Spring Security如何详细实现基于用户名密码的登录过程？

本文共计1829个文字，预计阅读时间需要8分钟。

目录+环境+用户名密码登录+E-R图+POM依赖+配置文件+Mapper+Service设计+HTML+Controller+启动+完整代码+环境+JDK 1.8+Spring Boot 2.3.0.RELEASE+Maven 3.6.1+H2数据库+用户名密码登录+首先，我们用Spring Sec

目录

• 环境
• 用户名密码登录
• E-R图
• POM依赖
• 配置文件
• Mapper
• Service设计
• HTML
• Controller
• 启动
• 完整代码

环境

JDK 1.8

Spring Boot 2.3.0.RELEASE

Maven 3.6.1

H2 数据库

用户名密码登录

首先，我们用 Spring Security 实现用户输入用户名密码登录验证并获取相应权限。

E-R图

完整建表语句

因为是测试程序，所以用H2数据库来测试。SQL脚本在resouces/db目录下，项目启动后会自动初始化脚本，无需手动执行。

schema.sql

DROP TABLE IF EXISTS `SYS_ROLE`; DROP TABLE IF EXISTS `SYS_USER_ROLE`; DROP TABLE IF EXISTS `SYS_USER`; create table SYS_ROLE ( ID INT not null primary key, NAME VARCHAR(255) not null ); create table SYS_USER ( ID INT not null primary key, NAME VARCHAR not null, PASSWORD VARCHAR(255) not null ); create table SYS_USER_ROLE ( USER_ID INT not null, ROLE_ID INT not null, constraint pk_1 primary key (ROLE_ID, USER_ID), constraint fk_1 foreign key (ROLE_ID) references SYS_ROLE (ID) on update cascade on delete cascade, constraint fk_2 foreign key (USER_ID) references SYS_USER (ID) on update cascade on delete cascade );

data.sql

INSERT INTO `SYS_ROLE` (`ID`, `NAME`) VALUES (1, 'ADMIN'),(2, 'USER'); INSERT INTO `SYS_USER` (`ID`, `NAME`, `PASSWORD`) VALUES (1, 'super', '888888'), (2, 'jack', '666666'), (3, 'lucy', '999999'); INSERT INTO `SYS_USER_ROLE` (`USER_ID`, `ROLE_ID`) VALUES (1, 1),(2, 2),(3, 2);

准备好建表语句后，完成实体类的编写

SysRole.java

package org.hui.login.model; /** * 用户角色 * @author zenghui * @date 2020-05-20 */ public class SysRole { private Integer id; private String name; public Integer getId() {return id;} public void setId(Integer id) {this.id = id;} public String getName() {return name;} public void setName(String name) {this.name = name;} }

SysUser.java

package org.hui.login.model; /** * 用户基本信息 * @author zenghui * @date 2020-05-20 */ public class SysUser { private Integer id; private String name; private String password; public Integer getId() {return id;} public void setId(Integer id) {this.id = id;} public String getName() {return name;} public void setName(String name) {this.name = name;} public String getPassword() {return password;} public void setPassword(String password) {this.password = password;} }

SysUserRole.java

package org.hui.login.model; /** * 角色和用户对应关系 * @author zenghui * @date 2020-05-20 */ public class SysUserRole { private Integer userId; private Integer roleId; public Integer getUserId() {return userId;} public void setUserId(Integer userId) {this.userId = userId;} public Integer getRoleId() {return roleId;} public void setRoleId(Integer roleId) {this.roleId = roleId;} }

以上，完成了数据层的设计。

POM依赖

<?xml version="1.0" encoding="UTF-8"?> <project xmlns="maven.apache.org/POM/4.0.0" xmlns:xsi="www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="maven.apache.org/POM/4.0.0 maven.apache.org/xsd/maven-4.0.0.xsd"> <modelVersion>4.0.0</modelVersion> <parent> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-parent</artifactId> <version>2.3.0.RELEASE</version> <relativePath/> <!-- lookup parent from repository --> </parent> <groupId>example</groupId> <artifactId>spring-login</artifactId> <version>0.0.1-SNAPSHOT</version> <name>spring-login</name> <description>Spring Security to implements Login</description> <properties> <java.version>1.8</java.version> </properties> <dependencies> <dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-security</artifactId> </dependency> <dependency> <groupId>org.mybatis.spring.boot</groupId> <artifactId>mybatis-spring-boot-starter</artifactId> <version>2.1.2</version> </dependency> <dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-web</artifactId> </dependency> <dependency> <groupId>com.h2database</groupId> <artifactId>h2</artifactId> <scope>runtime</scope> </dependency> </dependencies> <build> <plugins> <plugin> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-maven-plugin</artifactId> </plugin> </plugins> </build> </project>

配置文件

application.properties

spring.datasource.url=jdbc:h2:mem:userdb spring.datasource.driverClassName=org.h2.Driver spring.datasource.username=sa spring.datasource.password=123 #设置SQL脚本的位置，resources/db目录下，如果不设置的话，默认就在resources目录下 spring.datasource.schema=classpath:db/schema.sql spring.datasource.data=classpath:db/data.sql #H2控制台启用 spring.h2.console.enabled=true #访问H2的URL spring.h2.console.path=/h2 # 下划线转化为驼峰命名 mybatis.configuration.map-underscore-to-camel-case=true

Mapper

采用了Mybatis来操作数据库。

准备好需要的几个Mapper，如下

SysRoleMapper.java

package org.hui.login.mapper; import org.apache.ibatis.annotations.Mapper; import org.apache.ibatis.annotations.Select; import org.hui.login.model.SysRole; /** * @author zenghui * @date 2020-05-20 */ @Mapper public interface SysRoleMapper { @Select("SELECT * FROM sys_role WHERE id = #{id}") SysRole selectById(Integer id); }

SysUserMapper.java

package org.hui.login.mapper; import org.apache.ibatis.annotations.Mapper; import org.apache.ibatis.annotations.Select; import org.hui.login.model.SysUser; /** * @author zenghui * @date 2020-05-20 */ @Mapper public interface SysUserMapper { @Select("SELECT * FROM sys_user WHERE name = #{name}") SysUser selectByName(String name); }

SysUserRoleMapper.java

package org.hui.login.mapper; import org.apache.ibatis.annotations.Mapper; import org.apache.ibatis.annotations.Select; import org.hui.login.model.SysUserRole; import java.util.List; /** * @author zenghui * @date 2020-05-20 */ @Mapper public interface SysUserRoleMapper { @Select("SELECT * FROM sys_user_role WHERE user_id = #{userId}") List<SysUserRole> listByUserId(Integer userId); }

Service设计

Spring Security提供了一个UserDetailsService接口，我们需要实现这个接口的loadUserByUsername方法，用于用户信息的获取，如果存在用户，则把用户的密码获取出来，如果不存在这个用户，直接抛异常。

我们新建一个SysUserDetailService.java

package org.hui.login.service; import org.hui.login.mapper.SysRoleMapper; import org.hui.login.mapper.SysUserMapper; import org.hui.login.mapper.SysUserRoleMapper; import org.hui.login.model.SysRole; import org.hui.login.model.SysUser; import org.hui.login.model.SysUserRole; import org.springframework.security.core.GrantedAuthority; import org.springframework.security.core.authority.SimpleGrantedAuthority; import org.springframework.security.core.userdetails.User; import org.springframework.security.core.userdetails.UserDetails; import org.springframework.security.core.userdetails.UserDetailsService; import org.springframework.security.core.userdetails.UsernameNotFoundException; import org.springframework.stereotype.Service; import java.util.ArrayList; import java.util.Collection; import java.util.List; /** * @author zenghui * @date 2020-05-20 */ @Service public class SysUserDetailService implements UserDetailsService { private final SysUserMapper sysUserMapper; private final SysRoleMapper sysRoleMapper; private final SysUserRoleMapper sysUserRoleMapper; public SysUserDetailService(SysUserMapper sysUserMapper, SysRoleMapper sysRoleMapper, SysUserRoleMapper sysUserRoleMapper) { this.sysUserMapper = sysUserMapper; this.sysRoleMapper = sysRoleMapper; this.sysUserRoleMapper = sysUserRoleMapper; } @Override public UserDetails loadUserByUsername(String username) throws UsernameNotFoundException { Collection<GrantedAuthority> authorities = new ArrayList<>(); // 从数据库中取出用户信息 SysUser user = sysUserMapper.selectByName(username); // 判断用户是否存在 if(user == null) { throw new UsernameNotFoundException("用户名不存在"); } // 添加权限 List<SysUserRole> userRoles = sysUserRoleMapper.listByUserId(user.getId()); for (SysUserRole userRole : userRoles) { SysRole role = sysRoleMapper.selectById(userRole.getRoleId()); authorities.add(new SimpleGrantedAuthority(role.getName())); } // 返回UserDetails实现类 return new User(user.getName(), user.getPassword(), authorities); } }

如果用户存在，则会进行密码的校验，方便起见，密码我们假设储存为明文，实际上密码有很多加密的策略，这个后序可以自己配置，密码校验在SecurityConfig这个类中，代码如下：

package org.hui.login.config; import org.hui.login.service.SysUserDetailService; import org.springframework.context.annotation.Configuration; import org.springframework.security.config.annotation.authentication.builders.AuthenticationManagerBuilder; import org.springframework.security.config.annotation.method.configuration.EnableGlobalMethodSecurity; import org.springframework.security.config.annotation.web.builders.HttpSecurity; import org.springframework.security.config.annotation.web.builders.WebSecurity; import org.springframework.security.config.annotation.web.configuration.EnableWebSecurity; import org.springframework.security.config.annotation.web.configuration.WebSecurityConfigurerAdapter; import org.springframework.security.crypto.password.PasswordEncoder; /** * @author zenghui * @date 2020-05-20 */ @Configuration @EnableWebSecurity @EnableGlobalMethodSecurity(prePostEnabled = true) public class SecurityConfig extends WebSecurityConfigurerAdapter { private final SysUserDetailService sysUserDetailService; public SecurityConfig(SysUserDetailService sysUserDetailService) { this.sysUserDetailService = sysUserDetailService; } @Override protected void configure(AuthenticationManagerBuilder auth) throws Exception { auth.userDetailsService(sysUserDetailService).passwordEncoder(new PasswordEncoder() { @Override public String encode(CharSequence charSequence) { return charSequence.toString(); } @Override public boolean matches(CharSequence charSequence, String s) { return s.equals(charSequence.toString()); } }); } @Override protected void configure(HttpSecurity localhost:8080/login

显示登录页面，输入用户名密码，点击登录，即可看到效果。

完整代码

Github

Gitee
