInt8, `SilverlightVersion3` UInt32, `SilverlightVersion4` UInt16, `PageCharset` String, `CodeVersion` UInt32, `IsLink` UInt8, `IsDownload` UInt8, `IsNotBounce` UInt8, `FUniqID` UInt64, `HID` UInt32, `IsOldCounter` UInt8, `IsEvent` UInt8, `IsParameter` UInt8, `DontCountHits` UInt8, `WithHash` UInt8, `HitColor` FixedString(1), `UTCEventTime` DateTime, `Age` UInt8, `Sex` UInt8, `Income` UInt8, `Interests` UInt16, `Robotness` UInt8, `GeneralInterests` Array(UInt16), `RemoteIP` UInt32, `RemoteIP6` FixedString(16), `WindowName` Int32, `OpenerName` Int32, `HistoryLength` Int16, `BrowserLanguage` FixedString(2), `BrowserCountry` FixedString(2), `SocialNetwork` String, `SocialAction` String, `HTTPError` UInt16, `SendTiming` Int32, `DNSTiming` Int32, `ConnectTiming` Int32, `ResponseStartTiming` Int32, `ResponseEndTiming` Int32, `FetchTiming` Int32, `RedirectTiming` Int32, `DOMInteractiveTiming` Int32, `DOMContentLoadedTiming` Int32, `DOMCompleteTiming` Int32, `LoadEventStartTiming` Int32, `LoadEventEndTiming` Int32, `NSToDOMContentLoadedTiming` Int32, `FirstPaintTiming` Int32, `RedirectCount` Int8, `SocialSourceNetworkID` UInt8, `SocialSourcePage` String, `ParamPrice` Int64, `ParamOrderID` String, `ParamCurrency` FixedString(3), `ParamCurrencyID` UInt16, `GoalsReached` Array(UInt32), `OpenstatServiceName` String, `OpenstatCampaignID` String, `OpenstatAdID` String, `OpenstatSourceID` String, `UTMSource` String, `UTMMedium` String, `UTMCampaign` String, `UTMContent` String, `UTMTerm` String, `FromTag` String, `HasGCLID` UInt8, `RefererHash` UInt64, `URLHash` UInt64, `CLID` UInt32, `YCLID` UInt64, `ShareService` String, `ShareURL` String, `ShareTitle` String, `ParsedParams.Key1` Array(String), `ParsedParams.Key2` Array(String), `ParsedParams.Key3` Array(String), `ParsedParams.Key4` Array(String), `ParsedParams.Key5` Array(String), `ParsedParams.ValueDouble` Array(Float64), `IslandID` FixedString(16), `RequestNum` UInt32, `RequestTry` UInt8 ) ENGINE = Distributed('jiazz_cluster_3s_2r', '', 'hits_shard', rand());3.3.3.5 加载数据数据集 clickhouse.com/docs/en/getting-started/tutorial/
- rand()为sharding key，数据将会随机分配到每个分片
- 由于internal_replication=true，一旦数据写入每个分片的第一个副本，ClickHouse系统将自动将数据复制到第二个副本中
# 在里选择ch-host1的挂载目录logs cd ~/studySpace/docker/clickhouse/ch2-volume1/logs curl datasets.clickhouse.com/hits/tsv/hits_v1.tsv.xz | unxz --threads=`nproc` > hits_v1.tsv docker exec -it ch-host1 /bin/bash root@ch-host1:/#cd /var/log/clickhouse-server # 数据文件比较大，导入时间要长 root@ch-host1:/var/log/clickhouse-server# clickhouse-client --query "INSERT INTO dwh.hits_distributed FORMAT TSV" --max_insert_block_size=100000 < hits_v1.tsv查数据
ch-host1 :) select * from dwh.hits_distributed limit 1; SELECT * FROM dwh.hits_distributed LIMIT 1 Query id: 126b3803-659e-48fb-a12f-9e0a261de1ca ┌─────────────WatchID─┬─JavaEnable─┬─Title───────────────────────────────────────────────────────────┬─GoodEvent─┬───────────EventTime─┬──EventDate─┬─CounterID─┬───ClientIP─┬─ClientIP6─┬─RegionID─┬─────────────UserID─┬─CounterClass─┬─OS─┬─UserAgent─┬─URL────────────────────────────────────────────────────────────┬─Referer────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────┬─URLDomain─────────┬─RefererDomain───────┬─Refresh─┬─IsRobot─┬─RefererCategories─┬─URLCategories────┬─URLRegions─┬─RefererRegions─┬─ResolutionWidth─┬─ResolutionHeight─┬─ResolutionDepth─┬─FlashMajor─┬─FlashMinor─┬─FlashMinor2─┬─NetMajor─┬─NetMinor─┬─UserAgentMajor─┬─UserAgentMinor─┬─CookieEnable─┬─JavascriptEnable─┬─IsMobile─┬─MobilePhone─┬─MobilePhoneModel─┬─Params─┬─IPNetworkID─┬─TraficSourceID─┬─SearchEngineID─┬─SearchPhrase─┬─AdvEngineID─┬─IsArtifical─┬─WindowClientWidth─┬─WindowClientHeight─┬─ClientTimeZone─┬─────ClientEventTime─┬─SilverlightVersion1─┬─SilverlightVersion2─┬─SilverlightVersion3─┬─SilverlightVersion4─┬─PageCharset─┬─CodeVersion─┬─IsLink─┬─IsDownload─┬─IsNotBounce─┬─────────────FUniqID─┬───────HID─┬─IsOldCounter─┬─IsEvent─┬─IsParameter─┬─DontCountHits─┬─WithHash─┬─HitColor─┬────────UTCEventTime─┬─Age─┬─Sex─┬─Income─┬─Interests─┬─Robotness─┬─GeneralInterests───────────────────────┬───RemoteIP─┬─RemoteIP6─┬─WindowName─┬─OpenerName─┬─HistoryLength─┬─BrowserLanguage─┬─BrowserCountry─┬─SocialNetwork─┬─SocialAction─┬─HTTPError─┬─SendTiming─┬─DNSTiming─┬─ConnectTiming─┬─ResponseStartTiming─┬─ResponseEndTiming─┬─FetchTiming─┬─RedirectTiming─┬─DOMInteractiveTiming─┬─DOMContentLoadedTiming─┬─DOMCompleteTiming─┬─LoadEventStartTiming─┬─LoadEventEndTiming─┬─NSToDOMContentLoadedTiming─┬─FirstPaintTiming─┬─RedirectCount─┬─SocialSourceNetworkID─┬─SocialSourcePage─┬─ParamPrice─┬─ParamOrderID─┬─ParamCurrency─┬─ParamCurrencyID─┬─GoalsReached─┬─OpenstatServiceName─┬─OpenstatCampaignID─┬─OpenstatAdID─┬─OpenstatSourceID─┬─UTMSource─┬─UTMMedium─┬─UTMCampaign─┬─UTMContent─┬─UTMTerm─┬─FromTag─┬─HasGCLID─┬─────────RefererHash─┬────────────URLHash─┬─CLID─┬─YCLID─┬─ShareService─┬─ShareURL─┬─ShareTitle─┬─ParsedParams.Key1─┬─ParsedParams.Key2─┬─ParsedParams.Key3─┬─ParsedParams.Key4─┬─ParsedParams.Key5─┬─ParsedParams.ValueDouble─┬─IslandID─┬─RequestNum─┬─RequestTry─┐ │ 4944118417295196513 │ 1 │ вышивка в Москве - Образовать фото мочия - Почта Mail.Ru: Силва │ 1 │ 2014-03-17 13:19:26 │ 2014-03-17 │ 57 │ 1581336367 │ ��:�[�Uc��m��� │ 54 │ 610708775678702928 │ 0 │ 1 │ 3 │ hurpasspx?EntityType=images.jpg,iconnId=140Z1BmWE9JVEdoQ2Zud01aa0f8b72a2cb141ad2fbb6bc0488a293f1c0b7bbfe6e0921396325_7860c5b30e0216&mb_url=svit/realesta.com/?do=news.ru/yandex.php?thread%2FEl0TTQQZIClEGYFcJG1F4XldSeWtvVkFkf38xIAEsQVgWCVtUe15_d34cemhbU0dIfji-RM │ hurpass.uaprod.hu │ incityadspix.com.vn │ 0 │ 0 │ [6,98,456,8586] │ [5,92,469,13425] │ [348,1010] │ [267,694] │ 1846 │ 952 │ 29 │ 8 │ 0 │ 0. │ 0 │ 0 │ 24 │ s� │ 1 │ 1 │ 0 │ 0 │ │ │ 3223479 │ -1 │ 0 │ │ 0 │ 1 │ 1246 │ 906 │ 157 │ 2014-03-17 16:32:09 │ 5 │ 1 │ 19832 │ 0 │ utf-8 │ 291 │ 0 │ 0 │ 0 │ 5970711023083247428 │ 117479153 │ 0 │ 0 │ 0 │ 1 │ 0 │ E │ 2014-03-17 13:03:08 │ 55 │ 1 │ 2 │ 16014 │ 8 │ [5,2,14,925,4,3993,72,6,9,27,1,3,1019] │ 2024189568 │ ���_Y����5Ӵ. │ 8687 │ -1 │ 1 │ nD │ Tp │ │ │ 0 │ -1 │ -1 │ -1 │ -1 │ -1 │ -1 │ -1 │ -1 │ -1 │ -1 │ -1 │ -1 │ 7557 │ -1 │ -1 │ 0 │ │ 0 │ │ � │ 0 │ [834016] │ │ │ │ │ │ │ │ │ │ │ 0 │ 7613536979754271517 │ 966296541083783832 │ 0 │ 0 │ │ │ │ [] │ [] │ [] │ [] │ [] │ [] │ ���+������bKQ9 │ 1324 │ 1 │ └─────────────────────┴────────────┴─────────────────────────────────────────────────────────────────┴───────────┴─────────────────────┴────────────┴───────────┴────────────┴───────────┴──────────┴────────────────────┴──────────────┴────┴───────────┴────────────────────────────────────────────────────────────────┴────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────┴───────────────────┴─────────────────────┴─────────┴─────────┴───────────────────┴──────────────────┴────────────┴────────────────┴─────────────────┴──────────────────┴─────────────────┴────────────┴────────────┴─────────────┴──────────┴──────────┴────────────────┴────────────────┴──────────────┴──────────────────┴──────────┴─────────────┴──────────────────┴────────┴─────────────┴────────────────┴────────────────┴──────────────┴─────────────┴─────────────┴───────────────────┴────────────────────┴────────────────┴─────────────────────┴─────────────────────┴─────────────────────┴─────────────────────┴─────────────────────┴─────────────┴─────────────┴────────┴────────────┴─────────────┴─────────────────────┴───────────┴──────────────┴─────────┴─────────────┴───────────────┴──────────┴──────────┴─────────────────────┴─────┴─────┴────────┴───────────┴───────────┴────────────────────────────────────────┴────────────┴───────────┴────────────┴────────────┴───────────────┴─────────────────┴────────────────┴───────────────┴──────────────┴───────────┴────────────┴───────────┴───────────────┴─────────────────────┴───────────────────┴─────────────┴────────────────┴──────────────────────┴────────────────────────┴───────────────────┴──────────────────────┴────────────────────┴────────────────────────────┴──────────────────┴───────────────┴───────────────────────┴──────────────────┴────────────┴──────────────┴───────────────┴─────────────────┴──────────────┴─────────────────────┴────────────────────┴──────────────┴──────────────────┴───────────┴───────────┴─────────────┴────────────┴─────────┴─────────┴──────────┴─────────────────────┴────────────────────┴──────┴───────┴──────────────┴──────────┴────────────┴───────────────────┴───────────────────┴───────────────────┴───────────────────┴───────────────────┴──────────────────────────┴──────────┴────────────┴────────────┘ 1 rows in set. Elapsed: 28.719 sec.如果以上有错误就删除数据库并重新开始
DROP DATABASE IF EXISTS dwh DROP DATABASE IF EXISTS dwh01 DROP DATABASE IF EXISTS dwh02 DROP DATABASE IF EXISTS dwh03Snow nothing, reap nothing.
