2021秋季MIT 6.S081 实验八 锁机制如何实现？

本文共计3029个文字，预计阅读时间需要13分钟。

开始日期：22.6.16操作系统：Ubuntu 20.0.4链接：Lab Lock目录：Lab Lock写在前面实验内容：Memory allocator access code, Buffer cache access code, result, 总结Lab Lock写在前面总结实验一：kalloctest使用

开始日期：22.6.16

操作系统：Ubuntu20.0.4

Link：Lab Lock

目录

• Lab Lock
  • 写在前面
  • 实验内容
    • Memory allocator
      • access code
    • Buffer cache
      • access code
    • result
  • 总结

Lab Lock 写在前面

总结一下，实验一kalloctest，使用了自旋锁、数组链表；
实验二，bcachetest中，使用了自旋锁、睡眠锁、哈希桶（哈希链表）、LRU（time stamp实现）

参考材料

• 《算法精解》

• LRU算法四种实现方式介绍

实验内容 Memory allocator

实现内存分配器，减少竞争，主要实现思路是原先只有一个freelist，一个lock给八个cpu竞争使用，而我们需要重新设计为八个freelist、八个lock给八个cpu使用。
中途会有一个问题，就是当某个cpu对应的freelist没有空闲页面了，该怎么办？实验介绍给出的方案是从其它cpu的freelist中偷（steal）过来，笔者的具体实现是依靠一个for循环遍历数组链表（kmems[NCPU]）找到一个空闲页面来用，如果所有页面都满了，就只能返回0。

笔者期间还遇到一个c语言的问题：结构体的是如何设置的？
经过查阅资料和自己测试，明白了在{前的是类型名（type name），是拿来定义的，在}后的是变量名（variable name），是拿来使用的

access code

// Physical memory allocator, for user processes, // kernel stacks, page-table pages, // and pipe buffers. Allocates whole 4096-byte pages. #include "types.h" #include "param.h" #include "memlayout.h" #include "spinlock.h" #include "riscv.h" #include "defs.h" void freerange(void *pa_start, void *pa_end); extern char end[]; // first address after kernel. // defined by kernel.ld. struct run { struct run *next; }; // we must have the type_name(Keme) so we can establish the array of struct(kmems[NCPU]) struct Keme{ struct spinlock lock; struct run *freelist; }; struct Keme kmems[NCPU]; void kinit() { // set eight "kmem" for eight cpus for(int i = 0; i < NCPU; i++){ initlock(&kmems[i].lock, "kmem"); // we build a single freelist to kmems[0] firstly if (i == 0) freerange(end, (void*)PHYSTOP); } } void freerange(void *pa_start, void *pa_end) { char *p; p = (char*)PGROUNDUP((uint64)pa_start); for(; p + PGSIZE <= (char*)pa_end; p += PGSIZE) kfree(p); } // Free the page of physical memory pointed at by v, // which normally should have been returned by a // call to kalloc(). (The exception is when // initializing the allocator; see kinit above.) void kfree(void *pa) { struct run *r; if(((uint64)pa % PGSIZE) != 0 || (char*)pa < end || (uint64)pa >= PHYSTOP) panic("kfree"); // Fill with junk to catch dangling refs. memset(pa, 1, PGSIZE); r = (struct run*)pa; // get current cpu_id push_off(); int cpu_id = cpuid(); pop_off(); // free a page from freelist of cpu_id acquire(&kmems[cpu_id].lock); r->next = kmems[cpu_id].freelist; kmems[cpu_id].freelist = r; release(&kmems[cpu_id].lock); } // Allocate one 4096-byte page of physical memory. // Returns a pointer that the kernel can use. // Returns 0 if the memory cannot be allocated. void * kalloc(void) { struct run *r; // get current cpu_id push_off(); int cpu_id = cpuid(); pop_off(); acquire(&kmems[cpu_id].lock); // use 'acquire' also disable intrruption r = kmems[cpu_id].freelist; // if freelist of current cpu_id has freepage we use it if(r){ kmems[cpu_id].freelist = r->next; release(&kmems[cpu_id].lock); memset((char*)r, 5, PGSIZE); // fill with junk return (void*)r; } // else we steal freepage from other freelist of cpus else{ release(&kmems[cpu_id].lock); for(int i = 0; i < NCPU; i++){ // avoid race condition(same cpu_id lock) if (i != cpu_id){ acquire(&kmems[i].lock); // the last_list also not memory so ret 0 if(i == NCPU - 1 && kmems[i].freelist == 0){ release(&kmems[i].lock); return (void*)0; } // It is OK to allocte a freepage by stealing from other cpus if(kmems[i].freelist){ struct run *to_alloc = kmems[i].freelist; kmems[i].freelist = to_alloc->next; release(&kmems[i].lock); memset((char*)to_alloc, 5, PGSIZE); // fill with junk return (void*)to_alloc; } // if no matching condition, we must release current lock release(&kmems[i].lock); } } } // Returns 0 if the memory cannot be allocated. return (void*)0; } Buffer cache

实现buffer cache的并发（concurrency），保证一个不变性（invariant ）：即每次只有一个buffer被cpu或者process使用。同时不要让其它process或cpu都等待一个cache lock（这暗示要使用睡眠锁）

实现思路主要是将30个buf（NBUF == 30）划分为13个哈希桶（bucket），每个bucket都有一个对应的自旋锁即bcache.bucket。分配一个buf时，先对bache上锁，再对这个buf对应的bucket上锁，分配结束之后，先对这个buf对应的bucket解锁，再对bache解锁，达成不变性的要求。

• 为了完成划分，笔者将哈希表的前两个bucket的buf为4个，后十一个bucket的buf设置为2个。这也是加上辅助函数get_max_buf的原因。
• 这里会涉及到一个问题，为什么不每个buffer都设一个锁，因为实际上每个buffer已经有对应的睡眠锁，这些睡眠锁是使用buf里的数据内容时才使用的。那为什么不能再设定一个自旋锁呢？笔者目前没能清楚为什么不行，笔者猜测和8.1 ~ 8.3相关，但是我没有完全弄明白这些章节。
• 笔者只知道，访问一个buf的结构时是不需要对sleeplock: buffer进行上锁、解锁操作，只有使用这个buf的数据内容才需要对sleeplock: buffer进行上锁、解锁操作，原因应该也是和章节相关。但是访问bucket是肯定要用两个锁的（sleeplock: cache和spinlock: bcache.bucket）
• 为什么将bucket的数量设置为质数后，就可以减少访问buckets时冲突，笔者猜测这里涉及到hashtable的知识点了，但没有继续深入。

为了实现LRU，笔者使用了ref_is_zero_nums、ref_is_zero[NBUK][MAXBUF]等变量用来找到最大时间戳（lru_time_stamp）对应的哈希桶编号（lru_bucket）和缓存区编号（lru_buf），这里会有三种情况。

• ref_is_zero_nums == 0，说明没有buf的refcnt == 0，直接报错
• ref_is_zero_nums == 1，说明只有一个buf的refcnt == 0，直接把它分配出去
• 其它情况，即ref_is_zero_nums >= 2，说明至少有两个buf的refcnt == 0，我们要找出它们当中的最大时间戳（lru_time_stamp）对应的哈希桶编号（lru_bucket）和缓存区编号（lru_buf）

brelse()、bpin()、 bunpin()的使用都不需要使用sleeplock: cache

• brelse()是因为不再使用bcache.head了，所以不需要使用sleeplock: cache
• bpin()、 bunpin()不使用是因为访问一个buf的结构时不需要任何用锁
  • 使用sleeplock: cache会导致panic: sched locks

access code

首先是一些定义：

笔者遇到一件很奇葩的事情，在2021版本usertests在qemu里面跑的时候能够通过，但是使用make grade指令跑的时候就无法通过。更奇葩的是，在2020版本就能够跑过，但是2021版本就跑不过（哭笑），解决方案是参考20版本把FSSIZE改为10000。不改的话会导致panic: balloc: out of blocks

/* param.h */ ... #define FSSIZE 10000 // size of file system in blocks #define MAXPATH 128 // maximum file path name #define NBUK 13 // a fixed number of buckets in a hashtable of cache #define MAXBUF 4 // buckets[0] or buckets[1] has 4 buffers, other buckets[i] has 2 buffers(i: 2 ~ 12) /* buf.h */ struct buf { ... uchar data[BSIZE]; uint time_stamp; // the time stamp of current block };

然后是实现代码：

// Buffer cache. // // The buffer cache is a linked list of buf structures holding // cached copies of disk block contents. Caching disk blocks // in memory reduces the number of disk reads and also provides // a synchronization point for disk blocks used by multiple processes. // // Interface: // * To get a buffer for a particular disk block, call bread. // * After changing buffer data, call bwrite to write it to disk. // * When done with the buffer, call brelse. // * Do not use the buffer after calling brelse. // * Only one process at a time can use a buffer, // so do not keep them longer than necessary. #include "types.h" #include "param.h" #include "spinlock.h" #include "sleeplock.h" #include "riscv.h" #include "defs.h" #include "fs.h" #include "buf.h" // each bucket has a lock, the name already be setted to 'bcache.bucket' struct Bucket{ struct spinlock lock; struct buf buf[MAXBUF]; }; struct Bcache{ // we must use sleeplock so that // "don't all(processes, cpus) have to wait for bcache.lock" struct sleeplock lock; struct Bucket buckets[NBUK]; } bcache; // we use bcache, but we don't use bcache's' // buckets[0] or buckets[1] has 4 buffers // and other buckets[i] has 2 buffers(i: 2 ~ 12) // get the max buf of current bucket int get_max_buf(int i){ int max_buf = MAXBUF - 2; if (i == 0 || i == 1) max_buf = MAXBUF; return max_buf; } void binit(void) { struct buf *b; initsleeplock(&bcache.lock, "bcache"); int max_buf; for(int i = 0; i < NBUK; i++){ // each bucket has a lock, the name already be setted to 'bcache.bucket' initlock(&bcache.buckets[i].lock, "bcache.bucket"); max_buf = get_max_buf(i); for (int j = 0; j < max_buf; j++){ b = &bcache.buckets[i].buf[j]; initsleeplock(&b->lock, "buffer"); acquire(&tickslock); b->time_stamp = ticks; // a buf get the current time_stamp release(&tickslock); } } } // Look through buffer cache for block on device dev. // If not found, allocate a buffer. // In either case, return locked buffer. static struct buf* bget(uint dev, uint blockno) { struct buf *b; int max_buf; acquiresleep(&bcache.lock); // Is the block already cached? for(int i = 0; i < NBUK; i++){ acquire(&bcache.buckets[i].lock); max_buf = get_max_buf(i); for (int j = 0; j < max_buf; j++){ b = &bcache.buckets[i].buf[j]; if(b->dev == dev && b->blockno == blockno){ b->refcnt++; acquire(&tickslock); b->time_stamp = ticks; // update time_stamp, bacause the block be used release(&tickslock); release(&bcache.buckets[i].lock); releasesleep(&bcache.lock); acquiresleep(&b->lock); return b; } } release(&bcache.buckets[i].lock); } // Not cached. // Choose the least recently used (LRU) unused buffer based on time_stamp. // init ref_is_zero[NBUF] int ref_is_zero[NBUK][MAXBUF]; for(int i = 0; i < NBUK; i++){ max_buf = get_max_buf(i); for(int j = 0; j < max_buf; j++) ref_is_zero[i][j] = 0; } // find to all refcnts equale to 0, // and set a lru_bucket and lru_buf when their refcnt equal 0 int ref_is_zero_nums = 0; int lru_bucket = 0; int lru_buf = 0; for(int i = 0; i < NBUK; i++){ acquire(&bcache.buckets[i].lock); max_buf = get_max_buf(i); for (int j = 0; j < max_buf; j++){ b = &bcache.buckets[i].buf[j]; if (b->refcnt == 0){ ref_is_zero[i][j] = 1; ref_is_zero_nums++; lru_bucket = i; lru_buf = j; } } release(&bcache.buckets[i].lock); } // 0 => panic; 1 => alloc a buffer; other => find the max time_stamp then goto alloc a buffer if (ref_is_zero_nums == 0) panic("bget: no buffers"); if (ref_is_zero_nums == 1){ // do noting but alloc a buffer } else{ uint lru_time_stamp; acquire(&bcache.buckets[lru_bucket].lock); b = &bcache.buckets[lru_bucket].buf[lru_buf]; lru_time_stamp = b->time_stamp; release(&bcache.buckets[lru_bucket].lock); for(int i = 0; i < NBUK; i++){ acquire(&bcache.buckets[i].lock); max_buf = get_max_buf(i); for(int j = 0; j < max_buf; j++){ if (ref_is_zero[i][j] == 1){ b = &bcache.buckets[i].buf[j]; if (b->time_stamp > lru_time_stamp){ lru_time_stamp = b->time_stamp; lru_bucket = i; lru_buf = j; } } } release(&bcache.buckets[i].lock); } } // alloc a buffer acquire(&bcache.buckets[lru_bucket].lock); b = &bcache.buckets[lru_bucket].buf[lru_buf]; b->dev = dev; b->blockno = blockno; b->valid = 0; b->refcnt = 1; acquire(&tickslock); b->time_stamp = ticks; // update time_stamp, bacause the block be used release(&tickslock); release(&bcache.buckets[lru_bucket].lock); releasesleep(&bcache.lock); acquiresleep(&b->lock); return b; } // Return a locked buf with the contents of the indicated block. struct buf* bread(uint dev, uint blockno) { struct buf *b; b = bget(dev, blockno); if(!b->valid) { virtio_disk_rw(b, 0); b->valid = 1; } return b; } // Write b's contents to disk. Must be locked. void bwrite(struct buf *b) { if(!holdingsleep(&b->lock)) panic("bwrite"); virtio_disk_rw(b, 1); } // Release a locked buffer. // Move to the head of the most-recently-used list. void brelse(struct buf *b) { if(!holdingsleep(&b->lock)) panic("brelse"); releasesleep(&b->lock); // why don't acquire lock of 'cahce'? // we use lock of 'cahce', because we use 'bcache.head' in orinal version // because we just change time_stamp of 'b'(buffer), we don't use any lock b->refcnt--; acquire(&tickslock); b->time_stamp = ticks; // update time_stamp, bacause the block be used release(&tickslock); } // we don't use bache.lock, becasue we can directly access the struct of buf void bpin(struct buf *b) { // acquiresleep(&bcache.lock); b->refcnt++; // releasesleep(&bcache.lock); } void bunpin(struct buf *b) { // acquiresleep(&bcache.lock); b->refcnt--; // releasesleep(&bcache.lock); } result

笔者还改了下timeout=300 为 times=500

== Test running kalloctest == $ make qemu-gdb (107.5s) == Test kalloctest: test1 == kalloctest: test1: OK == Test kalloctest: test2 == kalloctest: test2: OK == Test kalloctest: sbrkmuch == $ make qemu-gdb kalloctest: sbrkmuch: OK (15.7s) == Test running bcachetest == $ make qemu-gdb (22.0s) == Test bcachetest: test0 == bcachetest: test0: OK == Test bcachetest: test1 == bcachetest: test1: OK == Test usertests == $ make qemu-gdb usertests: OK (289.6s) == Test time == time: OK Score: 70/70 总结

• 完成日期：22.6.18
• 本次实验，笔者践行“无论如何都不看参考答案”的信念，第一次体验到完全靠自己完成的快感，在图书馆里欢呼起来了，体验到了知识被应用、知识被链接时，自我生长的感觉
• 一开始关于hashtable的概念不是很清楚，导致结构体的定义出错，后面就不可能对了。看了《算法精解》才搞懂
• 写概括性注释真的很重要，16号写完kalloctest，等到18号写blog的时候就记得不是很清楚了
• 最近在听Sunshine Girl moumoon
